- Page 1 Installation Manual E8 - 400 E8 - 500 E8 - 600 Solar or Electric Systems...
- Page 2 WARNING Important Safety Information Gate equipment has hazards associated with its use and therefore by installing this product the installer and user accept full responsibility for following and noting the installation and safety instructions. Failure to follow installation and safety instructions can result in hazards developing due to improper assembly.
-
Page 3: Table Of Contents
Table of Contents Important Safety Information ..............2 - 6 Manually Opening and Closing Gate ............4 Technical Specifiations .................. 7 Kit Inclusions ..................... 7- 8 Optional Extras ..................... 9 Example Setup of Single Swing Gate ............10 Example Setup of Double Swing Gates ............11 Before You Begin (Power Options &... -
Page 4: Important Safety Information
Important Safety Information Because automatic gate operators produce high levels of force, consumers need to know the potential hazards associated with improperly designed, installed, and maintained automated gate opener systems. Keep in mind that the gate opener is just one component of the total gate op- erating system. - Page 5 Important Safety Information For the Installer and End User WARNING To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Never let children operate or play with gate controls. Keep the remote control away from children. Always keep people and objects away from the gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
- Page 6 Important Safety Information For the Installer and End User After Installation Attach the warning sign (included) to the gate to alert the public of automatic gate operation. The gate is automatic and could move at any time, posing serious risk of entrapment. No one should be in contact with the gate when it is moving or stationary.
-
Page 7: Technical Specifiations
Technical Specifications Supply voltage: 16vac Transformer or Solar Backup Battery: 12Vdc Lead acid maintenance free Operating Voltage: DC 16-18V for normal speed DC 6-10V for cushioning speed Driving Method: Screw driven type Max. Output Power: 80W per driver Gear Box: Three-stage spur gear reducer Operating Cycle: 13-19 seconds Per 90°... -
Page 8: Kit Inclusions
STANDARD KIT INCLUSIONS Actuator Arm with cardboard template Caution Sign Control Box Main Control board Receiver Rubber Stop Push Button Remotes 12v Battery Regulator 20watt Solar Panel Transformer (if Solar) (if Solar) (if Electric) Primary Secondary Gate Bracket Bracket Set Release Key Bracket Bracket... -
Page 9: Optional Extras
OPTIONAL EXTRAS Round Gate Bracket Round Post Brackets Adjustable Hinge Long Range Upgrade Extra Secondary Bracket Wired Keypad Wireless Keypad 40watt Upgrade Keyed Push Button Wireless Eyebeams Wired Eyebeams... -
Page 12: Before You Begin (Power Options & Solar Panel)
Before You Begin POWER OPTIONS 1. Determine Charging Option for Battery: Transformer OR Solar NEVER USE TRANSFORMER AND SOLAR PANEL(S) AT THE SAME TIME. It will damage the control board. IMPORTANT • Transformer is suitable for outdoor use. Use 2.5m x 2 core cable •... -
Page 13: Proper Gate Installation
IMPORTANT: Check For Proper Gate Installation • The gate must be plumb, level, and swing freely on its hinges. • The gate must move throughout its arc without binding or dragging on the ground. • A properly leveled gate will not have the tendency to self-open or self-close and remain sta- tionery. -
Page 14: Installation Pointers & Cardboard Template
Installation Pointers The proper position of the Primary and Secondary Brackets (post bracket) and gate bracket is crucial to the efficiency and leverage of the gate opener. Attention needs to be paid to both its correct height and its position on the post in respect to the relationship between your gate hinge pivot point and the motor pivot point on the bracket. -
Page 15: Installatioin Of Gate Opener
Installation of Gate Opener Primary and Secondary Post Brackets The position of the Primary and Secondary post brackets are crucial to the success of your installation and attention needs to be paid to both correct height and position on the post in respect to the relationship between your hinge pivot point and the motor pivot point on the bracket. -
Page 16: Installing The Gate Stop
Installing the Gate Stop Double Gates Installing the rubber gate stop is required GATE TABS FOR DOUBLE GATES to ensure proper alignment of the two gates and for them to have a solid push onto the stopper in the full-cosed position. Single Gates The gate should either stop onto a post in the closed position, or you can use... -
Page 17: Pull-To-Open Setup
Pull-to-Open Setup Actuator on the inside of the property with the gate pulling in to open Long Step1. Template Position the template on the ground approximately where the arm is to be installed with the short length in the fully open position and the long length at the fully closed position. - Page 18 Pull-to-Open Setup Actuator on the inside of the property with the gate pulling in to open Step 4. Ensure that there is sufficient angle (more than 5 degrees) non parallel between the template and the gate. It is important that in both the full open and full close positions, the arms must not be parallel to the gate.
- Page 19 Pull-to-Open Setup Actuator on the inside of the property with the gate pulling in to open • Check your J & K measurements. • Pivot point should be worked out from template now • Open the gate to 90 degrees •...
-
Page 20: Push-To-Open Setup
Push-to-Open Setup Actuator on the inside of the property with the gate pushing outwards You may require the longer secondary bracket for this setup (see optional extras page 9) Step1. Position the template on the ground approximately where the pivot point of the arm is to be installed with the long length in the fully open position and the short length at the fully closed position. - Page 21 Push-to-Open Setup Actuator on the inside of the property with the gate pushing outwards Step 4. Ensure that there is sufficient angle (more than 5 degrees) non parallel between the template and the gate. It is important that in both the full open and full close positions, the arm must not be parallel to the gate.
- Page 22 Push-to-Open Setup Actuator on the inside of the property with the gate pushing outwards Setup shown with Post Brackets on the back of the gate post 2 possible mounting positions for the post bracket for push to open gates • Back of post •...
- Page 23 Push-to-Open Setup Actuator on the inside of the property with the gate pushing outwards Round Gate Bracket Installation Optional extra if ordered with the kit to suit farm gates Round Gate Bracket Standard Gate Bracket Photos above for illustration purposes only - round gate bracket examples...
-
Page 24: Transformer Wiring Installation
Transformer Wiring Installation The Transformer can be relocated up to 50mtrs from the control box. You MUST install the transformer via a RCD to avoid injury from shock as per local government electrical requirements. Always switch off mains power when any work is being carried out on or around the gate installation. - Page 25 Transformer Wiring Installation SINGLE AND DOUBLE WIRING SETUP Battery Do not adjust dial at top of board - it’s for battery charging voltage 8 Dip switch settings see page 28 Safety Beams Light (Remove wire) For single arm Sensor + Red use only Motor A - Black and DIP 5 ON...
-
Page 26: Solar Wiring Installation
Solar Wiring Installation Connection of Power Source (Solar) The system can be solar powered via an optional solar system with 12V voltage regulator connected directly to the battery. Do NOT use both solar and mains power at the same time. The Solar panel must face FULL NORTH with the recommended tilt from your wiring diagram booklet and within 10m of the battery. - Page 27 Solar Wiring Installation SINGLE AND DOUBLE WIRING SETUP Battery Do not adjust dial at top of board - it’s for battery charging voltage 8 Dip switch settings see page 28 Safety Beams Light (Remove wire) For single arm Sensor + Red use only Motor A - Black and DIP 5 ON...
-
Page 28: Control Board - D1
Control Board - D1 The E8 D1 control board is specially designed to match 12Vdc arm gate motors. The electronic panel requires no maintenance as long as the gate operates in proper order and is kept dry and insect free. Mount the control box as close to the actuator arm (maximum 10m cable) as possible connected with minimum .66mm 2 core electrical cable to reduce any voltage drop which will affect the performance of the system. -
Page 29: Setting Up The System - Single Gate
Setting up the System Single Gate Setup Set DIP switch 5 to the ON position and connect the arm motor wires to MT A terminals DO NOT connect the arm motor wires to MT B. Receiver - Connect both receiver wires together (orange & brown) and place into the far right terminal [1SIDE]. -
Page 30: Setting Up The System - Double Gates
Setting up the System Double Gates Setup Make sure DIP switches are all set to the OFF position and connect the arm motor wires to MT A and MT B terminals. Receiver - Connect both receiver wires together (orange & brown) and place into terminal [2SIDE]. -
Page 31: Remote Controls & Receiver
Remote Controls and Receiver Remote Controls: The 12Vdc remote transmitter contains 2 signals represented by button 1 and button 2 on your remotes. Confirm with the owner which function they want for each of the buttons. Double gate setup button #1 can be set as a single gate operation while button #2 is set as double gate operation. -
Page 32: Other Considerations
Other Considerations Gate Stop must be installed in the centre of the driveway for double gates to close up onto and apply solid pressure. Arm Condensation Drain Hole: Always mount arms with condensation drain holes facing down or water will enter the motor and damage the electrics voiding the warranty. This is indicated on your arm with the “THIS SIDE DOWN”... -
Page 33: External Light Connection
External Light Connection NOT for Solar Power Setup The D1 control board has a 12Vdc output on the Lamp Relay Terminal. Left terminal is negative and right is positive. This output is to energise an EXTERNAL 12Vdc relay which in turn can be used to turn on/off a higher rating electrical item such as a Pillar Light. -
Page 34: Trouble Shooting
Trouble Shooting Problem: The gate does not travel smoothly when opening or closing. Solution: • Ensure there is no obstrucion to the movement of the gate such as hitting the ground. This can be verified by releasing the gate to emergency release mode. Manually swing the gate open/close to detect any tight spots. -
Page 35: Other Accessories
OTHER ACCESSORIES Long Range Receiver TO PROGRAM REMOTES TO THE RECEIVER Step 1: press and hold remote button that is to trigger the opener. It is important that this button is contin- uously held from step 1 through to step 3. Step 2: place the jumper over the two LEARN pins on the PC Board for 2 seconds. -
Page 36: Photocells/Eyebeams -Wired
Photocells/Eyebeams - Wired INSTALLATION The best installation height should be more than 20cm Installation distance should be not less than 1m The infrared protection device should be vertically placed and in the same horizontal line Install the receiver and than the transmitter (when they are in a straight line, the OFF light of the receiver goes out) AVOID DIRECT SUNLIGHT... -
Page 37: Keypad - Wired
Keypad - Wired After wiring your keypad, check that it’s operational by entering the 4 digit factory code 2580. If you have double gates you will need to follow the setup noted below Double gate setup. Once gate/s are working with the factory code you can then move onto entering a new pin code/s. -
Page 38: Keypad - Wireless
Keypad - Wireless Enter a pin code (4 digits) into keypad Enter program mode = 0 0 0 0 * Enter channel = 0 1 # Enter your pin code = ? ? ? ? # (pin code now entered) Pairing receiver to keypad Press P1 on the receiver board (red LED will go solid) Enter your pin code = ? ? ? ? # (red LED will flash to say keypad and receiver are paired) -
Page 39: Gate Lock - Double Setup
Electric Gate Lock WHITE BLUE... -
Page 40: Gate Lock - Single Setup
Electric Gate Lock... -
Page 41: Other Information
The complete system should be tested weekly and imme- diately after a break-in, an attempted break-in, fire, storm, earthquake, accident, or any kind of construction activity inside or outside the premises. PLEASE VISIT OUR WEBSITE FOR TERMS AND CONDITIONS WWW.BMGI.COM.AU... -
Page 42: Installer & Owner Notes
Installer & Owner Notes...
Need help?
Do you have a question about the E8-400 and is the answer not in the manual?
Questions and answers
How to unlock / disarm the e8 gate with the release key? where is the lock located on the arm?
To unlock or disarm the BMGi E8-400 gate with the release key:
1. Insert the release key into the release bolt.
2. Unscrew the release bolt fully.
3. Pull the actuator arm off the gate bracket.
4. The gate will now swing freely.
The lock (release bolt) is located on the actuator arm. If leaving the actuator arm off the gate, disconnect the power to prevent motor or cable damage.
