- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. BROAN QL130WW Owner's Manual Shop genuine replacement parts for BROAN QL130WW Find Your BROAN HVAC Parts - Select From 1309 Models -------- Manual continues below --------...
-
Page 2: Important Safety Instructions
& save these instructions! Ql100 series range hood To register this product visit: www.broan.com intended For doMestic cooKinG onlY iMPortant saFetY instructions iMPortant saFetY instructions 1. For general ventilating use only. do not use to exhaust hazard- WarninG – to reduce the risK oF Fire, electric shocK, ous or explosive materials and vapors. -
Page 3: Vertical Discharge
horiZontal discharGe throuGh Wall WALL SUPPLIED DUCT WALL CAP TRANSITION (Model 838AL) RANGE HOOD FiGure 1 ROOF CAP vertical discharGe usinG 3¼” x 10” duct CUTOUT DIMENSIONS 1" ELBOW EAVE CAP (Model 836AL) VIEW 3¼" x 10" 12" 9" DUCT "... -
Page 4: Installation
PreParation locators 1. Use the dimensional drawings (refer to FiGures 1 - 3) to lay BaFFle out the range hood’s mounting holes, wiring access and duc- Plate twork by marking the cabinet bottom and drywall where appli- cable. NOTE: Cabinets with recessed bottoms will require wood shims to make mounting surface flush with cabinet frame. 2. Make cutouts for wiring and ductwork. 3. If the hood is to be ducted, install the ductwork so that is flush to the range hood’s mounting surface. refer to FiGure 1 if the range hood is to be installed with a FiGure 4 horizontal discharge. refer to FiGure 2 and FiGure 3 if the range hood is to be installed with a vertical discharge. 4. Run two-conductor wire (with ground) from a power source to the hood location. Bring approximately 12” of wiring through 7”... -
Page 5: Wiring Connections
2. refer to FiGure 9. The filter slides into channels at the back of the hood, on either side of the fan compartment, and snaps under the spring clips near the front of the fan compartment. Maintenance Filters iMPortant: The aluminum filter should be removed once monthly and washed in hot detergent water. Rinse in clear, warm water and shake off excess moisture before replacing. The filter may also be cleaned in your dishwasher. FiGure 9 in a non-ducted installation: Replace filter every 3-6 months as needed. cleaninG The hood should be wiped off occasionally both inside and outside using warm water, mild dish detergent and a soft cloth. Never use scouring powders, steel wool pads or any other abrasive cleaners which will destroy the hood’s finish. rePlaceMent Parts Should replacement parts be required, please indicate hood model number and appropriate part number. Contact your Broan dealer or NuTone at: In the U.S. contact: Broan-nutone llc Hartford, Wisconsin www.broan.com 800-558-1711 In the Canada contact: Broan-nutone canada Mississauga, Ontario www.broan.ca 877-896-1119... -
Page 6: Service Parts
service Parts KeY no. Part no. descriPtion R680508 7-in. Round Duct Plate R99360244 Knob, White (2 req.) R99360247 Knob, Biscuit (2 req.) R401658 Grille, White R401659 Grille, Biscuit R740014 3¼” x 10” Damper Assembly R520135 Motor R566096 Lamp Socket Assembly (Short Wires) R566097 Lamp Socket Assembly (Long Wires) R531076 Fan Blade R607225 External Hitch Pin (Hairpin) R401603 Baffle, White R401606 Baffle, Biscuit R680541 Wiring Cover R401650 Light Lens R610092 Aluminum Filter R561138 Fan & Light Switch NTK4402-000 Rectifier Assembly (Night Light) R111687... -
Page 7: Warranty
WarrantY Broan one Year liMited WarrantY Broan warrants to the original consumer purchaser of its products that such products will be free from defects in materials or work- manship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IM- PLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. During this one-year period, Broan will, at its option, repair or replace, without charge, any product or part which is found to be defec- tive under normal use and service. THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS AND TUBES. This warranty does not cover (a) normal maintenance and service or (b) any products or parts which have been subject to misuse, negligence, accident, improper maintenance or repair (other than by Broan), faulty installation or installation contrary to recommended installation instructions. The duration of any implied warranty is limited to the one-year period as specified for the express warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. BROAN’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLU- SIVE REMEDY UNDER THIS WARRANTY. BROAN SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This warranty su- persedes all prior warranties. To qualify for warranty service, you must (a) notify the company at the address or phone number below (b) give the model number and part identification and (c) describe the nature of any defect in the product or part. At the time of requesting warranty service, you must present evidence of the original purchase date. In the U.S. contact: Broan-nutone llc Hartford, Wisconsin www.broan.com 800-558-1711 In the Canada contact: Broan-nutone canada Mississauga, Ontario www.broan.ca 877-896-1119 Product specifications subject to change without notice. Printed in U.S.A., Rev. 02/08, Part No. 628029B...
