LR-BST-REACT INSTALLATION
1. ELECTRICAL WIRING OF LR-BST-REACT
Regardless of the power supply or solar panel, the wiring is the same. The
connection of the power cable is made by a 2-core cable for which there is no
polarity.
• Remove the upper and lower part of the
LR-BST-REACT by rotating them.
• Insert the SIM Card (if it is not present).
1. POWER SUPPLY CONNECTION
1
• Drill the grommet located under the lower part of the LR-BST-REACT.
• Pass the cable through the grommet.
• Connect the cable to the green connector.
(No polarity to respect)
