Summary of Contents for BERG BRF-1D
- Page 1 SERVICE, INSTALLATION AND USER MANUAL REACH-IN REFRIGERATORS BRF-1D/BRF-2D/BRF-3D SS REACH-IN FREEZERS BFZ-1D/BFZ-2D/BFZ-3D SS PLEASE READ COMPLETELY...
-
Page 2: Table Of Contents
TABLE of CONTENTS INTRODUCTION ....................................... 2 SERIAL NUMBER INFORMATION ................................2 RECEIVING AND INSPECTING THE EQUIPMENT ..........................3 APPLIANCE SAFETY ....................................3 IMPORTANT SAFEGUARDS ..................................4 Electrical Connection .................................... 5 Power Surges ....................................... 5 Refrigerant Disposal ..................................... 5 Appliance Disposal ....................................5 APPLIANCE INSTALLATION .................................. -
Page 3: Introduction
INTRODUCTION This user’s manual is intended for installing, using and servicing your appliance. It is recommended that this manual be kept in an accessible place. Every machine is designed and manufactured according to the highest standards of safety and performance. It meets or exceeds UL 471 safety standards and sanitation standard NSF 7. Our company assumes no liability or responsibility of any kind for products manufactured by our company that have been altered in any way, including the use of any parts and/or other components not specifically approved by our company. -
Page 4: Receiving And Inspecting The Equipment
RECEIVING AND INSPECTING THE EQUIPMENT Even though the equipment is shipped crated, care should be taken during unloading so the equipment is not damaged while being moved into the building. 1. Visually inspect the exterior of the package and skid or container. Any damage should be noted and reported to the delivering carrier immediately. -
Page 5: Important Safeguards
IMPORTANT SAFEGUARDS Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. We strongly recommend that you have a professional install your new machine. The warranty may be affected or voided by an incorrect installation. -
Page 6: Electrical Connection
IMPORTANT SAFEGUARDS (cont.) Electrical Connection Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded. The power cord of this appliance is equipped with a 3-prong grounding plug that mates with a standard 3-prong grounding wall outlet to minimize the possibility of electric shock hazard from the appliance. -
Page 7: Appliance Installation
APPLIANCE INSTALLATION WARNING Excessive Weight Hazard Use two or more people to move and install appliances. Failure to do so may result in injury. Remove Packaging Materials IMPORTANT: Do not remove any permanent instruction labels or the data label on your appliance. •... -
Page 8: Installation Clearance
APPLIANCE INSTALLATION (cont.) Installation Clearance Double Door Models Single Door Models 2” 12” (305mm) clear space 51mm 60.5 in 60.5 in 1537 mm 1537 mm Max Door Swing Max Door Swing Clearance Clearance 27 in 27 in 686 mm 686 mm Leveling Ensure the floor where the unit is to be located is level. -
Page 9: Operation
OPERATION Refrigerator Cycle Refrigerators: During the refrigeration cycle, the evaporator fans will run continuously when doors are closed, and the evaporator fans will stop when one or more doors are open. The door switch will activate the lights when opened. Every 6 hours, the unit will turn off and allow the evaporator coil to defrost by the compressor stopping. - Page 10 9. For best performance the ambient conditions should be less than 80°F with a relative humidity below 65%. 10. Ensure the automatic defrost cycle is set to keep the evaporator fan coil free of ice with proper air flow or the unit won’t maintain the right temperature.
-
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE DANGER The unit must be turned off and disconnected from the power source whenever performing service, maintenance functions or cleaning the refrigerated area. Failure to comply may result in death or severe personnel injury. NOTE Ongoing appropriate preventative maintenance along with cleaning the unit will preserve its performance, deliver a high-quality fresher product and extend the appliance life. -
Page 12: Stainless Steel Care And Cleaning
CLEANING AND MAINTENANCE (cont.) Stainless Steel Care and Cleaning To prevent rust or discoloration on stainless steel several important steps need to be taken. First, one must understand the properties of stainless steel. Stainless steel contains 70-80% iron which will rust. It also contains 12-30% chromium which forms an invisible passive film over the steel’s surface which acts as a shield against corrosion. -
Page 13: Troubleshooting Guide
TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE If the unit appears to be malfunctioning, read through the OPERATION section of this manual first. If the problem persists, see the Troubleshooting chart below. The problem may be something very simple that can be solved without a service call. - Page 14 TROUBLESHOOTING (cont.) Action Fault Probable Cause Check the hot gas line temperature. The condensate pan isn’t keeping up Add an additional powered condensate evaporator pan to and is overflowing. Water is pooling up on the accommodate the overflow. floor near the appliance. Reposition the drain line so it flows If connected to a floor drain the setup has become misaligned...
-
Page 15: Dimensions And Technical Information
DIMENSIONS AND TECHNICAL INFORMATION Model Product Dimension, W x D x H Volume Temperature Range BRF-1D 27.2 x 33.3 x 80.9in/691 x 846 x 2055mm 19.3 cu. ft. / 542L 34-41℉/1-5℃ BFZ-1D 27.2 x 33.3 x 80.9in/691 x 846 x 2055mm 19.3 cu. -
Page 16: Warranty
ONE YEAR WARRANTY Berg warrants to the original purchaser of this unit, the unit cabinet and all parts thereof, to be free from defects in material and workmanship, under normal conditions of use and maintenance, for a period of one (1) year from the date of original purchase. - Page 17 Equipment or from any other cause relating thereto, whether arising in contract, tort, warranty, strict liability or otherwise. BERG’s liability hereunder in any case is expressly limited, at BERG’s election, to repair or replacement of, or crediting the user with, an amount equal to the purchase price of such goods.
