Exibel D1051C9Z Manual

Wireless mouse
Art. no. 39-2789 Model D1051C9Z
Please read the entire instruction manual before using the product and
then keep it for future reference. We accept no liability for any errors
in the text or images and we reserve the right to make any necessary
changes to technical data. If you have technical problems or other
questions, please contact our customer service team.
Product description
2 3
4
6
5
7
1
8
1. Go back to desktop
2. Left mouse button
3. Right mouse button
4. Clickable scroll wheel
5. [ DPI ] Set the speed of the mouse pointer on the screen
6. Indicators for charging and the connected device:
White LED: Charging in progress/connected to 2.4G
Blue LED: Connected to Bluetooth 1
Green LED: Connected to Bluetooth 2
7. Next
8. Previous
9. Side scroll wheel
10. Device selector
11. USB receiver storage compartment
12. On/off switch
13. Win/mac, toggle between Windows and macOS
Using the mouse
On/Off
Push the On/Off switch (12) to "ON" to start
the mouse and "OFF" to switch it off.
UNITED KINGDOM - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk postal: 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
Charging
1. Connect the USB cable to the mouse and to any USB port.
2. Indicator (6) turns red during charging and goes out when the
mouse is fully charged.
Connecting with the USB receiver
12 1. Remove the receiver from its storage compartment in
the base of the mouse and plug it into a USB port on
13
9
your computer.
The mouse will install itself automatically.
11
Win
10 Mac1
2. Press (10) and select
Mac2
Connecting with Bluetooth
The mouse can be connected to and toggle between two Bluetooth
devices.
1. Press [
2. Press and hold [
begin to flash.
3. Connect and start searching for Bluetooth devices on the unit
the mouse is to be connected to.
Selecting Windows or macOS
For the function buttons (1), (7), (8) to work correctly, the right opera-
ting system/language must be selected. Note: Not all languages are
supported for macOS.
Press [Win/mac] (13) once or repeatedly to change mode.
The indicator LED (6) will flash the following number of times for
the mode selected:
-
-
-
Standby mode
ON
To save power, the mouse will go into light standby mode after
3 seconds and deep standby mode after 8 minutes.
OFF
Press any button to restart it.
Win
Mac1
Mac2
English
USB receiver.
] (10) and select channel BT1 or BT2.
] for 3 seconds until a blue or green light
Win * * (All languages)
mac 1: * * * (English UK)
mac 2: * * * * (Other Nordic countries. Does not support
Norwegian)
DPI button (5)
DPI = The speed of the mouse pointer on the screen.
Press repeatedly to toggle between the DPI settings:
800, 1600, 2400, 3200 or 4000
Storage
Store the USB receiver in its compartment in the base of the mouse if
you are travelling or you need to take the mouse somewhere with you.
Cleaning and maintenance
• Clean the mouse with a damp cloth. Use only mild detergents.
Never use solvents or corrosive chemicals.
• Remove the battery if you are not going to use the mouse for
a long time.
Troubleshooting
Problem Solution
The buttons and Check whether Win/mac is set correctly
functions do not for the operating system in use.
work properly.
The mouse does not Is the mouse switched on? Is the battery
work. charged?
Is the correct channel activated/selected
on the device selector?
Check the USB port and try switching to
another port.
Responsible disposal
This symbol indicates that the product should not be
disposed of with general household waste. This applies
throughout the entire EU. To prevent any harm to
the environment or health hazards caused by incorrect
waste disposal, the product must be handed in for
recycling so that the materials can be disposed of in
a responsible way. To recycle the product, take it to
your local recycling facility or contact the retailer. They
will ensure that the product is disposed of in a way that
does not harm the environment.
Specifications
Battery Chargeable
Connection USB-C
DPI 800, 1600, 2400, 3200, 4000
