Elipta Pole Spot Duo E6471S Technical Data Sheet

.
E6471S - Elipta Pole Spot Duo
Part code
Diffuser
Dimensions (mm)
Cable length (mm)
Construction
Finish
Class
IP rating
Maximum wattage
Lamp base
Lamp included
Dimmable
Input voltage
Net weight (g)
Gross weight (g)
Warranty
Manufactured in accordance with
Origin of manufacture
Installation notes
Ensure mains supply is isolated prior to installation of this
product.
Unscrew the bezel and insert lamp. Apply small amount of grease
to thread and screw back on to the body of the light.
Screw the spike into the light and place the luminaire in desired
location.
Refer to the instruction manual for further guidance.
Note – This product must be installed by a qualified electrician.
E6471S
Clear
103x63x400
1500
Aluminium
Rustic Brown Powder coat
Class III
IP65
LED - 10W
MR16
No
Dependant on lamp
12V DC
1232
1341
2 Years
BS EN 60598
PRC
