PLASMA MONITOR (DISPLAY)
WALL HANGER UNIT
Thank you for purchasing the Daewoo Electronic Plasma Display Wall Hanger Unit. This
wall unit is specifically designed for use with the Daewoo Plasma Display. To ensure the
safe operation of the unit, please read these instructions before installing.
INSTRUCTION MANUAL
DP-HG22
H W
A A
N L
G L
E
R
U
N
I
T
Advertisement
Related Manuals for Daewoo DP-HG22
Summary of Contents for Daewoo DP-HG22
-
Page 1: Instruction Manual
WALL HANGER UNIT Thank you for purchasing the Daewoo Electronic Plasma Display Wall Hanger Unit. This wall unit is specifically designed for use with the Daewoo Plasma Display. To ensure the safe operation of the unit, please read these instructions before installing. - Page 2 TABLE OF CONTENTS 1. Check for enclosed parts ... 2 2. Important Safety Instructions ... 3 3. Assembly Instructions ... 6 4. Adjusting angles after installation ... 12 To install the wall hanger unit, Please consult an Authorized service center first.
- Page 3 PLASMA DISPLAY HANGER UNIT 1. PLEASE CHECK THE ITEMS SHOWN BELOW FRAME SET A CONNECTING FRAME M5 SCREWS (20 MM) (12) PAPER PATTERN PLAN Paper pattern plan FRAME SET B CONCRETE WALL ANCHOR WALL SCREWS M5 SCREWS (30MM)
-
Page 4: Important Safety Instructions
(Failing to do so may cause the unit to vibrate and to fall) Do not use the wall hanger unit with other products. This wall hanger unit is specifically designed to fit the Daewoo Plasma Display. (Failing to do so may cause the unit to fall and break) - Page 5 PLASMA DISPLAY HANGER UNIT PLEASE FOLLOW THESE SAFETY PRECAUTIONS WHEN INSTALLING OR HANDLING Special care is needed when installing onto the wall due to its weight (35Kg) When installing on a concrete wall Please be sure to use the enclosed concrete anchors.
- Page 6 PLEASE FOLLOW THESE SAFETY PRECAUTIONS WHEN INSTALLING OR HANDLING When installing, please use the size referenced below to choose a place, and attach the paper pattern plan to the wall. It is important to use the paper pattern plan to choose the proper place; otherwise, it can result in damage to the wall and you will not be able to install the unit When installing, please allow at least 15 cm at the top, bottom, left and right on the wall, and clear all items away from where the unit will be.
-
Page 7: Assembling Instructions
PLASMA DISPLAY HANGER UNIT 3. ASSEMBLING INSTRUCTIONS PREPARATION WHEN THE PLASMA DISPLAY IS ATTACHED TO THE STAND TO DETACH THE STAND FROM THE PLASMA DISPLAY To avoid unwanted marks on the unit, place a protective covering over the surface you will be working on and lay the plasma display as shown below. - Page 8 MODEL: DP-HG22 INSTALLING THE WALL FRAME SET A ON THE PLASMA DISPLAY PANEL Replace the previous instruction (#2) with the following updated one. Four M5 screws are not used out of total number. Make sure the installation is secure. Installation by professional is preffered.
- Page 9 PLASMA DISPLAY HANGER UNIT INSTALLING WALL FRAME SET B AND CONNECTING FRAME INSTALLING WALL FRAME SET B AND CONNECTING FRAME. Frame set B Connecting Frame ATTACHING PAPER PATTERN PLAN ON THE WALL Place the enclosed paper pattern plan (actual size) on the wall with glue or tape.
- Page 10 INSTALL THE WALL FRAME SET ON THE WALL Install the wall frame set on the wall by matching the concrete anchors with the holes, then use the wall screws (8) to secure tightly. INSTALLING ON THE WALL HELD BY SUPPORTING WOODEN STRUCTURE If it is not feasible to attach frame set B firmly and completely, due to the distance between the two supporting woods;...
- Page 11 PLASMA DISPLAY HANGER UNIT INSTALLING PLASMA DISPLAY ON THE WALL CONNECTING UPPER PART OF FRAME SET A AND FRAME SET B Frame set A At least two people are needed to put these frames together. CONNECTING LOWER PART OF FRAME SET A AND FRAME SET B Adhere Frame set B to Plasma Display unit, then, take the lower part of Frame set B as pictured below and push the (Z) part up gently then let go to connect.
- Page 12 TO PROVIDE THE SECUREST FIT After installing plasma display and wall frame sets, for a more secure fit, secure M5 screws (M5x30) on the (Z) part so that (Z) will not move up and down as shown in the picture below.
- Page 13 PLASMA DISPLAY HANGER UNIT 4. ADJUSTING ANGLES AFTER INSTALLATION (10˚, 15˚, 20˚) HOW TO ADJUST VIEWING ANGLES Note This adjustment needs to be done when the plasma display is tightly secured. Otherwise, the unit can fall and break. Please retain the two screws for future angle adjustments. At least two people are needed when modifying angle adjustment.
