- Page 1 Operating Instructions Chip Extraction Unit SAA 2001 SAA 2003 SAA 3001 SAA 3003 SAA 3001 SAA 2001...
-
Page 2: Table Of Contents
Subject to technical changes and errors. 12 Spare parts ........... 15 12.1 Spare parts orders .......... 15 12.2 Spare parts drawings........16 13 Wiring diagrams ........20 14 EC - Declaration of Conformity ... 21 SAA Series | Version 1.11... -
Page 3: Introduction
Safety instructions in this operation manual have been Dr.-Robert-Pfleger-Str. 26 highlighted with symbols. Safety instructions are indica- D-96103 Hallstadt / Germany ted by signal terms that express the degree of risk involved. Repair service: Fax: 0951 96555-111 E-Mail: service@stuermer-maschinen.de Internet: www.holzstar.de SAA Series | Version 1.11... -
Page 4: Operator Responsibility
In this process, the following shall apply in particular: SAA Series | Version 1.11... -
Page 5: Personal Protective Equipment
Protective glasses protect the eyes against projected parts and splashes of liquid. As soon as the signs are not clearly visible and compre- hensible at first glance, the machine must be stopped until new signs have been attached. SAA Series | Version 1.11... -
Page 6: General Safety Aspects
11. Wood dust is explosive and can be harmful to health. In particular, tropical woods and hardwoods such as beech and oak are classified as carcinogenic. 12. Work with reason and with concentration. Do not use the chip extraction unit if you are not concentrated. SAA Series | Version 1.11... -
Page 7: Safety Aspects In Dealing With Application Of Tools
- To avoid contact with the blower wheel, unused exhaust connections must always be covered. - While working outside good footwear is recommen- ded. - Keep the working area free of rubbish. - All protective devices must be mounted immediately after servicing. SAA Series | Version 1.11... -
Page 8: Intended Use
Misuse of the chip extraction unit can lead to dangerous situations. Stürmer Maschinen GmbH accepts no liability for design and technical modifications to the chip extraction unit.. Claims of any kind for damage due to improper use are excluded. SAA Series | Version 1.11... -
Page 9: Type Plate
Observe the accident prevention regulations issued by your Employers Liability Insurance Association or other competent supervisory authority, responsible for your company. Fasten the loads properly. SAA Series | Version 1.11... -
Page 10: Machine Description
Support rods Bag clamp - The installation location must have good illumina- Intake duct Filter tion. Filter (Inlet) 6.2 Scope of supply 1. Filter bag 2. Chip bag 3. Operating instructions SAA Series | Version 1.11... -
Page 11: Set Up The Chip Extraction Unit
Step 5: Inspect regularly the chip bag and empty it unit if full is. Step 6: Before operating the on / off switch, make sure that the filter bag is good fixed. Fig. 4: Connection machine and exhaust system SAA Series | Version 1.11... -
Page 12: Installation Of The Chip Extraction Unit
Step 2: Attach the Y-piece. Step 3: Attach the filter bag at the top with the bag clamp. Step 4: Fasten the chip bag at the bottom with the clamp. Fig. 7: Installation of the fan/motor assembly (2) SAA Series | Version 1.11... -
Page 13: Maintenance And Service
Damaged safety devices, machine parts and coun- ters must be exchanged in accordance with the requi- rements by an approved professional workshop. SAA Series | Version 1.11... -
Page 14: Malfunctions, Their Potential Causes And Remedies
If necessary, ask for sized with Ø larger the product-specific data sheets. than100 mm. 4. The extraction 4. Set the Extrac- line is too long tion Unit near on the wood- working machine SAA Series | Version 1.11... -
Page 15: Disposal By Municipal Collection Point
Item number of your machine: the event of a use of unauthorised spare parts. 5922201 Chip Extraction Unit SAA 2001 5922203 Chip Extraction Unit SAA 2003 5922301 Chip Extraction Unit SAA 3001 Chip Extraction Unit SAA 3003 5922303 SAA Series | Version 1.11... -
Page 16: Spare Parts Drawings
The following drawings are intended to help identify the necessary spare parts. To order, please send a copy of the part drawing with the marked components to your dealer. Spare parts drawing SAA 2001/ SAA 2003 Fig. 12: Spare parts drawing SAA 2001/ SAA 2003 SAA Series | Version 1.11... - Page 17 Spring washer Switch box Hex screw* M8x16 Cross head tapping screw Cross head screw* M4x60 Cross head screw* M6x10 Cable Inlet Bolt Inlet cover Hexagon socket screw* M6x20 * Standard part, available from specialist retailers SAA Series | Version 1.11...
- Page 18 Spare parts Spare parts drawing SAA 3001/ SAA 3003 Fig. 13: Spare parts drawing SAA 3001/ SAA 3003 SAA Series | Version 1.11...
- Page 19 Inlet Collector right Screw Washer Hex screw Upper bag support Unterlegscheibe Filter bag Turbo fan Packing Collector Inlet Washer Motor base Switch Hex screw Cable Hex screw Bolt Bag clamp Motor Switch box Head screw SAA Series | Version 1.11...
-
Page 20: Wiring Diagrams
Wiring diagrams 13 Wiring diagrams Wiring diagram SAA 2001/ 230 Wiring diagram SAA 2003 / 400 Wiring diagram SAA 3001 / 230 Wiring diagram SAA 3003 / 400 Fig. 14: Wiring diagrams SAA Series | Version 1.11... -
Page 21: Ec - Declaration Of Conformity
DIN EN 60204-1:2019-06 Safety of machinery - Electrical equipment of machines - Part 1: General requirements Responsible for documentation: Kilian Stürmer, Stürmer Maschinen GmbH, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 09.11.2020 ______________________ Kilian Stürmer CEO, Director SAA Series | Version 1.11... - Page 22 www.holzstar.de...
