INSTALLATION MANUAL
VERANDA V920 - RIVA

Advertisement

loading
Need help?

Need help?

Do you have a question about the V920-RIVA and is the answer not in the manual?

Questions and answers

Related Manuals for Verano V920-RIVA

Summary of Contents for Verano V920-RIVA

  • Page 1 INSTALLATION MANUAL VERANDA V920 - RIVA...
  • Page 2 INSTALLATION MANUAL VERANDA V920 - RIVA Index page Exploded view Summary of the parts Required tools Important before installation 1. Mounting the wall profilel 2. Fixing the hinge profile 3. Gutter and Post 4. Footplate 5. Placing the side beams 6.
  • Page 3 INSTALLATION MANUAL VERANDA V920 - RIVA Exploded view Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden. 17 79- 160404(2) 1253-220908EN...
  • Page 4 INSTALLATION MANUAL VERANDA V920 - RIVA Summary of the parts 20. Foot plate 1. Wall profile 21. Coupling post/gutter 2. Hinge profile 22. Coupling (aluminium) post/gutter 3. Intermediate beam profile 23. Leaf catcher 4. Side beam profile 24. Gutter outlet 5.

  • Page 5: Required Tools

    General warning Installing the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of this specific Verano® product. If you cannot install the product yourself, you can always opt for professional installation.
  • Page 6 INSTALLATION MANUAL VERANDA V920 - RIVA Mounting the wall profile ±500 mm 100 mm 200 mm Boorlijn ±500 mm 100 mm 200 mm 10 mm drilling line Boorlijn Drill holes (Ø 5 mm) into the wall profile (1). Distance between holes approx. 50 cm. •...
  • Page 7 INSTALLATION MANUAL VERANDA V920 - RIVA Fixing the hinge profile Place piece of tape to prevent Place piece of tape to prevent Wall Wall Wall Wall the tilt profile from falling out the tilt profile from falling out Compritape Compritape Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden.
  • Page 8 INSTALLATION MANUAL VERANDA V920 - RIVA Gutter and Post 65 mm boorlijn 65 mm 65 mm 65 mm 65 mm boorlijn boorlijn boorlijn boorlijn drilling line 65 mm 65 mm 65 mm 65 mm boorlijn boorlijn boorlijn boorlijn Drainage • First measure the position of the center hole, then drill on the drilling line on the inside of the gutter. •...
  • Page 9 B (x6) x nr. of beams Seal round the edge INSTALLATION MANUAL VERANDA V920 - RIVA Seal round the edge before and after mounting before and after mounting x nr. of beams Seal round the edge B (x6) before and after mounting Footplate B (x6) Seal round the edge...
  • Page 10 INSTALLATION MANUAL VERANDA V920 - RIVA Placing the side beams 14 en 15 14 en 15 14 and 15 14 en 15 14 en 15 Laat de goot iets naar de afvoer aflope Side beam - wall (left and right) Side beam - gutter (left and right) • Place the side beam (4) into the hinge profile (2). •...
  • Page 11 INSTALLATION MANUAL VERANDA V920 - RIVA Positioning and lining up Laat de goot iets naar de afvoer aflopen Laat de goot iets naar de afvoer aflopen Laat de goot iets Allow the gutter to slant naar de afvoer aflopen towards the drainpipe Afvoer Afvoer Afvoer...
  • Page 12 INSTALLATION MANUAL VERANDA V920 - RIVA Laying the intermediate beams Beam - wall Beam - gutter • Place the intermediate beam (3) into the hinge profile (2) • Place the intermediate beam (3) into the gutter (6). between the rubbers. •...
  • Page 13 INSTALLATION MANUAL VERANDA V920 - RIVA How to lay the glass Glas tegen Glas tegen Glas tegen Glas tegen stopper stopper stopper stopper Glass against Glas tegen Glas tegen stopper stopper stopper Speling van ± 5 mm Speling van ± 5 mm Speling van ±...
  • Page 14 INSTALLATION MANUAL VERANDA V920 - RIVA Placing the rubber wall strips Glas ‘klik’ Glas Glas Glas Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden. 17 79- 160404(2) 1253-220908EN...
  • Page 15 INSTALLATION MANUAL VERANDA V920 - RIVA 12. Placing glass roofing panels and rubber strips ‘klik’ ‘klik’ Glas Glas Glas ‘klik’ Glas Glas Glas ‘click’ ‘klik’ Glas Glas Glas Glas Glass Glass Glas Glass Glas Glas Glas Glas Glas Glass Glass Glas Glas Glas Glas Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden.
  • Page 16 INSTALLATION MANUAL VERANDA V920 - RIVA 13. Drain pipe and post click profile The drain pipe is located inside the post. Drain pipe: • Click in the drain pipe (26) and connect it to the drains. • Cut the post click profiles (8) to size. •...
