Summary of Contents for Soozier A90-281
- Page 1 INapc003_US A90-281_A90-281V01 Instruction Manual Twist stepper with handle * Maximum user weight is 100 kg. IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS READING CAREFULLY! Please keep this manual in a safe place for easy reference 1.It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly. - Page 3 Attention! 1.If the computer would not be displaying data normally, please install the battery again. 2.The battery must be taken out from the computer for safe treatment once it was out of energy for trash. 3.This manual is also suitable for equipment without computer. MAINTAIN Neutral detergent can be used to dilute the water to wipe the cloth carefully wipe the oil, and then dry with a dry cloth.
-
Page 4: Exploded Drawing
EXPLODED DRAWING... -
Page 5: Parts List
PARTS LIST PART DESCRIPTION PART DESCRIPTION Main frame Computer Pedal frame (L) Bolt Pedal frame (R) Computer EVA Cushion Bolt Pedal (R) Magnet Pedal (L) Washer Adjustment knob Plastic washer Plastic bushing Washer (Ǿ40) Bolt cap Screw Bolt (M6 * 15) Handle fix seat Stopper Washer... - Page 6 ASSEMBLY INSTRUCTIONS Carefully follow all the assembly steps as explained on this manual. Please refer to the illustrations in order to assemble all parts correctly. Step 1: 1:Take the Main frame and handles out of carton. Lay out all the parts as illus- trated in the image on the left picture.
- Page 7 SESSIONE DI ALLENAMENTO Step 3 3 : Assemble the middle tube into low parts and fasten it as like left picture show. Step 4 4 : Assemble the upper tube into middle and fasten it as shown. Pls repeat above assemble step for left handle assembly.
-
Page 8: Function Parameter
FUNCTION PARAMETER SCAN Automatically scans each function in sequence. TIME Displays the total time of the workout session starts from 00:00 – 99:59. COUNT Displays the total number of steps taken during the workout session. REPS/MIN Displays the repetitions (or strides) per minute during the workout session. -
Page 9: Battery Replacement
BATTERY REPLACEMENT If the figure of display show dim and power use out ,pls replace the battery. Step 1 Battery Take the computer from main frame , Open the Computer (Part: 22), replace old battery to new one (Pic.: 1) Step 2 Install the Computer (Part: 22) into Main Frame (Part: 1), then to check the function again. - Page 10 PRODUCT OPERATION GUIDE METHOD OF USE GUIDANCE 1: Before using stepper , please put the pedal position by hand carried to the highest, then adjusting knob at the bottom of stepper to keep the pulley on the condition of tight ,see below pictures .
