Summary of Contents for Must LP1800 Series
- Page 1 Rechargeable LiFePO4 Battery LP1800 Series User Manual...
-
Page 2: Warnings And Safety Precautions
2) If the battery is stored for a long time, it must be charged every six months, and the SOC (state of charge)should be no less than 30%. - Page 3 Before installation,switch the grid power off and ensure the battery is in the turned off mode. c. Wiring must be correct, do not mistake the positive and negative cables ,and ensure no short circuit with the external device. d. lt is forbidden to connect the battery and AC power directly.
-
Page 4: Package Contents
INTRODUCTION Switched Lithium lron Phosphate Battery is a new energy storage product which can provide reliable power support for various equipment and systems. Switched Lithium lron phosphate battery has a built-in BMS(Battery Management system), whichcan manage and monitor battery voltage, current, temperature and other information. HIGHLIGHTS High-cycle Life Longer service Life... -
Page 5: Specifications
SPECIFICATIONS 25.6V 51.2V 21.6-29.2V 43.2-58.4V 29.2V 58.4V 0.5C 50A/100A/150A/200A 0.5C 50A/100A/150A/200A CE/UN38.3/MSDS... -
Page 6: Identifying Parts
IDENTIFYING PARTS 11 12 13 1.RST 8.WiFi antenna 9.Power switch 2.DRY port 3.RS485 port 10.BAT+ 4.CAN port 11.RUN Indicator 5.RS232 port 12.ALM Indicator 6.Parallel port 13.SOC Indicator 7.BAT- Short description of identifying parts(Detailed description found in settings and descriptions ). 1.RST: When the BMS is dormant, press the button (3~6S) to release, the protection plate is activated, and the LED indicator light starts from "RUN"... - Page 7 SETTINGS AND DESCRIPTIONS (Continued) RS458 and CAN: For an lnverter and a Secondary Battery: RS485 Communication port Definition: Port Definition Port Definition CANH RS485 Communication Port Definition CANL...
- Page 8 SETTINGS AND DESCRIPTIONS (Continued) Battery pack parallel function: a.Use a parallel communication cable to connect the parallel output interface of the host machine to the interface of the first slave machine, and then connect the paralleloutput interface of the first slave machine to the parallel input interface of thesecond slave machine.
- Page 9 SETTINGS AND DESCRIPTIONS (Continued) RS232(Adjusting): RS232 connecting with upper computer to let manufacturer or professional engineer to process adjusting service RS232 Port Port RS232 Communication port Difinition...
- Page 10 SETTINGS AND DESCRIPTIONS (Continued) BMS basic function Protection and alarm Management and monitor Charge/Discharge End Cells Balance Intelligent Charge Model Charge Over Voltage Charge/Discharge Current Limit Discharge Under Voltage Capacity Retention Calculate Charge/Discharge Over Current Administrator Monitor High/Low Temperature(cell/BMS) Operation Record Short Circuit Power Cable Reverse Soft start of inverter...
- Page 11 SAFE HANDLING GUIDE OF LITHIUM BATTERIES Inverter PV ARRAY Public Grid Local Load LiFePO 4 Lithium Battery Battery Module...
- Page 12 SAFE HANDLING GUIDE OF LITHIUM BATTERIES (Continued) Tools: Note: Use appropriately insulated tools to prevent accidental electric shock or short circuits. If insulated tools are unavailable, cover the entire exposed metal surfaces of the available tools, except their tips, with electrical tape. Safety Gear: Safety Gear: It is recommended to wear safety gear, insulated gloves, safety Goggles and safety shoes...
- Page 13 Package ltems INSTRUCTIONS FORUSE Package Items: Unpack and check the packing list. 1.Battery Module Package; a.Single Battery Pack; 2 x Communication cable 4 x Open Terminal 1 x Instruction Manual b. can be customized per requirement: Battery cable,communication cable,parallel cable. 2.
- Page 14 INSTALLATION AND OPERATION (Continued) lf the ambient temperature outside is in the operating range, the battery pack will stop operating to protect itself. The optimal temperature range for the battery pack is 15°C to 35℃.Frequent exposure to harsh temperatures may deteriorate the performance and life of the battery pack.
- Page 15 INSTALLATION AND OPERATION (Continued) Installation of battery pack Put battery modules into cabinet and connect the cables: Dial Code 1 Dial Code 2 Dial Code 3 (1) Put the battery into the cabinet (2) Drive the 4 pcs screws (3) Connect the cables between battery modules (4) Connect the cables to inverter...
- Page 16 INSTALLATION AND OPERATION (Continued) CAUTION 1. A suitable breaker between the battery system and inverter is required. 2.The complete installation and operation of the system must follow the local electric standard. Power On: Double check all the power and communication cables.
- Page 17 INSTALLATION AND OPERATION (Continued) 3. Switch the red switch on the primary battery to turn the power on; all the battery LEDs will be on one by one from the primary battery. COMMUNICATION Dial Code 1 Communication Parallel Cables Dial Code 2 NEGATIVE —...
-
Page 18: Emergency Situations
Cut off all power switches on the inverter. 3. Damaged Batteries: Damaged batteries are dangerous and must be handled with the utmost care.They are not for use.And may pose a danger to people or property. lf the battery pack seems damaged, pack it in its original container and return it to an authorised dealer. -
Page 19: Battery Maintenance
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF ELECTRICAL AND MECHANICAL COMPONENTS. At the end of its working life, the product must not be disposed of as urban waste. lt must be taken to a particular local authority differentiated waste collection centre or a dealer providing this service.Disposing a household appliance separately avoids possible negative environmental...
