READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
10070221 REV 3 P-1 - 01/21
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
NYELX-C2 Series
1
Installation Instructions
Phone: (800) 556-7690
www.mulelighting.com
Advertisement
Related Manuals for MULE NYELX-C2 Series
Summary of Contents for MULE NYELX-C2 Series
- Page 1 NYELX-C2 Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
-
Page 2: Installation Instructions
NYELX-C2 Series Installation Instructions Recessed Ceiling or Recessed Wall Mount Fig. 1 Recessed 1. Position the recessed kit between the joists. (Fig. 1) Joist Housing Bar Hanger 2. Align one end of the bar hangers with the bottom of the joist, then secure temporarily by hammering in the “nail-in”... - Page 3 NYELX-C2 Series Installation Instructions Surface Ceiling or Surface Wall Mount Fig. 5 J-box 1. Secure the adjustable crossbar to the J-box using the (2) 8-32 x 1” screws (supplied). Use the slotted portion of the adjustable crossbar to Adjustable Crossbar...
-
Page 4: Electrical Connections
NYELX-C2 Series Installation Instructions Electrical Connections Make electrical connections as follows: 120VAC 277VAC White - Common White - Common Black - 120VAC Orange - 277VAC Note: Cap unused wires to prevent shorting. Fig. 7 Battery 1 Battery 2 LED Strip... - Page 5 NYELX-C2 Series Installation Instructions Self-Test/Self-Diagnostics (SD) Operation The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the EXIT sign. At predetermined intervals, the EXIT sign will automatically switch into battery mode. Refer to the Self-Test Features section of this page for timing details.
