Installation and Operating Manual
Important Safety Instructions
Polarization Instructions for Models CS-8 and CS-RM with power. These have a polarized plug (one blade wider than
the other). This plug will fit in a Polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If
it does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way! DO NOT USE
WITH EXTENSION CORD! When using an electrical vacuum cleaner, basic precautions should always be followed
including the following: Read all instructions carefully before using this vacuum cleaner.
Warning: To reduce the risk of fire, electric shock, or injury
1. Do not leave appliance when plugged in. Unplug from an electrical outlet when not in use and before servicing.
2. Do not use outdoors, on wet surfaces or to suck up drywall/saw dust.
3. Never operate this vacuum cleaner without a dust bag and filters in place.
4. Close attention is necessary when used by or near children. Do not allow unit to be used as a toy.
5. Use only for intended use as described in this manual. Use only the manufacturer's recommended attachments
and dust bag.
6. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left
outdoors, or fell into water, return the vacuum cleaner to InterVac or an authorized service dealer for examination
and repair.
7. Do not put any object into openings. Do not use with any openings blocked; keep free of dust, lint, hair, and any
other material that may reduce air flow. When the secondary filter becomes dirty, rinse in warm water or replace
with a new filter. Filter should be completely dry before using.
8. Never drop or insert any object into any opening.
9. Turn off all controls before unplugging.
10. Do not pull or carry by cord, do not use cord as a handle, do not close a door on the cord, or pull cord around
sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
11. Do not unplug by pulling on cord. To unplug, grasp the plug. not the cord.
12. Keep hair, loose clothing, fingers, and all parts of body away from any openings and all moving parts.
13. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
14. Use extra caution when cleaning on stairs.
15. Do not handle plug or appliance with wet hands.
16. Do not pick up flammable or combustible liquids such as gasoline or use in areas where they may be present.
17. Do not place objects against the vacuum cleaner. Keep area clear.
https://tiffin-motor-homes-prod.mindtouch.us/Resources/All_Component_Manuals/Appliances/InterVac/Installation_and_Oper...
Updated: Fri, 27 Sep 2024 19:18:11 GMT
Powered by
1
Advertisement
Related Manuals for Tiffin Motorhomes CS-8
Summary of Contents for Tiffin Motorhomes CS-8
- Page 1 Important Safety Instructions Polarization Instructions for Models CS-8 and CS-RM with power. These have a polarized plug (one blade wider than the other). This plug will fit in a Polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it does not fit, contact a qualified electrician to install the proper outlet.
-
Page 2: Specification
23. Do not install in any area where explosive vapors or fumes, Might be present. Specification: CS-6 and CS-8 120Volt, 10Amp60Hz, Weight 5.5 lb. CS-RM 120 Volt, 10Amp 60Hz high efficiency motor, Weight 5.6 lb. CS and CS-RM 220 Volt, 5 Amp, 50/60 Hz Parts List: •... - Page 3 3) X250 dust brush 10) D900 pipe to flex-hose coupling, CS-RM 4) X300 upholstery tool 11) X640 2” dia. flex-hose, CS-RM only 5) X200 crevice tool 12) Y10 for CS6/8, Y11 for CS-RM/9/10, dust bag 6) X157 telescoping wand 13) E30 6’ low voltage wire, for CS-RM only 7) 35-foot vacuum hose depending on model 1) on-off switch 2) sliding hole cover...
- Page 4 hole of the power unit. 2. Install the vacuum valve about 3 to 4 feet from the vacuum. (The 2” dia. Flex-hose comes standard at 4’ feet long.) 3. With a circular saw, see above on the right and below, cut a 2-1/2” hole, with a jig saw open the hole so that the vacuum valve is flush with the wall.
- Page 5 https://tiffin-motor-homes-prod.mindtouch.us/Resources/All_Component_Manuals/Appliances/InterVac/Installation_and_Oper… Updated: Fri, 27 Sep 2024 19:18:11 GMT Powered by...
- Page 6 If the vacuum stops running: If the vacuum hose becomes clogged the motor will shut off. Push the switch into "source" (Model CS-6) or "off" position (Model CS-8 and CS-RM) and let the motor cool down for one hour. Restart the vacuum without the vacuum hose attached and push the slider cover to open on the front panel, let the vacuum run for about 10 minutes.
- Page 7 2. To stop the vacuum cleaner, push the switch to the "O" off or "MICRO / SOURCE" position depending on Model. How to change vacuum dust bag CS-6 and CS-8 Model with single collar bag 1. Remove the front panel on the vacuum cleaner by sliding the latch/lock to the left and remove the front panel and dust bag.
-
Page 8: Troubleshooting
CS-RM Model with double collar bag 1. Remove the front panel on the vacuum cleaner by sliding the latch/lock to the left and remove the front panel with dust bag attached dust bag. Remove full bag and discard. 2. Please notice: the #Y11 double sided bag has 2 openings. The collar which attaches in the back of the vacuum chamber is clearly marked "PUSH THIS COLLAR OVER PIPE IN THE BACK OF THE VACUUM CHAMBER FIRST"... - Page 9 • One of the gray hoses connecting the vacuum with a valve came loose or was not connected properly. • The slider on the vacuums front panel is not closed. If motor suddenly stops: • The most common cause is a clogged hose. Disconnect vacuum hose from cleaner, hold one end high up in the air and drop a quarter or similar object into the hose.
