  • Page 1 USER’S MANUAL TMT 800LS SLIDING GATE OPENER...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction & Recommendations .........................3 Areas of injury or entrapment ..........................4 Technical Specifications ............................4 Kit Inclusions .................................5 Operator Parts Indentification..........................5 Site Setup ................................6 Gate Forces................................6 Automating Unlevel Gate ............................7 Anchoring Base Plate ............................8 Securing Motor ..............................8 Manual Override ..............................8 Mounting Racking ..............................9 Mounting Limit Brackets ............................9 Wiring Transformer ...............................10...

  • Page 3: Introduction & Recommendations

    INTRODUCTION & RECOMMENDATIONS We strongly recommended using the services of an experienced gate installer to install your gate operator but if you intend installing the operator yourself, the manual must be read carefully before any installation begins. While you have taken all reasonable steps to ensure that your gate operator is safe to install and use, it must be noted that your gate is a heavy moving piece of equipment and can cause serious damage or injury if it strikes an object or person.

  • Page 4: Areas Of Injury Or Entrapment

    AREAS WHERE INJURY OR ENTRAPMENT CAN OCCUR 5 & 6 1. Gate Wheels (Pets at risk when lying at the gate) 5. Pinion Gear 2. Between the gate & the end stop 6. Between the gate operator & the gate 3.

  • Page 5: Kit Inclusions

    KIT INCLUSIONS 4 x racking Motor & Base Plate 1 x Outdoor Transformer for L/V kit only 2 x Release keys 2 x Remotes 4 x Bolts and washers 2 x limit brackets with screws OPERATOR PARTS INDENTIFICATION a. Gear Cog e.

  • Page 6: Site Setup

    SITE SETUP Guide & Rollers Gate Catcher Important - the gate MUST have permanent end stops in both the closed and Gate Stop open positions to prevent the gate running off the track in the even of a failure GATE PULL AND RUNNING FORCES The gate Pull and Running Forces must be measured before installing the operator.

  • Page 7: Automating Unlevel Gate

    AUTOMATING UNLEVEL GATE We do not recommend automating a gate which is not level. Failure to level the gate will put undue stress on the operator and the gate may bump the end stops. Futhermore, if the operator is in manual override mode, the gate may run freely down the slope and present a safety risk.

  • Page 8: Anchoring Base Plate

    4. Attach the base plate to the slab, using the 4 bolts supplied or other fixings. Note: the 60mm distance is using BMGi’s racking which is 40mm wide SECURE THE MOTOR TO THE BASE PLATE Secure the motor to the base plate using the 4 screw holes as shown.

  • Page 9: Mounting Racking

    MOUNTING THE RACK ON THE GATE There must be a 2-3mm gap clearance between the mounted rack and the cog 1. Start with the gate in the open position, place the first piece of rack on the cog making sure you have the 2-3mm gap between the rack and cog.

  • Page 10: Wiring Transformer

    Image B OPTIONAL BACKUP BATTERY WIRING The backup battery is optional and can be added at anytime. BMGi does not carry the battery size required. Parts required: 2 x 12volt 1.4 amp hr batteries 1 x loop wire with battery connectors...

  • Page 11: Control Board Layout

    CONTROL BOARD 8.8. DOWN...

  • Page 12: Remote Tuning

    REMOTE TUNING & ERASING 1. Remote tuning: Press the RF button for 3 seconds and the LED display will show CS. Then press the remote left button (A), the LED display will blink 3 times and stay on. After 7 seconds without any new remotes learnt, the LED will be off and the remote learning is complete - see images 1, 2, 3 2.

  • Page 13: Factory Reset

    FACTORY RESET IF A FACTORY RESET IS REQUIRED FOR SOME REASON, FOLLOW THE BELOW INSTRUCTIONS It is recommended the user checks the menu functions and adjust any values back to BMGi default settings before proceeding. Press UP and DOWN for 3 seconds and the LED will display “CL”...

  • Page 14: How To Set The Parameters

    30% Operating speed 40% Operating speed 50% Operating speed Opening Ramp Down First 25% of full distance BMGi default 81 Distance First 20% of full distance preset in factory First 15% of full distance (Default) First 10% of full distance...
  • Page 15 (Medium Gate) 10A (Default) (Heavy Gate) Pedestrian Mode (Default) E1 = 3 sec Travel Time 3 Seconds (BMGi Default - preset in factory) This is how long 6 Seconds the gate will open 9 Seconds for before turning 12 Seconds...
  • Page 16 ..CONTINUED DEFINITION FUNCTION VALUE DESCRIPTION External Device key No Function (Default) A key B key C key D key Auto Close Override No Function (Default) A key B key C key D key Photocell 1 Activation Function OFF (Default) Function ON Photocell 2 Activation Function OFF (Default) Function ON...
  • Page 17 F3 Function Settings Logic F3-1 The reactions of the photocells when detecting obstacles Gate Status Photocell 2 Photocell 1 Closed Open not allowed No effect Open No effect Reloads automatic closing time Stop during moving Open not allowed Reloads automatic closing time Closing No effect Open...

  • Page 18: Accessory Wiring

    ACCESSORY WIRING Wiring in your Visitor Push Button TMT motor control board Wiring in your Key Visitor Push Button Attaching Point Attaching Point Drill hole here for cable entry and silicone TMT motor control board...
  • Page 19 Wiring in your Long Range Receiver TMT motor control board Scan below for more help on wiring and tuning LONG RANGE 7CH RECEIVER Wiring in your KP receiver TMT motor control board Scan below for more help on wiring and tuning KP RECEIVER...
  • Page 20 Wiring in your Keypad TMT motor control board KEYPAD WIRING Wiring in your GSM Gate Opener TMT motor control board Door Sensor Scan below for more help on Relay Out put wiring and instructions Power DC9-24V GSM Gate Opener...
  • Page 21 Wiring in your Hard Wired Safety Beams/Photocells TMT motor control board Control board will have factory settings - observe these and adjust Wiring in your Semi Wireless Safety Beams/Photocells TMT motor control board Control board will have factory settings - observe these and adjust WIRELESS BEAMS...

  • Page 22: Service Schedule

    Service schedule The TMT 800LS gate operator, much like a car, will provide many years of excellent service if a service schedule is carried out at regular intervals. Follow these basic checks and do repairs in time to get the most out of your operator.
  • Page 23 The complete system should be tested weekly and immediately after a break-in, an attempted break-in, fire, storm, earthquake, accident, or any kind of con- struction activity inside or outside the premises. PLEASE VISIT OUR WEBSITE FOR TERMS AND CONDITIONS WWW.BMGI.COM.AU OR SCAN THE QR CODE BELOW...
