Soozier A90-279 Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IN240400323V01_US
A90-279_A90-279V01
Maximum user weight is 120 kg.
*
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A90-279 and is the answer not in the manual?

Questions and answers

Related Manuals for Soozier A90-279

Summary of Contents for Soozier A90-279

  • Page 1 IN240400323V01_US A90-279_A90-279V01 Maximum user weight is 120 kg. IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTIONS...

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS READING CAREFULLY! Please keep this manual in a safe place for easy reference 1.It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.

  • Page 3: Maintenance / Inspection

    Attention! 1.If the computer would not be displaying data normally, please install the battery again. 2.The battery must be taken out from the computer for safe treatment once it was out of energy for trash. 3.This manual is also suitable for equipment without computer. MAINTAIN Neutral detergent can be used to dilute the water to wipe the cloth carefully wipe the oil, and then dry with a dry cloth.

  • Page 4: Exploded Drawing

    EXPLODED DRAWING...

  • Page 5: Spare Parts List

    SPARE PARTS LIST DESCRIPTION QTY. DESCRIPTION QTY. Main frame Plastic washer Pedal support tube(L) T-shaped steel washer Pedal support tube(R) Plastic washer Upper stand tube Plastic plugφ25 Lower stand tube Flat washerφ19 Handle tube Circlip Pedal Plastic washer Bushingφ60 Hex screw M12x80 Pull pin Flat washerφ12 Monitor base...

  • Page 6: Assembling Instruction

    ASSEMBLING INSTRUCTION After unpack the carton, check and make sure nothing is missing. 1. lock the rear end cap(51) with cross screw (48). 2. Insert the bushing(13) to the front tube of the main body.
  • Page 7 3.Connect the lower stand(5) tube to the upper stand(4) tube by pull pin (9). 4.Make the connecting line(44) go through stand tubes. 5.Connect the line of the main body to the connecting line(44) that go through the stand tubes. 6.Connect the lower stand tube (5) to the mian body with Inner hexagon screw M8x20 (43) and Arc-shaped washer (49).
  • Page 8 7.Make the upper side of connecting line go through the hole on the monitor base(10). 8. Install the handle bar with Inner hexagon screw M8x25 (45). 9.Connect the upper end of connecting line to the line of the monitor.
  • Page 9 10. Insert the monitor(11) to the monitor base(10). 11.Install the plastic cover. 12. install the adjusting knob(14) to the main body.

  • Page 10: Specifications

    COMPUTER SPECIFICATIONS: TIME........00:00-99:59 CALORIES (CAL).....0.0-9999KCAL COUNT......0-9999 STRIDES/MIN....0-2000 BATTERY: 1 AAA 1.5V batteries are required. Remove the battery cover on the back of the computer; insert 1 new “AAA” batteries. Ensure that the batteries are correctly positioned and that proper contact is made with terminals. NOTE: Removing the batteries will erase any stored monitor function.

  • Page 11: Operation Procedures

    OPERATION PROCEDURES: AUTO ON/OFF: The computer turns on when any key is pressed or when it receives an input from the sensor. The computer turns off when the sensor has no signal input or if no key is pressed for approximately 4 minutes. RESET: The unit can be reset by changing the batteries or pressing the RESET key for 3 seconds.
