Instruction Manual for AE-T Set (with RHC)
Portable Dry Fog Humidifier Set
with Automatic Humidity Control
(incl. AKIMist® "E", Humidity Controller RHC-C11 and Sensor HN-EK)
Thank you for purchasing our product.
Please read this manual carefully and follow the instructions to ensure optimal
performance.
Keep this manual handy for quick reference.
Parts of products may be changed without prior notice.
Please be aware that due to continuing efforts to improve our products, some
details in this manual may differ from the actual product.
Thank you for your understanding.
－
Contents
－
P.1
P.3
P.3
P.4
P.5
P.6
P.11
P.14
P.15
P.16
No.NKG24M106-2E
Advertisement
Table of Contents
Related Manuals for IKEUCHI AE-T Set
Summary of Contents for IKEUCHI AE-T Set
-
Page 1: Table Of Contents
No.NKG24M106-2E Instruction Manual for AE-T Set (with RHC) Portable Dry Fog Humidifier Set with Automatic Humidity Control (incl. AKIMist® “E”, Humidity Controller RHC-C11 and Sensor HN-EK) Thank you for purchasing our product. Please read this manual carefully and follow the instructions to ensure optimal performance. -
Page 2: Safety Precautions
1. Safety Precautions If the product is used without observing the information given Warnings under this symbol, death or serious injury may result. Cautions If the product is used without observing the information given under this symbol, personal injury, physical, and/or property damage may result. - Page 3 Cautions ・Close the air and water valves before disassembling AKIMist “E” and the nozzles. Failing to do so may result in nozzle damage and water leakage. ・Operate only in environments with a temperature of 5-40ºC and humidity below 80% RH. Avoid areas with dust or chemical atmospheres containing organic solvents, acids, or alkalis.
-
Page 4: Features
2. Features Produces large volumes of Dry Fog with simple operation. Light weight, compact and easy to move. Easy assembly. 3. Checking the Delivery Before starting installation, please verify that all the parts listed below are included in your delivery. If any item is missing, please contact us or your supplier. -
Page 5: Structure
4. Structure AKIMist “E” Portable Dry Fog Humidifier Set is to be assembled as shown below. AKIMist “E” ® Dry Fog Humidifier Operating air pressure regulator Extendable pole Spiral tubes Humidity sensor (hereafter referred to as “Sensor”) Sensor cable (5 m) Humidity controller Water tank RHC-C11... -
Page 6: Caution Before Assembly
5. Caution Before Assembly ★Tighten the screw firmly with a spanner. ★Apply sealing tape to each thread. Tube Leave the first few turns of the thread without sealing tape. Wrap the remainder of the threading with 2 to 3 turns of sealing tape while maintaining some tension. -
Page 7: Assembly
6. Assembly Scan for assembly guide. Refer to manual for details. Note: This video does not include assembly instructions for step 11 (mounting the humidity sensor) and subsequent steps on page 10. Please refer to the manual for these instructions. Assemble AKIMist “E”... - Page 8 3) Attach the spiral tubes on the AKIMist “E” mounting unit as follows. I. Remove the fitting cap from AKIMist “E” mounting unit. Slip the fitting cap on the end of the black spiral tube. II. Insert the black tube all the way into the fitting of the mounting unit. Cautions Tube inserting is very tight.
- Page 9 4) Open the lid of water tank and fill the tank with water. Replace the cap and tighten it firmly. 5) Set the water tank on the stand. 6) Connect the blue valve at the end of black spiral tube to the joint on the water tank.
- Page 10 8) Install AKIMist “E” to the mounting unit as below. Protective caps are placed on the air and water inlets of the AKIMist "E". Remove them before installation. I. Push the plugs for air and water into their respective sockets until they click. Refer to page 5 for how to connect the couplers.
- Page 11 10) Adjust the height of the extendable pole as desired. Loosen Tighten 11) Install the humidity sensor on the wall, then connect the pre-attached sensor cable from RHC-C11 to the sensor, referring to the 1. Preparation Before Use section in the enclosed RHC-C11 manual (pages 3, 6-13). 12) Connect the solenoid valve to RHC-C11 as below.
-
Page 12: Operation
7. Operation 1. Starting operation The actual appearance and shape of the parts may differ from the presented images. 1) Remove the protective caps from the nozzles of the AKIMist ”E” before use. 2) Turn on the RHC-C11 power switch and set the relative humidity set value (SV), referring to 2. - Page 13 2. During operation When you need to change the spray volume Adjust the air pressure by turning the control knob of the air pressure regulator on the AKIMist “E” mounting unit. See the table below. Spray volume (L/hr) Air pressure (MPa) AE-1 AE-2...
- Page 14 3. Stopping operation and The actual appearance and shape of the parts may differ from the water refill to the tank presented images. ☆ indicates procedures only for stopping operations. △ indicates procedures only for liquid refilling. No mark indicates common procedures to both. 1) Close the red valve on the stand.
-
Page 15: Maintenance
8) Confirm that the blue valve at the foot of the spiral tube is closed and disconnect the coupler at the foot of the water tank. Push down the ring of female coupler, then pull out the coupler. ☆ 9) Empty the water tank. △... -
Page 16: Troubleshooting
9. Troubleshooting If any trouble occurs, immediately stop the air supply and check as follows. (Also see the troubleshooting section in the instruction manuals of AKIMist ”E” and RHC-C11.) Troubles Probable causes Solutions No spray or spray Air compressor is not turned on. Switch it on. -
Page 17: Specifications
10. Specifications ■ AKIMist ”E” Portable Dry Fog Humidifier Set (AE-T set) ® AE-1 AE-2 AE-3 AE-4 Humidifier model No. (03C) (03B) (03C) (03B) (03C) (03B) (03C) (03B) Spray volume* (L/hr) 1.3–3.6 2.6–7.2 3.9–10.8 5.2–14.4 13.2 Air consumption 22–43 44–86 66–129... - Page 18 https://www.dry-fog.com/en/ Overseas Division Daiichi Kyogyo Bldg., 1-15-15, Awaza, Nishi-ku, Osaka 550-0011 Japan Fax: +81-6-6538-4022 e-mail: overseas@kirinoikeuchi.co.jp...
