Summary of Contents for Verano RIVA V920
- Page 1 INSTALLATION MANUAL VERANDA V920 - RIVA...
- Page 2 INSTALLATION MANUAL VERANDA V920 - RIVA Index page Exploded view Summary of the parts Required tools Important before installation 1. Mounting the wall profilel 2. Fixing the tilt profile 3. Gutter and Post 4. Footplate 5. Laying the two end profiles (outer beams) 6.
-
Page 3: Exploded View
INSTALLATION MANUAL VERANDA V920 - RIVA Exploded view Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden. 10399-191126EN 17 79- 160404(2) - Page 4 INSTALLATION MANUAL VERANDA V920 - RIVA Summary of the parts 21. Waste duct nut 1. Wall profile 22. Drain pipe ø 50 mm 2. Tilt profile 23. Drain pipe bracket 3. Beam profile 24. Condensate profile (poly) 4. End frame beam 25.
-
Page 5: Required Tools
General warning Installing the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of this specific Verano® product. If you cannot install the product yourself, you can always opt for professional installation. - Page 6 INSTALLATION MANUAL VERANDA V920 - RIVA Mounting the wall profile 100 mm 100 mm 100 mm 100 mm 10 mm drilling line 100 mm 100 mm 10 mm 10 mm drilling line drilling line Drill 2 holes (Ø 5 mm) into the wall profile (1) for each corresponding rafter. •...
- Page 7 INSTALLATION MANUAL VERANDA V920 - RIVA Fixing the tilt profile Place piece of tape to prevent Place piece of tape to prevent Wall Wall Wall Wall the tilt profile from falling out the tilt profile from falling out Compritape Compritape Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden.
- Page 8 INSTALLATION MANUAL VERANDA V920 - RIVA Gutter and Post 65 mm drilling 65 mm 65 mm 65 mm line drilling drilling drilling 65 mm line 65 mm line line 65 mm drilling 65 mm drilling drilling line line drilling line line Drainage •...
- Page 9 B (x6) x nr. of beams Seal round the edge INSTALLATION MANUAL VERANDA V920 - RIVA Seal round the edge before and after mounting before and after mounting x nr. of beams Seal round the edge B (x6) before and after mounting Footplate B (x6) Seal round the edge...
- Page 10 INSTALLATION MANUAL VERANDA V920 - RIVA Laying the two end profiles (outer beams) Allow the gutter to sla towards the drainpip drain End profile - wall (left and right) End profile - gutter (left and right) • Slide the end profile (3) into the tilt profile (2). • Slide the end profile (3) into the gutter (5). • Screw them together with 1 screw. •...
- Page 11 INSTALLATION MANUAL VERANDA V920 - RIVA Positioning and lining up Allow the gutter to slant Allow the gutter to slant towards the drainpipe towards the drainpipe Allow the gutter to slant towards the drainpipe drainpipe drainpipe drainpipe 90° 90° 90° 90°...
- Page 12 INSTALLATION MANUAL VERANDA V920 - RIVA Laying the beam profiles Beam - wall Beam - gutter • Slide the beam (3) into the tilt profile (2). • Slide the beam (3) into the gutter (5). • Screw it in with 2 screws. • Slide the T connector (14) under the beam profile. •...
- Page 13 INSTALLATION MANUAL VERANDA V920 - RIVA How to lay the glass/polycarbonate panels Stopper Stopper Stopper Stopper Stopper Stopper Slack of ± 5 mm Slack of ± 5 mm Slack of ± 5 mm PLEASE NOTE: Lay the glass panels with the polished Slack of ±...
- Page 14 INSTALLATION MANUAL VERANDA V920 - RIVA Inserting the rubber wall strips Glass/Polycarbonat ‘click’ ‘click’ Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate Subject to misprints, errors and technical modifications. Drukfouten, fouten en technische wijzigingen voorbehouden. 10399-191126EN 17 79- 160404(2)
- Page 15 INSTALLATION MANUAL VERANDA V920 - RIVA 12. Placing glass roofing panels and rubber strips ‘click’ ‘click’ ‘click’ ‘click’ Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate ‘click’ ‘click’ Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate ‘click’ ‘click’ Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate Glass/Polycarbonate Polycarbonate Polycarbonate Glass Glass Polycarbonate Polycarbonate Glass Glass Polycarbonate Polycarbonate Glass Glass Polycarbonate Polycarbonate Glass...
- Page 16 INSTALLATION MANUAL VERANDA V920 - RIVA 13. Drain pipe and post click profile The drain pipe is located inside the post. Drainpipe: • Click in the drain pipe (22) and connect it to the drains. • Click the post click profile (7) into the post. •...
- Page 17 INSTALLATION MANUAL VERANDA V920 - RIVA Processing the polycarbonate roof panels Storage If you storage the polycarbonate roof panels, to plates need to lie on a flat surface, for example pallets. The plates may not be stacked directly on the ground. Avoid direct sunlight and rainwater and cover n polycarbonaatplaat the plates with a white polythene foil.
- Page 18 polycarbonaatplaat en voorkom het slingeren agen en boren. INSTALLATION MANUAL VERANDA V920 - RIVA p een effen ondergrond igen. Daarna onmiddellijk t rechtstreeks dek af met witte olycarbonaatplaten n onder een afdak. rd tegen afschuiving door AntiDust tape (gesloten) (closed) speling dient dan aan de zaag met fijn getand UV-layer on top...
- Page 19 AntiDust tape (gesloten) UV-laag weghalen le speling dient dan aan de UV-laag zit boven n speling van circa 3 mm INSTALLATION MANUAL VERANDA V920 - RIVA – 10 daarom valt condensvocht Condensprofiel khelling tussen 5 – 10 de onderzijde e van de plaat. lakt te worden met gesloten AntiDust tape Condensprofie...
- Page 20 INSTALLATION MANUAL VERANDA V920 - RIVA Registration number TüV The Netherlands QA B.V.: 1231 Verano BV Bedrijfsweg 8 5683 CP Best, Nederland Certificate number: 1231-CPR-1090-1-2400-A-293 EN 1090-1:2009 + A1:2011 Aluminium parts, to be applied in veranda’s according to order: see sticker on the back of this installation manual...
