MODEL REFRIGERANT R290 RPC26MCWF Portable Room Air Conditioner Operation & Installation Manual...
Page 2
Before proceeding with the operation of your new Rinnai Portable Room Air Conditioner, please read this manual thoroughly and gain a full understanding of the requirements, features and operation of your new appliance.
The flexible cord and plug must not be modified. If the cord or plug are damaged, they must be replaced by Rinnai or a Rinnai appointed service agent. DO NOT cover or place articles on or against any parts of this appliance, to avoid overheating.
Page 5
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances.
Page 6
If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO fire extinguisher adjacent to the charging area. Rinnai Portable Room AC OIM...
Page 7
Replacement parts shall be in accordance with the manufacturer’s specifications. NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment. Intrinsically safe components do not have to be isolated prior to working on them. Rinnai Portable Room AC OIM...
Page 8
Extreme care shall be taken not to overfill the refrigeration system. Prior to recharging the system it shall be pressure tested with OFN. The system shall be leak tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site. Rinnai Portable Room AC OIM...
Page 9
The evacuation process shall be carried out prior to returning the compressor to the suppliers. Only electric heating to the compressor body shall be employed to accelerate this process. When oil is drained from a system, it shall be carried out safely. Rinnai Portable Room AC OIM...
Elevate the air conditioner if necessary. • Make sure the air intake and outlet grills are unobstructed. • Clean the filters at least once every two weeks. SPECIFICATIONS MODEL RPC26MCWF Function Cooling Only Control Remote and Wi-Fi via App Power Supply 220V-240V~ / 50Hz...
(16°C to 32°C). When the room temperature is higher than set temperature, Cool mode; When the room temperature is lower than set temperature, Fan mode. Press the ON/OFF button (1) to stop operation. Inthismode,youcannotadjustthefanspeeds. NOTE Rinnai Portable Room AC OIM...
8 hours 1°C has passed the appliance will resume normal operation. 1°C Set temp Sleep mode is not available in FAN only and Sleep mode 8 hours DRY mode NOTE C°C = Set cooling temperature Rinnai Portable Room AC OIM...
NOTE Onlyonemodeofoperationisavailableatanytime. NOTE WI-FI OPERATION Refer to the Wireless Operation Manual for App connectivity and operation. A copy of the manual may be downloaded from the Rinnai Website: https://www.rinnai.com.au/air-conditioning/portable-air-conditioners/ or by scanning this QR code: Rinnai Portable Room AC OIM...
Cool Button Dry (Dehumidifying) Button 10. This button has no function on this model. BASIC OPERATION REMOTE CONTROLLER The Rinnai Remote Controller allows for convenient operation of the appliance within a 8 metre range. Aconfirmationbeepsoundstoconfirmthatasuccessfulcontrollerinputhasbeenreceivedby theappliance. NOTE BUTTON DESCRIPTIONS & OPERATION "ON/OFF"...
Page 16
Do not drop or throw the remote control. Do not leave the remote control in the sun or near heating devices. Only use a single CR2032/3V button cell. Ensure the battery cover is securely in place. ThediagramshownoftheRemoteControllerisanexampleonly.Theimagecontainsalmostall ofthefunctionbuttons. NOTE RemoteControllersmaybeslightlydifferentfromillustrateddiagramdependingonwhichmodel purchased. Rinnai Portable Room AC OIM...
To re-attach the Lower Air Intake Grill (10) ensure that all the tabs are properly seated and that the grill is securely clipped back into place and that the securing screw is replaced. The power may now be reconnected. Failuretocleanthefiltersregularlycancauseexcessivecondensationtoformandreducethe appliancesefficiency. NOTE Ifyouneedreplacementfilters,pleasecontactRinnai. Rinnai Portable Room AC OIM...
WHEN TO CALL FOR SERVICE SYMPTOM CAUSE There is a burning smell and a Turn off the air conditioner, and contact Rinnai. strange sound coming from the unit. When operated if a circuit breaker (safety, ground) is thrown or a fuse is blown.
Place the Duct to Unit Adaptor (17) over the Exhaust Outlet (5), push it downwards to ensure it engages the Exhaust Outlet tabs. Screw one end of the Exhaust Duct (16) into the Duct to Unit Adaptor (17). On the other end of the Exhaust Duct (16) fix the Window Exhaust Duct Adaptor (15). Rinnai Portable Room AC OIM...
Slide lock nut and bolt Insert window Foam seal exhaust duct adaptor here Itisrecommendedtoplacealengthoffoamdraftsealingstripalongthetopandbottomedgesof thekitortheinsidethewindowopeningtoformaseal. NOTE Connect the Window Exhaust Duct Adaptor (15) to the Adjustable Slider Kit (14). Rinnai Portable Room AC OIM...
Option 2 - Existing Waste Outlet: with drain outlets (7) and (8) plugged, fit the condensate drain hose (18) to drain outlet (12) and drain the condensate into a drain tray or waste outlet. ThepointtowhichthecondensateistobedrainedMUST BElowerthanthedrainageoutletpoint. Whenusingadraintrayoption,ensurethatthecapacityofthetrayisgreaterthanthatofthe NOTE condensatebeingproduced. Rinnai Portable Room AC OIM...
1 “Authorised Service Representative” means an independent service contractor authorised by Rinnai or Rinnai service personnel. 2 “Rinnai” means Rinnai Australia Pty Ltd (ABN 74 005 138 769) and any related company. “Certificate(s) of Compliance” means certificate(s) issued by licensed personnel (including plumbers, refrigeration mechanics, electricians or other relevant tradespeople) to certify that any prescribed works comply with applicable regulatory requirements.
Page 23
Normal Business Hours by an Authorised Service Representative. Repair by persons other than an Authorised Service Representatives may void the Warranty. 2.4 Alternatively to clause 2.3 above, Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product.
Page 24
7 “Purchaser’s Responsibilities” on page 25; c) notifies Rinnai within 30 days of a defect occurring or, in the case of a latent defect, becoming apparent, that a claim is being made under this Warranty; and d) provides, in support of the claim made under this Warranty, a Proof of Purchase.
Page 25
Rinnai to enquire about alternative arrangements. If you wish to make a warranty claim in respect of any fixed Product, please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product.
Help Line. innai recommends that this appliance be serviced every 2 years. With our policy of continuous improvement, we reserve the right to change, or discontinue at any time, specifications or designs without notice. Rinnai Portable Room AC RPC26MCWF OIM Issue 1 - August 2024...
