Moman M1 User Manual

Microphone M1
User Manual
Thank you for choosing MOMAN product. Please read this manual
carefully before use and follow all instructions mentioned herein.
Caring For Your MOMAN Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids
warranty.
Please have the product checked or repaired by authorized
technicians if any malfunctions happened.
Failure to follow all the instructions may result in mechanics
damage.
Warranty does not apply to human errors.
Packing List
Transmitter x1 Receiver Charging cable
[ 2 pcs for M1XL / M1XT ] (Type-C or Lightning x1
Connector) x1
Mic Windshield x1 Carrying Bag x1 User Manual x1
[ 2 pcs for M1XL / M1XT ]
Product Introduction
1. TX Transmitter
① Power Key
② Working Indicator
③ Built-in Microphone
④ Back Clip
⑤ Type-C Charging Port
2. RX Receiver
① Volume Button
② Type-C Port
Lightning Connector
③ Working Indicator
④ Connector
Type-C Connector
3. Indicator
* Note：The indicator identification shown as follows.
Left Right
① Transmitter
Working Indicators (White Light) On： Flash：
Slow Flash
Unpaired
Illuminate sequentially
Paired, normal working
Single indicator keeps on
Noise cancellation on
② Receiver
Working Indicators (White Light) On： Flash：
Slow Flash
Unpaired
Connected and working normally.
1~5 indicators on
The number of lights on indicates the
current volume
Single indicator flashed
Mute on
slowly
Operations
1. Turn On/Off
① Transmitter: Long press the power button of the transmitter for 3
seconds.
*Note：The transmitter will shut down automatically if it is unpaired
or disconnected for 5 minutes.
② Receiver: Insert the mobile phone device to switch on
automatically, and the indicator flashes.
