- Page 1 INSTALLATION MANUAL AWNING V210 - RHODOS...
-
Page 2: Table Of Contents
INSTALLATION MANUAL AWNING V210 - RHODOS Inhoudsopgave page Content package Necessary tools Specifications Important before mounting Installation on the wall 1.1 Marking the holes 1.2 Drilling the holes 1.3 Drilling the control hole 1.4 Installation using wall strips Electrical wall control 2.1 Connecting the wall control 2.2 Standard factory setting Remote control 3.1 Connecting the remote control... -
Page 3: Content Package
INSTALLATION MANUAL AWNING V210 - RHODOS Content package 1. Sun awning * 2. Control a. Manual control: crank handle b. Electrical: switch + plug c. Remote controlled: remote control + plug * The displayed awning is a manual control version. Necessary tools • Drilling machine In case of electrical control: •... -
Page 4: Specifications
INSTALLATION MANUAL AWNING V210 - RHODOS Specifications Sizes in mm Wall installation Front view wall support left Awning section Minimal width per fabric projection Projection [mm] Minimal awning width [mm] 1500 1830 2000 2400 2500 2970 2500 Equilateral 2790 3000 3620 3000 Equilateral 3240... -
Page 5: Important Before Mounting
INSTALLATION MANUAL AWNING V210 - RHODOS Important before mounting General warning Mounting the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the mounting of this specific Verano® product. If you cannot mount the product yourself, you can always opt for professional mounting. The mounting team of Verano® is pleased to help you. -
Page 6: Installation On The Wall
INSTALLATION MANUAL AWNING V210 - RHODOS Installation on the wall 1.1 Marking the holes For the installation of the awning, the two wall supports (A) need to be level horizontal and vertical. See figure 1.1 and 1.2. The wall supports need to be installed in the same line on the wall. If the wall supports are not in the same line (with an uneven position of the arms as a result) the awning will not function correctly. -
Page 7: Installation Using Wall Strips
INSTALLATION MANUAL AWNING V210 - RHODOS 1.4 Installation using wall strips If there are less than five rows of stones above the installation location, wall strips need to be used. The strips divide the power over a larger wall surface so that the wall can carry more weight. See figure 1.3. LEFT RIGHT LINKS RECHTS Drill slot boorsleuf fig. 1.3 Using wall strips Follow the steps below to install the wall strips (see figure 1.3 and 1.4): 1. Mark the positon of the wall strips on the wall according to size X and Y in figure 1.2. The wall strips need to be, both horizontal and vertical, levelled. Make sure that the installation holes are in the middle of the stone. If necessary, use an alignment string. -
Page 8: Electrical Wall Control
INSTALLATION MANUAL AWNING V210 - RHODOS Electrical wall control 2.1 Connecting the wall control 1. Check the position of the motor (left or right), seen from the outside! 2. If you have inside control, first guide the cable through the hole in the wall you drilled before. 3. Connect the four-wired cord of the motor and the three-wired cored with plug following the scheme below. 4. Put the plug in the power point. 5. -
Page 9: Remote Control
INSTALLATION MANUAL AWNING V210 - RHODOS Remote control 3.1 Connecting the remote control 1. If the power point is located on the inside, first guide the wire through the hole in the wall you drilled before. 2. Install the plug according to the color scheme below: • Brown 220V power supply • Blue 220V power supply • Yellow/green grounding • Black (do not connect) • White (do not connect) •... -
Page 10: Inclination
INSTALLATION MANUAL AWNING V210 - RHODOS Inclination 4.1 Standard factory setting The walk-through height of the front bar is standardly set between 1,80 and 1,90 meter at an installation height of 2,70 meter. 4.2 Setting the inclination If you want to set the awning different from the standard factory setting, follow the steps below: 1. Roll the awning out. The arm connections are located left and right on the awning. 2. -
Page 11: Front Bar
INSTALLATION MANUAL AWNING V210 - RHODOS Front bar 5.1 Setting the front bar The right position can be achieved if the front bar connects perfectly to the top- and bottom cap if the awning is closed. See figure 5.1. fig. 5.1 Position front bar Follow the steps below if the opening between the cap and the front bar is to large: 1. -
Page 12: Valance
INSTALLATION MANUAL AWNING V210 - RHODOS Valance 6.1 Installation of the valance Follow the steps below for the installation of the valance. See figure 6.1. 1. Take the cover of the front bar on one side. The fabric tendon is locked in the front bar. 2. Slide the fabric tendon in the valance at the side where the fabric is open. 3. Slide the valance carefully in the intended recess. -
Page 13: User Information
INSTALLATION MANUAL AWNING V210 - RHODOS User information A high quality cloth is integrated into your chosen screen. In view of optimal quality we have chosen a high technology production process in which every step of the production is strictly selected. By way of automation, permanent checks, laboratory tests and finely detailed after-care, nothing is left to chance.
