RBS Holdings Pinewood Assembly Book

14'x16' building
Hide thumbs

Advertisement

Quick Links

Download this manual
Sentry Buildings
Assembly Book
Revised August 21, 2024
the Pinewood
14'x16' Building
Manufactured by RBS Holdings, LLC
205 Arlington Drive
Greenville, PA 16125
This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from
RBS Holdings, LLC
© Copyright 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pinewood and is the answer not in the manual?

Questions and answers

Related Manuals for RBS Holdings Pinewood

Summary of Contents for RBS Holdings Pinewood

  • Page 1 Assembly Book Revised August 21, 2024 the Pinewood 14'x16' Building Manufactured by RBS Holdings, LLC 205 Arlington Drive Greenville, PA 16125 This manual is copyrighted. Under the copyright laws, this manual may not be copied, in whole or in part, without consent from RBS Holdings, LLC ©...
  • Page 2 MPORTANT NFORMATION BOUT Thank you for purchasing our kit. Please read the following information before beginning construction. Always check with your local HOA or building code office for any requirements or restrictions. Floor: Wood flooring is sold optionally. You may choose to build your own or pour a cement pad. Always wear safety glasses when cutting or nailing! Tools Required: Hand or Circular Saw Level...
  • Page 3 Constructing Details for Optional Heavy Duty Floor System Do Not make the foundation larger than 14' x 16'. Check local building codes in your area, the construction may have to change. Depending on your intended use of storage a cement slab may be more appropriate.
  • Page 4 Constructing Details for Floor System continued Stagger Solid Blocking over Center Runners 6. Gather cuttoff 2x6 boards and (1) one 2x6- 16' and cut pieces to fit between the floor joists as blocking. Install these boards over the center 4x4 runners. Stagger the 2x6 blocks to make it easier to nail the block between the joist.
  • Page 5 Step 1 Assemble 16' Back Wall Frame 1. Cut, if necessary, (2) two 2x4-16' (one will be treated) to a length of 192". Position the boards together and indicate with 'X' marks where the wall studs will be located. 16'-0" Top Wall Plate 16'-0"...
  • Page 6 Step 2 Assemble Front Wall Frame Refer to door manufacturers specifications for rough opening size. Adjust measurements accordingly. 1. Cut, if necessary, (2) two 2x4-16' (one will be treated) to a length of 192". Position the boards together and indicate with 'X' marks where the wall studs will be located. Mark an 'S' on bottom plate where the door header supports will be located.
  • Page 7 Step 3 Assemble a 13'-5" Long End Wall Frame If 2x4-14' boards are not available 16' long 2x4 will be substituted. 1. Cut (2) two 2x4-14' (one will be treated) to a length of 13'-5". Position the boards together and indicate with 'X' marks where the wall studs will be located. 13'-5"...
  • Page 8 Step 5 Assemble a 13'-5" Long End Wall Door Frame 1. Cut (2) two 2x4-14' (one will be treated) to a length of 13'-5". Position the boards together and indicate with 'X' marks where the wall studs will be located and an 'S' where the door header support studs will be located.
  • Page 9 Step 6 Install Wall Frames & 2x4 Tie Plates The 13'-5" long wall frames are positioned between 16' front and back walls. 1. Erect wall frames on the floor. IMPORTANT: make sure frames are square and plumb. Secure the frames together at the corners using (4) four 10d sinkers. Brace front and end walls with door opening frames with pre-cut studs.
  • Page 10 Step 7A Install Siding If a siding panel has a damaged edge, install this edge at a corner where it will be covered with corner trim. If installing building on concrete slab, install siding flush with the bottom plate. For wood floor, extend siding 3/4"...
  • Page 11 Step 7B Install Siding continued 6. Install (4) four siding panels on back wall frame. Start at corner with siding flush with end wall siding. 7. Install siding panel 'FL' with the 'cut' edge flush with the siding of the front wall. 8.
  • Page 12 Step 9 Mark 2x8 Joist Headers 1. Mark for joist spacing. The first space will be 11-3/4" measuring from inside the end wall frame. Important: Mark the 'X' mark on the right side of the lines. DETAIL 'A" 91" Long 2x8 Joist Header View of 16' Back wall from Inside 13'-5"...
  • Page 13 Step 10 Install 2x8 Floor Joist on Left End If 2x8-14' boards are not available 16' long 2x8 will be substituted. 1. Cut a 14' long 2x8 to 161" and install to the end of the 2x8 joist headers. Secure with (3) three 10d sinkers.
  • Page 14 Step 11B Install 2x8 Floor Joist on Right End continued 3. Cut a 59" long 2x8 using the cutoff from the previous step. Install the 2x8 to the front wall. Mark lines for joist spacing. Important: Mark the 'X' mark on the right side of the lines. 59"...
  • Page 15 Step 12 Install Loft Flooring Cut (2) two 5/8" x 4'x8' OSB sheets to get (2) two 32" and (2) two 64" long pieces. See Detail 'A'. 2. Cut (1) one 24" x 96" floor panel and (1) one 24" x 64" from a 5/8" x 4'x8' sheet. See Detail 'B'.
  • Page 16 Step 13 Install Trim on End Walls IMPORTANT: Trim Must Be Installed Before Installing Roof Gables! Depending on the pre-cut stud length and if the siding extends below the bottom plate, you may have a space between the top of the siding and the loft floor. Nail 1-1/2" x 48" siding fillers behind trim.
  • Page 17 Step 14A Assemble Gable Frame 1. Cut a 16' long 2x4 to a length of 14'-2". 2. Gather (2) 62-1/8" long and (2) 69-7/8" long 2x4s. Position 62-1/8" boards as shown below. Set the 14'-2" long 2x4 on edge and nearest to 14' end wall. The gable frame when complete will be 2"...
  • Page 18 Step 14B Assemble Gable Frame continued 6. Install pre-cut gable studs inside the gable frame. Use a framing square to make sure the studs are perpendicular to bottom plate. Adjust 2x4s to fit tight against top frame and bottom plate. Use 3-1/2"...
  • Page 19 Step 15 Install Siding on Gable Frame 1. Select the first gable frame assembled and position so the wood gussets are facing down. 2. The bottom 2x4 plate prevents the gable from laying flat on the floor. Locate 65" long 2x4s that have a 1x3 board attached.
  • Page 20 Step 16 Install Gables 2x4-12' Vertical Boards 1. Install (2) two 2x4-12' boards on the end wall to prevent the gable from falling off during installation. Install (2) two more 2x4-12' boards to brace the vertical 2x4 in place. Be- fore installing the vertical 2x4s attach (2) two 2x4 blocks to the back of the 2x4s.
  • Page 21 Step 17 Assemble 2x6 Roof Trusses 1. Lay truss parts inside the temporary blocks used around gable frames. One end of the 69-7/8" long 2x6 boards have a blue mark. Place these ends together at the ridge. Move (2) two blocks to the bottom of the truss legs to keep these from moving.
  • Page 22 Step 19 Install Trusses 1. Starting at the end wall without the door opening indicate with 'X' marks where the trusses will be located. The last space will be wider than the first (21-3/8") space. Mark 2x6 Plate on Front and Back Walls 24"...
  • Page 23 Step 20 Install Front and Back Wall Overhangs 1. Locate (4) four 7-1/4" long 1x4 trim blocks. Install one of the 1x4 trim blocks at each corner of front wall. Install the 1x4 trim blocks under the 2x4 gable plate, flush with the siding on the gable.
  • Page 24 Step 21 Install Roof Sheathing 1. Cut (4) four sheets of 7/16" OSB into the quantity and sizes shown below. Cut (1) one 4x8 Sheet Cut (1) one 4x8 Sheet Cut (2) two 4x8 Sheets 20-3/4" x 48" 20-3/4" x 96" 20-3/4"...
  • Page 25 Step 22 Install Gable Trim 1. Install 70-1/4" long 1x6 trim boards at the top of the gable. Install the trim with the vertical cut located at the peak of the gable. Install 1x6 flush with the top of the roof sheathing. Use 6d galv.
  • Page 26 Step 24 Install Doors Select the door without the pre-drilled hole on long edge. Lay door face down. 2. Install a 4-1/2" x 83" long siding panel as a door stop on right side of door. The door stop should extend 3/4" Door Stop Extends 3/4"...
  • Page 27 Step 25 Install Windows 1. Apply caulking around the window opening before installing the windows. 2. Hold the window in the opening using a few nails with a flat head so the trim can be inserted in the slot. Nails used to install shingles work well. 3.
  • Page 28 Step 29 Install Roofing — Not Supplied in Kit 1. Install metal roof 'drip' edging along the Optional Roof Covering perimeter of the roof. bdl. Roof Shingles 2. Install felt paper and shingles according to pcs. Roof 'drip' Edge-10' the instructions on the wrapper 400 sq.
  • Page 29 Qty. Material Shipped on Pallet Qty. Hardware Breakdown Truss - Top Cords x 69-7/8" lbs. !16d Galvanized Spiral Nails Truss Legs x 62-1/8" lbs. Coated Sinkers Pre-built Door Header x 37-1/2" lbs. Galvanized Nails Pre-built Soffit Overhangs 65" lbs. Galvanized Spiral Nails Gable Top Wall Plates x 69-7/8"...
