- Page 1 User Manual #695SQR2 / 695SQRRC Square 2-Head LED Emergency Light with Battery Backup PLEASE READ ENTIRE MANUAL BEFORE USE 08/2024...
-
Page 2: Table Of Contents
The battery in this unit may not be fully charged. After connecting the unit to electricity, the battery will take up to 24 hours to be fully charged. Replacement Lights • Only use lights specified in the exit sign. Using other light types may result in transformer damage or unsafe conditions. WWW.LAVEX.COM... -
Page 3: Installation Instructions
If your building has 277VAC, it is recommended to use that (red wire). If it does not, use the 120VAC (black wire). Both require using the neutral (white wire). 277VAC 120VAC POWER UNIT POWER UNIT SOURCE SOURCE Electrical Diagram 120VAC POWER UNIT SOURCE WWW.LAVEX.COM... - Page 4 BACK PLATE 5. Power Up and Test: Turn on the power to the unit and press the "TEST" button to check Fig. 2 Fig. 3 the light (Fig. 4). J-BOX BACK PLATE BACK PLATE UNIT Fig. 4 TEST UNIT (UNDERSIDE) WWW.LAVEX.COM...
-
Page 5: Remote Lights
LED lights will automatically turn on for a minimum of 90 minutes. TEST 2. Testing: • To test, press the "TEST" switch (Fig. 8). The emergency LED lights will illuminate. • When the switch is released, the lights will turn off. UNIT (UNDERSIDE) WWW.LAVEX.COM...
