E1042T - Elipta Nimbus 45 Bollard Light
Part code
Diffuser
Dimensions (mm)
Cable length (mm)
Construction
Finish
Class
IP rating
Maximum wattage
Lamp base
Lamp included
Dimmable
Input voltage
Net weight (Kg)
Gross weight (Kg)
Warranty
Manufactured in accordance with
Origin of manufacture
Installation notes
Ensure mains supply is isolated prior to installation of this
product.
Remove the top section Nimbus/Cirrus: Unscrew the Allen key
screws in the top cap using the Allen key provided and remove
the louvre assembly where fitted.
Refer to the instruction manual for further guidance.
Note – This product must be installed by a qualified electrician.
E1042T
Opal
450x100
2000
Teak/Stainless steel
Teak/Stainless steel
Class I
IP44
CFL 20W – LED 10W
E27
No
Dependant on lamp
240V 50Hz
2.1
2.6
2 Years
BS EN 60598
PRC
Advertisement
Related Manuals for Elipta Nimbus 45 E1042T
Summary of Contents for Elipta Nimbus 45 E1042T
- Page 1 E1042T - Elipta Nimbus 45 Bollard Light Installation notes Ensure mains supply is isolated prior to installation of this product. Remove the top section Nimbus/Cirrus: Unscrew the Allen key screws in the top cap using the Allen key provided and remove the louvre assembly where fitted.
