- Page 1 INSTALLATION MANUAL AWNING V282 - OVIEDO...
-
Page 2: Table Of Contents
INSTALLATION MANUAL AWNING V282 - OVIEDO Index Page Content package Necessary tools Specifications Important before mounting Mounting wall supports 1.1 Marking the holes 1.2 Drilling the holes 1.3 Drilling the hole for control Mounting the awning 2.1 Placing the awning 2.2 Securing the awning Electrical wall control 3.1 Connecting the wall control 3.2 Standard factory adjustment... -
Page 3: Content Package
INSTALLATION MANUAL AWNING V282 - OVIEDO Content 1. Awning 2. Side caps 2x 3. Wall supports 2x 4. Center support(s) (optional) 5. Locking bolts 2x, provided with nuts 6. Control a. Electrical: Switch and plug b. Remote controlled: Remote control and plug (optional) Necessary tools • Drilling machine In case of electrical control: • Support drill 10/14 mm • Nippers • Crosshead screwdriver •... -
Page 4: Specifications
INSTALLATION MANUAL AWNING V282 - OVIEDO Specifications V285 - Oviedo Sizes in mm Wall mounting 27.5 27.5 Front view wall support Awning section Ceiling mounting Top view ceiling support Awning section Minimum width per fabric projection Projection [mm] Minimum awning width [mm] 2000 2350 2500... -
Page 5: Important Before Mounting
INSTALLATION MANUAL AWNING V282 - OVIEDO Important before mounting General warning Mounting the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the mounting of this specific Verano® product. If you cannot mount the product yourself, you can always opt for professional mounting. The mounting team of Verano® is pleased to help you. Be careful for damages Don’t use a knife or any other sharp object when opening the packing. This may cause damage to the content of the pac- kage. Put the content of the package on a soft surface. Be careful when drilling, falling drill cuttings can cause damages. Check if the window frame or façade is flat and smooth. Check the mounting height Make sure that you have enough mounting height on your façade to place the awning. Above the wall support (mounting support) have to be 5 rows of stones to prevent to much pressure on the façade. This is not often the case with a house- extension. It is recommended to drill the mounting hole in the fifth stone (minimum) measured from the top. Wall strips When there are fewer than five rows of stones above the wall support, wall strips have to be used. These strips divide the forces over a bigger wall surface when the walls are to weak. View page 11 for extensive instructions. Attention! Make sure there is no mounting point in the soldier course. These are often half stones. min. 30 cm soldier course rollaag Sliding door When the awning is fully open, it hangs down under the angle. Therefore we advise to keep at least 30 centimeters... -
Page 6: Mounting Wall Supports
INSTALLATION MANUAL AWNING V282 - OVIEDO Mounting wall supports 1.1 Marking the holes Mark the holes for the wall supports (A) and potential for the intermediate support (B) on the wall. These holes need to be aligned level, horizontal and vertical, according to the sizes X and Y in figure 1.1. Attention! Size X is the width of the awning without side covers. Make sure that there are at least two holes in the middle of a stone. View figure 1.2. If necessary, use an alignment string. X = width of the awning without side covers. Y = height of the window frame plus a minimum of 30 cm. A = wall support, always use four bolts. B = c enter support, with an awning bigger than 550 cm. Align the center support at the bottom! fig. -
Page 7: Mounting The Awning
INSTALLATION MANUAL AWNING V282 - OVIEDO Mounting the awning 2.1 Placing the awning 1. Hang the awning in the wall supports (A). View figure 2.1 and 2.2. 2. Make sure that the awnings is mounted level. If not, correct this. 3. Slide the adjustable part (B2) of the center support to its place in the mounting plate (B1). Make sure that de adjustable part falls in the back of the slot of the awning. View figure 2.3. 4. Install the adjustable part (B2) with adjusting bolt #10 and adjusting bolt #13. (optional) fig. 2.1 Hanging the awning fig. 2.2 Detail wall support A fig. 2.3 Detail wall support B Subject to misprints, errors and technical modifications. -
Page 8: Securing The Awning
INSTALLATION MANUAL AWNING V282 - OVIEDO 2.2 Securing the awning 1. Slide the locking block over the wall support (A). View figure 2.4. 2. Secure the awning by screwing the locking block with the included screw. 3. Repeat this on the other side of the awning. Attention! The awning may never be opened before the locking blocks are applied. fig. 2.4 Detail locking block Subject to misprints, errors and technical modifications. 268076 74-240411EN... -
Page 9: Electrical Wall Control
INSTALLATION MANUAL AWNING V282 - OVIEDO Electrical wall control 3.1 Connecting the wall control Follow the steps below: 1. Check the position of the motor (left or right) seen from the outside. 2. When you have the control inside, first feed a cable through the hole in the wall that you drilled earlier. 3. Connect the four-conductor cable of the motor and the three-conductor cable with plug according to the scheme below. 4. Insert the plug in the power socket. 5. The awning is now connected. Before you continue the installation, check if the awning correctly unrolls itself. fig. 3.1 Motor left (seen from the outside) fig. -
Page 10: Remote Control
INSTALLATION MANUAL AWNING V282 - OVIEDO Remote control 4.1 Connecting the remote control Follow the steps below: 1. If you have the power inside, please first enter the cable through the hole you drilled earlier. 2. Mount the plug regarding to the following color scheme: • Brown 220V • Blue 220V • Yellow/Green Grounding • Black Don’t connect • White Don’t connect • Orange Don’t connect 3. Insert the plug in the power socket. 4. -
Page 11: Mounting The Solar Panel With Imove® Solar Operation
afmeting zonnepaneel INSTALLATION MANUAL AWNING V282 - OVIEDO 1085x60x10mm Mounting the solar panel with iMove® Solar operation 5.1 Positioning the solar panel Position the solar panel on top of or next to the awning and make sure the solar panel can get enough light. If there is an overhang or overhanging gutter, make sure the panel is not in the shade. afmeting zonnepaneel Size solar panel 1085x60x10mm fig. 5.1 Positioning the solar panel 5.2 Mounting the solar panel Follow the steps below: 1. -
Page 12: Mounting The Solar Panel
INSTALLATION MANUAL AWNING V282 - OVIEDO 2. Connect the solar panel to the motor. If necessary, use an extension cable for the solar panel. fig. 5.3 Connecting the solar panel afmeting zonnepaneel 1085x60x10mm Note! Only the motor is solar powered. The lighting and motor have different hand transmitters. Subject to misprints, errors and technical modifications. 268076 74-240411EN... -
Page 13: Incline Angle
INSTALLATION MANUAL AWNING V282 - OVIEDO Incline angle 6.1 Standard factory adjustment The height of the front bar is standard set between 1,80 meter and 1,90 meter at a mounting height of 2,70 meter. 6.2 Adjusting the incline angle When you want to adjust the awning other than the factory adjustment, follow the steps below: 1. Role the awning out by using the wall switch or remote control. 2. The slope of the awning can be determined with the help of an allen bolt which can be found on the left and right beneath the mounting bracket. View figure 6.1. Lift the front bar while loosening, so that the allen moves easily. 3. Release the front bar to determine if the angle is to your liking. 4. Repeat this, when necessary, on the other side of the awning and check if the front bar is still hanging straight. fig. -
Page 14: Wall Strips
INSTALLATION MANUAL AWNING V282 - OVIEDO Wall strips Wall strips must be used at a situation with less than five rows of stones above the mounting place. The strips divide the power over a bigger wall surface, so that the wall can carry more weight. View figure 8.1 LEFT RIGHT LINKS RECHTS fig. 8.1 Using the wall strips 8.1 Mounting the wall strips Follow the steps below when mounting the wall strips (view figure 8.1 and 8.2): 1. Mount the wall brackets on the wall strips as high as possible. In this mounting, it is sufficient to use two bolts because the wall strip carries the weight of the awning. Attention! The left wall strip is turned 180 degrees pertaining to the right wall strip. fig. 8.2 Mounting the wall strip right Subject to misprints, errors and technical modifications. -
Page 15: Mounting The Wall Strip On An Centre Support
INSTALLATION MANUAL AWNING V282 - OVIEDO 2. Measure the strips carefully on the wall. Keep the placing of the wall brackets on the strips and width size X in figure 1.1 in mind. The wall strips need to be levelled horizontal and vertical. The mounting holes need to be in the middle of the stone. If desired use a align cord. Mount the wall strips tight to the wall. 3. Mount the fixation block beneath the wall strip. This block is needed for fixing the cover. 4. Place the cover on the lower part of the wall strip. You first need to cut this to the right size. 5. Mount the cover on the fixation block in the bottom of the wall strip. 6. The mounting of the wall brackets on the wall strips is ready. You can now continue with the placing of the awning. 8.2 Mounting the wall strip on an centre support In a situation with one or more centre supports, the wall strip needs to be mounted first. Mind open patio doors. When preferred, you can cut the wall strip custom. Subject to misprints, errors and technical modifications. 268076 74-240411EN... -
Page 16: Ceiling Mounting
INSTALLATION MANUAL AWNING V282 - OVIEDO Ceiling mounting 9.1 Mounting the ceiling brackets The awning can also be mounted to the ceiling using ceiling brackets (view figure 9.1). 1. Mount the mounting brackets to the ceiling brackets. 2. Measure the ceiling brackets on the ceiling. Please mind the placing of the wall brackets to the ceiling brackets and width size X in figure 1.1. 3. Mount the ceiling brackets including the mounting brackets to the sealing. Always use four bolts! 4. Follow the instructions from page four in this instruction manual. M10x70 fig. -
Page 17: User Information
INSTALLATION MANUAL AWNING V282 - OVIEDO User information A high quality cloth is integrated into your chosen screen. In view of optimal quality we have chosen a high technology production process in which every step of the production is strictly selected. By way of automation, permanent checks, laboratory tests and finely detailed after-care, nothing is left to chance.
