Summary of Contents for Subcold TREK Series
- Page 1 TREK SERIES PLEASE READ & RETAIN USER MANUAL FOR FUTURE REFERENCE USER MANUAL...
-
Page 2: Table Of Contents
Contents Important Safety Warnings __________________________________________ 3-4 Intended Usage & Environment _______________________________________ 4 Operating Instructions & Control Panel ________________________________ 5-9 Disconnecting & Handling Instructions _________________________________ 9 Maintenance _____________________________________________________ 10 Defrost __________________________________________________________ 11 Troubleshooting Guide ______________________________________________ 12 Product Specification _______________________________________________ 13 EPREL ____________________________________________________________ 14 Warranty __________________________________________________________ 14 Environmental Friendly Disposal ______________________________________ 14... -
Page 3: Important Safety Warnings
Important Safety Warnings • Ensure the appliance's power cable is not trapped or damaged during positioning. • Refrain from positioning portable power sockets or cables at the rear of the appliance. • Exercise caution to prevent the risk of child entrapment. •... -
Page 4: Intended Usage & Environment
Travel with Comfort and Convenience Whether it's for a day trip or a long excursion, the Subcold fridge is your reliable travel companion, ensuring access to fresh and chilled food and beverages throughout your adventure. Built to be energy-efficient, this fridge offers sustainability without sacrificing performance, suitable for both outdoor adventures and home use. -
Page 5: Operating Instructions & Control Panel
Operating Instructions & Control Panel Power Connection and Usage For Car Use: DC Power Cord: The unit comes with a 12V/24V DC power cord specifically for use in vehicles. Refer to Image 1 to see how to connect it in your car. For Home Use: Power Adapter: For indoor use, there is an optional power adapter that works with the DC power cord. - Page 6 Operating Instructions & Control Panel Operating Instructions for Your Appliance Powering On and Off: To Power On: Briefly press and hold the POWER button for 1 second. This will turn on the appliance and activate the display screen. To Power Off: Press and hold the POWER button for 3 seconds. Using the Control Panel: Unlocking the Screen: After switching the appliance on, if you need to use the control panel, start by unlocking the screen.
- Page 7 Operating Instructions & Control Panel Error Handling: Voltage Issues: If 'E1' appears on the display, indicating a voltage issue, you may need to lower the battery setting by one level (from H to M or L, or from M to L), depending on your vehicle's output voltage.
- Page 8 Operating Instructions & Control Panel Variable Vehicle Output: Be aware that the voltage output can vary from vehicle to vehicle. If the display shows an 'E1' error, it indicates a mismatch or issue with the voltage. Adjusting Voltage Levels: Should this occur, you can reduce the voltage setting by one level— for example, from High (H) to Medium (M), or from Low/Medium (L/M) to Low (L).
-
Page 9: Disconnecting & Handling Instructions
Operating Instructions & Control Panel Using the App: With the Bluetooth app, you can access various features of your fridge: • Adjust Settings: Tap the lock icon to unlock; it will automatically re-lock after 30 seconds of inactivity. • Temperature Controls: Check or change the temperature settings and the unit of measurement. •... -
Page 10: Maintenance
Maintenance Interior Maintenance: - Clean the interior of the appliance with clean water or neutral detergent. Clean thoroughly and wipe it dry with a clean cloth. Maintenance of the Door Gasket: - Carefully clean the door gaskets to prevent damage, especially if they are polluted by stains like oil or sauce. -
Page 11: Defrost
Defrost Excessive frost accumulation can impact the appliance's refrigeration efficiency and escalate energy consumption. Therefore, defrosting becomes necessary when the frost reaches a thickness of 5 mm. The manual defrosting process involves the following steps: • Remove all contents from the appliance. •... -
Page 12: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE CAUSES & SOLUTIONS • The appliance does not work Confirm if the power supply is functioning correctly. • Ensure the connectors are securely connected. • Check if the fuse has blown. • Verify if the power is switched on, indicated by the pan- el's illumination. -
Page 13: Product Specification
Product Specification Model TREK20 TREK32 TREK40 TREK50-DZ Colours Black + Grey Black + Grey Black + Grey Black + Grey Cooling System BX Compressor Cooling BX Compressor Cooling BX Compressor Cooling BX Compressor Cooling Temperature +24°C to -22°C +24°C to -22°C +24°C to -22°C Dual-zone +20°C to -20°C Range... -
Page 14: Eprel
TREK20 TREK40 TREK50 Warranty Registration To register your product warranty, kindly visit www.subcold.com/pages/product-registration and fill out the online form. Environmental Friendly Disposal To avoid any harm to the environment or human health caused by improper disposal of electrical waste, recycle the appliance responsibly to promote the reuse of material resources. - Page 15 01506 440557 @subcoldltd @subcold_official Subcold Ltd. 28/2 Firth Road Houstoun Industrial Estate Livingston, EH54 5DJ United Kingdom Authorised Representative Eurolink Europe Compliance Limited 25 Herbert Place Dublin, D02 AY86 Republic of Ireland...
