Whirlpool AKZ 130 Product Description Sheet

AKZ 130
IL
Last
First
ACCESSORIES • Grid
• Drip tray
OVEN FUNCTIONS TABLE
Function
Function
symbol
0 OVEN OFF
OVEN LIGHT
MLTF
(Heat Maintenance)
STATIC
PASTRY
(Static+Fan)
FAN
TURBOFAN
GRILL
TURBOGRILL
(Grill+Fan)
PROGRAMME
5019 310 54741
PRODUCT DESCRIPTION SHEET
First-Last... shelf positions
1.Control panel
2.Cooling fan* (not visible)
3.Top heating element (can be lowered)
4.Oven light
5.Round heating element (not visible)
6.Fan
7.Bottom heating element (not visible)
8.Oven door hinges
9.Oven cool door
*N.B.: The cooling fan switches on only when the oven has reached a
certain temperature.
After the oven switch off, the cooling fan may, however, continue to run
for a certain time to ensure proper cooling.
Preset Function description
temperature/level (see details in the user's manual)
- -
- To switch on the oven light.
To keep a constant temperature, either 35°C or
35C
60°C.
200C To cook food at one shelf level. Preheating.
To cook on two shelf levels, at the same
175C
temperature.
To cook on more than one shelf level, at the same
160C
temperature.
To cokk: large fruitcakes, stuffed vegetables,
160C
timbales, poultry.
3 To grill small pieces of meat, toast, etc...
3 To grill large pieces of meat.
P1 To bake pizza, bread, focaccia.
1
1. Selector knob: to choose the oven functions.
2. Button to select and confirm the different operations (operate by single presses only).
3. Knob to set: time of day, cooking time, the time at which cooking should terminate, the temperatures and the
power levels (Function P).
Push-Push knobs
• To use this type of knob, press it in the middle.
• Turn the knob to the desired position.
• Once cooking is over, turn the knob back to the position marked by "0" and press it again to restore it to its initial
setting.
STARTING THE OVEN
When the oven is connected to the power supply for the first time, or re-connected after a power failure, the display
shows " ".
To start the oven:
• turn knob 1 to "0".
• press button 2. The display shows "--:--".
FOR A DESCRIPTION ON HOW TO USE THE OVEN, PLEASE REFER TO THE PROGRAMMER DESCRIPTION SHEET.
