CTM3: Manual Changing Table
Installation instructions
The wall must be of solid construction and load bearing, capable of
•
supporting 250 kg
Maximum Working Load of Changing Table. (MWL):150 kg
•
Select the correct Anchors before installation,
•
DO NOT ATTEMPT TO INSTALL USING PLASTIC WALL PLUGS AND
WOODSCREWS
Please Note: Due to the complexity of different building methods
•
Astor Bannerman does not supply installation fixings and anchors
N.B The Changing table cannot be installed on a Gypframe™
•
wall with metal studs
Advice for safe Installation
Version 5 03/2023
Advertisement
Related Manuals for Astor-Bannerman CTM3
Summary of Contents for Astor-Bannerman CTM3
- Page 1 CTM3: Manual Changing Table Installation instructions Advice for safe Installation The wall must be of solid construction and load bearing, capable of • supporting 250 kg Maximum Working Load of Changing Table. (MWL):150 kg • Select the correct Anchors before installation, •...
- Page 2 CTM3 Change Table Installation Position Stud Walls with wood supports Noggins. For partition walls, reinforce with 2off noggins made from two pieces of 4" x 2" placed back to back, screwed (not Nailed) in place N.B picture shows optional guard rail...
- Page 3 CTM3 Change Table Advised installation position Bolts are 8mm Diameter Coach Screw (75mm long.) Through Anchor Rawl Bolt (shield anchor) To release the bed pull the black knob outwards Version 5 03/2023...
- Page 4 6. For fixing to ply only. Drill full depth pilot holes at all 4 marked positions. (8MM Ø Coach screws are usually used for plywood). 7. Fit the CTM3 frame onto the wall and secure. The Elephant Works, Andoversford Link, Cheltenham, GL54 4LB Tel 01242 820820 email: info@astorbannerman.co.uk www.astorbannerman.co.uk...
