Motorized Actuator SGSP-ACT Series SGSP(RE)-ACT-M2 Series Installation Manual CONTENTS For Your Safety ････････････3 Ⅲ．Check and Maintenance Ⅰ．Installation 1-1．Mounting 3-1．About Check and Maintenance ･･････････････････････6 ･････11 1-2．Connecting to Stage Controller 3-2．Lubrication ･･････8 ･････････････････････12 1-3．Connection Cables 3-3．About Life ･････････8 ･････････････････････12 1-4． 3-4．Store Controller setting ･････････9 ････････････・・・・・･･･13...
Page 2 ・ The prior written approval of SIGMAKOKI CO., LTD. is necessary to reprint or reproduce in whole or in part these materials. ・ If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license Japanese government and cannot be imported into a country other than the approved destination.
Page 3: For Your Safety
For Your Safety Before using this product, read this manual and all warnings or cautions in the  documentation provided. Only Factory Authorized Personnel should be changes and/or adjust the parts  of controller. The Symbols Used in This Manual WARNING CAUTION This symbol marks warnings that should...
Page 4: Disclaimer Of Liability
God, action by any third party, other accidents, and deliberate or accidental misuse. ④ If the equipment is used in a manner not specified by the SIGMAKOKI CO., LTD., the protection provided by the equipment may be impaired.
Page 5 CE marking EMC of this product has been measured by the connection of controller・cable in 【】on p8. Connecting to Stage Controller Since the compliance of the final machinery with EMC Directive will depend on such factors as the control-system equipment and electrical parts, it therefore must be verified through EMC measures by the customer of the machinery.
Page 6: Mounting ･･････････････････････6
Ⅰ．Installation 1-1．Mounting 【Before Installation】 (1) Please see our latest catalog for outer dimensions or sizes of fixing holes. (2) Check that your package includes the actuator and accessories. (3) Try an experimental connection of the actuator and the stage controller to see if the actuator can be driven by the controller correctly.
Page 7 Typical Installation of Motorized SGSP(RE)-6.5ACT-M2 Tighten Tighten Tighten SGSP(RE)-13,25ACT-M2 Tighten Tighten Use the attached nut to fix the motorized stage. •...
Page 8: Connecting To Stage Controller ･･････8
1-2．Connecting to Stage Controller Special Connection Cables (1) Connection with Stage Controller Insert the special cable with ・「D15H12A-RC-3」 See our latest catalog connectors at both ends into ・「GSEＦ-CA-3」 HIT-MV / HIT-SA-M2 SGSP(RE)-6.5ACT-M2 ←→ SHRC-203-M2 the connectors on the motorized SGSP(RE)-13ACT-M2 actuator and the stage controller.
Page 9: Controller Setting ･････････9
1-4．Controller Setting When performing step-out detection with the controller “HIT-MV/HIT-SA-M2” , please make the following settings in order for it to function normally. SGSP-6.5,13,25ACT SGSP(RE)-6.5,13,25ACT-M2 RES_UNIT Encoder resolution 500P/R 1-5．Resonance and Hunting of the Stages A motorized actuator will suddenly generate large vibration (noises) at a certain speed (frequency) range, which can result in missing steps or halting of actuator movement in the extreme case.
Page 10: Ⅱ．notes On Use
Ⅱ．Notes on Use 2-1．Operating Conditions The stage shall be used under the following conditions: Temperature : 5-40 °C Humidity 20-80% (without condensation) 2-2．Stepping Motor-driven actuator The ACT series has a knurled knob at the motor shaft, which allows you to rotate the •...
Page 11: Ⅲ．check And Maintenance
Ⅲ．Check and Maintenance 3-1．About Check and Maintenance Constant checks and maintenance are essential to operate the actuator without failure. Please see the Check and Maintenance List and perform daily checks and maintenance. (1) General Checks Check Before Operation Before you operate (move) the motorized actuator, or if the stage has been left unused for a considerable period of time, make sure that there are no abnormality or foreign substances in the moving parts as well as they are adequately greased to begin the operation (movement) of the actuator.
Page 12: Lubrication ･････････････････････12
(3) Check and Maintenance List Part Frequency How to check Remarks Moving Every time Check smoothness of stage move parts you use (precision guide block should slide smoothly) Check noises in movement Motor Every time Check noises in operation you use Check abnormal heat liberation during operation Position...
Page 13: Store ････････････・・・・・･･･13
3-4．Store If the motorized actuator will not be used for a long period of time, Wrap the motorized actuator body with anticorrosion paper or store it in a plastic bag containing a desicant. Please store under the following conditions. Temperature 0-40 °C Humidity 10-85% (without condensation)
