The PROSiXTEMP is a wireless temperature sensor intended for use with Honeywell Home controls that support

PROSiX™ series devices. The sensor sends an alarm or trouble signal (depending on zone type selected; ex. Monitor

Zone or 24hr Aux) when the temperature limit is exceeded. The sensor also features a front cover tamper switch.

Default Temperature Limits

Trigger Temperature

Cold

below 45°F (7°C)

Hot

above 95°F (35°C)

MOUNT THE PROSIXTEMP

1. To open the case, firmly slide the front and back housings in opposite directions and pull them apart.

2. Mount sensor as shown, using the double sided tape and screws provided.

3. Secure the front cover with the #2 x 1/4" screw.

After enrolling and before mounting, verify adequate signal strength by conducting a sensor test (see contr oller's

instructions) with the device in its intended mounting location. Adjust the device location and orientation as necessary.

A = Tamper Switch

B = LED

Installation and Setup Guide

PROSiXTEMP

Wireless Temperature Sensor

Need help?

Do you have a question about the PROSiX Series and is the answer not in the manual?

Page 1 Wireless Temperature Sensor Installation and Setup Guide The PROSiXTEMP is a wireless temperature sensor intended for use with Honeywell Home controls that support PROSiX™ series devices. The sensor sends an alarm or trouble signal (depending on zone type selected; ex. Monitor Zone or 24hr Aux) when the temperature limit is exceeded.
Page 2 ENROLL AND SETUP Set the controller in Programming Mode, when prompted: 1. Pull the battery tab to activate the PROSiXTEMP. (Use the tamper switch if the battery tab is removed.) 2. The LED flashes (up to about 20 seconds*) during enrollment. •...
Page 3 LED INDICATIONS Status Rapid Flashes for about 20 seconds, then Power Up – Enrollment ON for 3 seconds Power Up – Device enrolled; Cover Tamper activated. To stop flashes, Slow Flashes clear the tamper condition by reattaching the cover. It also times out after 10 minutes.
Page 4 For the latest warranty information, please go to: www.security.honeywellhome.com/warranty The Honeywell Home Trademark is used under license from Honeywell International Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates. 2 Corporate Center Drive, Suite 100 P.O. Box 9040, Melville, NY 11747 ...
