- Page 1 Petrol Air Compressor HP170-20P HD390-P HD390-P-ES HD390-PX4 HD390-PX4-ES HD500-P HD500-P-ES HD710-P HD710-P-ES INSTRUCTION MANUAL INSTRUCTION MANUAL Read through carefully and understand these instructions before use...
- Page 2 ■ SPECIFICATIONS HD170- HD390- HD390- HD390- HD500- HD710- Model HD390-P HD500-P HD710-P P-ES PX4-ES P-ES P-ES Power 4.6hp 6.5hp 6.5hp 6.5hp 6.5hp 13hp 13hp Free Air 170LPM 390LPM 390LPM 390LPM 390LPM 498LPM 498LPM 710LPM 710LPM Delivery Tank 180L 180L Size Cylinder Single Triple...
-
Page 3: Hot Components
DO NOT FORCE AIR COMPRESSORS The air compressor will do a better, safer job and give you much better service if it’s used at the duty cycle for which it was designed. The duty cycle will only take effect after the initial (1st ) tank fill for the day. This air compressors duty cycle is 75%. - Page 4 MAINTAIN YOUR AIR COMPRESSOR WITH CARE Follow the instructions for lubricating and changing accessories. Keep handles clean, dry and free from oil and grease. Ensure that ventilation slots are kept clean and free from dust at all times. Blocked ventilation slots or air filter can cause overheating and damage to the motor and this will not be covered under warranty.
-
Page 5: Ear Protection
■ PERSONAL SAFETY CLOTHING Do not wear loose clothing, jewellery or anything that could get caught in moving machinery. HAIR Long hair should be tied back or contained in a protective covering. EYE PROTECTION The use of safety goggles is highly recommended (normal glasses are not sufficient for eye protection) when using an air compressor. - Page 6 ■ SPECIFIC SAFETY INSTRUCTIONS WARNING! Do not use the air compressor in areas where there is a risk of explosion or fire from combustible materials. The sparks generated from certain tools attached to air compressor can ignite combustible materials as well as flammable liquids, paint, varnish, petrol, flammable gases and dust of an explosive nature. As a precaution it is recommended that you consult an expert on a suitable fire extinguisher and its use.
- Page 7 ■ OPERATING INSTRUCTIONS UNPACKING Carefully unpack your air compressor. This air compressor is bulky and heavy; a machinery assisted lift required. Dispose of all packing material in an environmentally responsible manner. ASSEMBLY Your air compressor requires minor assembly before initial operation. Check that you have all required components needed for assembly and initial use.
- Page 8 ■ ASSEMBLY & INSTALLATION Keep the engine at least 1 metre (3 ft) away from building walls and other equipment to prevent a fire hazard and ensure that the exhaust does not blow onto any surface. An exhaust deflector is supplied with the compressor for use, if necessary.
- Page 9 ■ RUNNING IN YOUR NEW AIR COMPRESSOR Before running in ensure that the following has been completed: Always check first to ensure that it has been received, inspected and installed in accordance with the instructions herein. Rectify any discrepancies before proceeding further. Check the compressor pump oil level by looking at the sight glass.
- Page 10 To minimize mechanical wear and tear, fuel consumption, and exhaust and noise emissions, do not operate the compressor unnecessarily for extended periods in unloading mode. Switch off the engine instead. Slowly open the outlet valve, but only if it is connected to a suitable compressed air hose(s) and/or distribution pipe(s) not open to the atmosphere.
-
Page 11: Belt Tension
■ BELT TENSION Correct belt tension is paramount to a safe and reliable air compressor. An over tight load belt can cause damage to bearings and premature motor failure. An over loose belt can cause poor performance and excess heat due to slippage which can also lead to premature component failure. This failures will not be covered by warranty. - Page 12 ■ MAINTENANCE DAILY Before use 1. Seal the tank drain tap. 2. Check the oil level. 3. Check safety valve operation. 4. Check the belt tension. Movement should be 10-15mm. Adjust if required. 5. Check for belt straightness. Adjust if required. After use 1.
- Page 13 THIS UNIT IS NOT DESIGNED FOR USE IN CONNECTION WITH ANY BREATHING APPARATUS WHATSOEVER. A SPECIALLY DESIGNED AIR COMPRESSOR IS NECESSARY FOR THIS FUNCTION. ALL RENEGADE INDUSTRIAL SERIES AIR COMPRESSORS ARE SPECIFIED ON SALE IN TERMS OF HORSEPOWER, TANK VOLUME, PUMP DISPLACEMENT, & FREE AIR DELIVERY. ACTUAL OUTPUT MUST MATCH OR EXCEED THE TOTAL REQUIREMENTS OF INTENDED USE.
- Page 14 ■ GENERAL VIEW AND MAIN COMPONENTS Image may not match exactly. For reference only.
- Page 15 Description Compressor Pump Air Filter Crankcase Breather Oil Fill Cap Oil Drain Plug Oil Level Sight Glass Petrol Engine Air Receiver Tank Air Receiver Tank Nameplate Drive Guard Handle Wheel Non-Return Valve Easy-Start Valve Unloading Line Safety Valve Drain Valve Discharge Outlet Pressure Gauge Pilot Valve...
- Page 16 TradeTools Pty Ltd 131 Quinns Hill Rd East Stapylton, Queensland 4207 P. 07 55406400 www.tradetools.com...
