XROCKER 2.0 BLUETOOTH User Manual

2.0 BLUETOOTH
NEED HELP?
EMAIL: SUPPORT@XROCKERGAMING.COM
WWW.XROCKERGAMING.COM
IMPORTANT: You must keep your original retail receipt as proof of purchase.
WIRED CONNECTION
TV & Tablets (ALL CONSOLES)
B1
1. Connect B1 Cable to X Rocker control panel
3.5mm INPUT socket.
2. Connect other end of the B1 cable to the TV
headphone socket.
3. Once connected to your TV, increase volume to
50% of the maximum for the best sound level.**
*If your TV does not feature a headphone socket then
you may need to purchase an additional TOSlink
adapter to get connected directly to a console for
audio.
**Depending on your TV you may need to increase
the headphone volume separately in the TV sound
settings.
TROUBLESHOOTING TIPS
No power going to control panel
No Sound
Sound is faint
My audio cables broke accidentally
My TV doesn't have a headphone socket
USER MANUAL - ENGLISH
®
CONNECT BY CONTROLLER
PS4 SYSTEMS ONLY
1. Connect B1 Cable to the bottom of the PS4
controller via the headset socket.
2. Connect the other end of the B1 cable to the chair
via the green port.
3. With the PS4 turned on and in the main menu,
press and hold the black PS button until the quick
menu appears.
4. In this menu select [Adjust Sound and Devices]
5. Then select [Output to Headphones]
6. Change the setting from [Chat Only] to [All Audio]
7. Make sure the volume in the previous menu is set to
the maximum.
• Make sure that the cable is connected correctly.
• Make sure that the power supply at the power source is working correctly.
• With the chair turned ON, wiggle the cable in the port. If lights flicker, contact support.
• Connect a phone using the TV connection guide to test the chair for sound
• Confirm that the device/system is correctly configured
• Make sure that you indeed have a headphone socket on your TV.
• Make sure the volume of the source device is at a higher level to strengthen the signal.
• Please contact X Rocker Support
• You may need to purchase a TOSlink Adapter. If you're unsure which one, contact support.
3M 3.5MM TO 3.5MM AUDIO CABLE
B1
FEMALE TO FEMALE RCA ADAPTERS
B3
BLUETOOTH CONNECTION
B1
1. On the audio output device, go into the
2. Once you're connected, the Bluetooth indicator
HEALTH & SAFETY
• Don't let X Rocker come in contact with liquids
• Consult Support before unscrewing any electrical components
• Be mindful of cables laying between X Rocker and Power Source
• Be mindful of cables when moving/swivelling in the X Rocker
• Note that broken cables may present a choking risk. Replace
broken cables through Support.
• Do not stand on X Rocker or exceed 250lbs
• Do not lean back on the chair to the point that the pedestal lifts
• Do not use arms as support for getting in and out of chair.
• Playing audio for long periods at loud volumes may contribute to
difficulties in hearing.
POWER SUPPLY CORD
B2
3M 3.5MM TO RCA FEMALE AUDIO CABLE
B4
Gaming Chair
Bluetooth settings, turn Bluetooth on if it is not
on already, and search for Gaming Chair. Upon
finding this, select the Gaming Chair option. If a
passcode is required, the four digit code will be
'0000'.
on the panel will light up.
