ENGLISH
1
SUB ORIGINAL OPERATING
INSTRUCTIONS
E-BIKE, EPAC, PEDELEC, S-PEDELEC
EN 15194
1 St Edition
SUB MANUAL AUF DEUTSCH
SUB MANUAL IN ENGLISH
SUB MODE D'EMPLOI
www.vello.bike/submanual
www.en.vello.bike/submanual
www.fr.vello.bike/submanuel
IMPORTANT!
Please read these operating instructions carefully before use and keep them in a safe place.
Do not dismantle any parts without consulting a qualified bicycle mechanic! Before you ride your bike for the first time,
you must have it checked by a qualified bicycle mechanic! For more information, videos and explanations,
visit www.en.vello.bike/support.
www.en.vello.bike/reg
Extend the warranty for the frame and fork of your VELLO bike from 2 to 5 years at
(more information on page 26).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vello SUB

Summary of Contents for Vello SUB

  • Page 1 For more information, videos and explanations, visit www.en.vello.bike/support. www.en.vello.bike/reg Extend the warranty for the frame and fork of your VELLO bike from 2 to 5 years at (more information on page 26).
  • Page 2 Before the ride Components and equipment Size adjustment Adjusting the seat height Permissible total weight Instructions for passenger transport Guide to loading the VELLO SUB with the appropriate accessories Electric drive MIK HD system Supernova lighting The frame Brake system...
  • Page 3 You will also find information on the correct maintenance and care of your VELLO SUB in these operating instructions. Make sure that your VELLO SUB has been checked by a specialised bicycle workshop before using it for the first time.

  • Page 4: General Information

    Please also carefully read the enclosed operating instructions for the Bosch Cargo Line drive. If you have any questions, please contact your VELLO dealer, the bike workshop of your choice or the VELLO team. We will be happy to help you!
  • Page 5 The VELLO SUB was developed for use on roads and paved paths. VELLO bikes are not designed for tricks, cross-country riding, extreme sports, climbing stairs, jumps, wheelies, or similar activities. Please use your VELLO SUB only as intended to avoid damage, accidents, or the cancellation of the warranty. Operating, maintenance and servicing conditions (as described in this user manual) are part of the intended use.

  • Page 6: Before The Ride

    Do not leave children unattended on the carrier: Never leave children unattended on the SUB, even if it is on the centre stand. Fidgeting children can affect the balance of the bike and a fall could result in serious injury.
  • Page 7 Supernova rear light with brake light function Magura brakes with strong grip The product image shown above is a sample image. Your VELLO SUB may differ in equipment and colour from the model shown above. The model shown is a VELLO SUB (CroMo frame) with hydraulic disc brakes, belt drive and Enviolo gears.

  • Page 8: Size Adjustment

    Remove your VELLO SUB from the packaging. Place the VELLO SUB on the floor. TIP: Place a blanket under the VELLO SUB to avoid damaging your floor and the VELLO SUB. Now carefully remove all packing materials and protective packaging.
  • Page 9 Stem The height and angle of the handlebars with the adjustable stem can be adjusted. Open the stem: Press down the safety button on the left-hand side of the lever (Fig. 3. 1 ). Now the lever can be raised (Fig. 3.2) and the angle of the stem adjusted (Fig. 3.3). To fix the angle, the lever must be pressed down again.

  • Page 10: Adjusting The Seat Height

    ENGLISH VERSION ADJUSTING THE SEAT HEIGHT To find the optimum seat height on your VELLO SUB, you can proceed as follows: Sit comfortably on the saddle. Position your heel on the pedal and push it down until it has reached its lowest point.
  • Page 11 PERMITTED TOTAL WEIGHT The permissible total weight of the VELLO SUB is 210kg. This maximum permissible weight may be further restricted by the component manufacturer’s recommendations for use. The permissible total weight is made up of the following: Weight of the SUB 24,9kg -28,9kg...
  • Page 12 Check assembly: Ensure that all accessories are correctly installed and securely fastened. Correct use of installed accessories: The Kids Railing, Footboards, Seat Pad, Comfy Passenger Set and SUB Cocoon are designed for seated use only. Standing on the accessories is unsafe and can cause permanent damage to the frame and accessories.
  • Page 13 (accessories are available separately at www.en.vello.bike) The VELLO SUB is a longtail e-cargo bike with a total load capacity of up to 210 kg, which is ideal for the environmentally friendly transport of goods and people in urban areas. VELLO offers accessories specially tailored to the SUB to fulfil as many requirements as possible.

  • Page 14: Electric Drive

    The Bosch Cargo motor provides support with up to 85 Nm up to the legally prescribed limit of 25 km/h. Further information at www.bosch-ebike.com You can ride your VELLO SUB just like a conventional bike. When the drive unit is switched on, the more Fig. 1.4 forcefully you pedal, the more the motor supports you with its torque.
  • Page 15 LED Remote The LED remote connects the VELLO SUB with the eBike Flow app. It shows all important riding data, is intuitive to operate and keeps your hands safely on the handlebars. The different coloured LEDs adjust their brightness to the surroundings - for optimum readability.
  • Page 16 The SUB luggage carrier has suitable profiles for the MIK and MIK-HD system accessories. The tool-free quick-change system makes it possible to change the configuration of the VELLO SUB quickly and easily. Child seats and load baskets can be safely attached and removed. Up to two MIK or MIK-HD systems can be fitted at the same time.
  • Page 17 (Fig. 1.5). The safety catch in the button pops up with a clicking sound (Fig. 1.6). Before placing a child in the child seat, please check that the child seat is securely attached to the luggage carrier of the SUB.
  • Page 18 BRAKE SYSTEM The VELLO SUB is equipped with two independent MT5 - 4 piston disc brakes from Magura to ensure maximum safety and to comply with legal regulations. Never ride with only one functioning brake and test the brakes for proper function before every ride.
  • Page 19 Operating instructions for Magura MT5 brakes: https://en.vello.bike/sub/magurabrakes PEDALS The VELLO SUB is equipped with foldable pedals. To fold the pedals, push the pedal cage towards the crank (Fig. 1. 1 ) and fold it 90 degrees (Fig. 1.2). Fig. 1.2...

  • Page 20: Wheels And Tyres

    WHEELS AND TYRES The VELLO SUB is equipped with 20-inch wheels to keep the centre of gravity as low as possible and stability and manoeuvrability high. The gear ratio of the front pulley has been adapted to the wheel size. 20-inch tyres with an E.T.R.T.O.
  • Page 21 BELT DRIVE The VELLO SUB bike is equipped with a belt drive from Gates. If necessary, clean the belt with water and a clean, soft (non-fraying) cloth. Do not apply any lubricant to the belt. Have the belt tension checked regularly by your specialist cycle workshop and adjusted if necessary.

  • Page 22: Maintenance And Service

    Please note that road salt on the roads in winter or the salty air near the coast can damage the bike. Clean the bike at least every 200 kilometres. HOW TO STORE YOUR VELLO CORRECTLY Store your VELLO bike in a dry room. Please note that the tyres lose pressure when stored for long periods.

  • Page 23: Workshop Service

    Your VELLO SUB is equipped with high-quality components that are usually available in local bike shops. However, if this is not the case, please contact VELLO. We will be happy to provide you with spare parts. CAUTION: Tampering with the components can restrict their functionality, cause defects, or damage the bicycle parts.
  • Page 24 ENGLISH VERSION TIGHTENING TORQUE COMPONENTS & ASSEMBLY INSTRUCTIONS COMPONENT TIGHTENING TORQUE NOTE Cable clamping screw 3,5 Nm ca. 7 Nm Brake lever Calliper clamping screw 10-15 Nm Grease thread Calliper bolt 8 Nm Brake callipers: 8 Nm M6 adapter screw Crank bolt Apply a little grease to the thread 40 Nm on both sides...
  • Page 25 Headset bearing, grub 10 Nm Apply a thin layer of grease to the screw (Allen 2.5mm) industrial bearing of the headset on both sides, then adjust the headset bearing using a small screw. Luggage carrier 6-10 Nm Mounting screws...

  • Page 26: Warranty And Guarantee

    ENGLISH VERSION WARRANTY AND GUARANTEE VELLO offers a manufacturer’s warranty of 2 years on the frame and fork, provided proof of purchase can be presented. Components (excluding wearing parts) have a warranty period of 2 years from the date of purchase.

  • Page 27: Ec Declaration Of Conformity

    European Directives in its design and construction at the time of declaration: Product description: E-pedelec for cargo Models: VELLO SUB and VELLO SUB Titan Year of production: 2023 Directives: Machinery Directive - 2006/42/EC, EMC Directive 2014/30/EC, Low Voltage...

  • Page 28: Recycling And Disposal

    At the end of its service life, the pedelec should be taken to a local collection centre. The battery can be returned to a VELLO dealer or sent to VELLO GmbH for disposal: VELLO GmbH - Disposal- Reinprechtsdorfer Str.
  • Page 29 2 x Bosch battery Battery model pack 400 WH pack 545 WH pack 545 WH 1x Bosch battery 2x Bosch battery pack 800 WH pack 800 WH Key number Schwalbe Schwalbe Tyres Big Apple Marathon Stamp and signature of the VELLO Bike dealer...
  • Page 30 ENGLISH VERSION HANDOVER PROTOCOL The VELLO SUB described above was handed over to the customer after final assembly in the finished state and the testing and functional check of the points listed below. Battery partially charged Lighting Front and rear brakes...
  • Page 31 I hereby expressly consent to my above-mentioned data being stored by the VELLO dealer and passed on to the manufacturer - VELLO Bike, so that I can be contacted directly, e.g. in the event of a recall. The data will not be passed on to third parties or...

  • Page 32: Inspection Intervals

    At the latest, after 200 kilometres or after six months from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 33 At the latest, after 2000 kilometres or after one year from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 34 At the latest, after 4000 kilometres or after two years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 35 At the latest, after 6000 kilometres or after three years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 36 At the latest, after 8000 kilometres or after three years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 37 At the latest, after 10000 kilometres or after four years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 38 At the latest, after 12 000 kilometres or after five years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 39 At the latest, after 14 000 kilometres or after six years from the date of purchase. Order n°: Date: Mileage: All necessary maintenance work carried out (see service and maintenance schedule for the VELLO SUB), parts replaced or repaired: Stamp and signature of the VELLO Bike dealer:...
  • Page 40 ENGLISH VERSION Thank you! Your VELLO team wishes you a safe journey at all times. VELLO GmbH Reinprechtsdorfer Str. 58-60 1050 Vienna, Austria E-mail: support@vello.bike - www.en.vello.bike Join the Community - Become a VELLOnaut: facebook.com/vellobike lnstagram: vellobike #vellobike Do you need help? www.en.vello.bike/support...
