iLive IBB503GEO User Manual

Watts Plus Portable Bluetooth Boombox
User's Guide for Model IBB503GEO v3139-01
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding - type plug.
A polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
FCC Warnings
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
Features
• Bluetooth 5.0 – range 49 ft.
• FM scan radio
• 3.5mm Aux In
• MicroSD slot and USB port
• 2 microphone inputs
• Carry handle
• Rechargeable battery
Includes
• User's guide
• AC/DC power adapter
• 3.5mm audio cable
• Removable shoulder strap
Controls and Functions
1. Previous Track/Channel: In Bluetooth/External Media
mode, press to select the previous track. In FM Radio
mode, after completing a full station search, press to select
the previous station.
2. Play/Pause/Pair/Scan:
- In Bluetooth/External Media mode, press to play/
pause tracks.
- In Aux In and FM Radio mode, press to mute and
unmute volume.
- In External Media mode, press and hold to select one
of four playback sequences.
- In FM Radio mode, press and hold to perform a full
station search.
- Press and hold to manually enter pairing mode.
3. Next Track/Channel: In Bluetooth/External Media mode,
press to select the next track. In FM Radio mode, after
completing a full station search, press to select the next
station.
4. LED Screen: Displays source/EQ information.
5. Source: Press once to switch between External Media/Aux/
Bluetooth/Radio modes. Press and hold to switch between
a source MP3 folder and a recording MP3 folder. Press and
hold for 5 seconds to turn Voice Prompts on/off.
Record/Delete: Press to start recording. Press again to
6.
finish recording. Press and hold to delete a recording. Note:
When recording, the Echo knob should be turned all the
way down.
Lights: Press to turn RGB lights in speakers on/off
7.
8. Equalizer: In Bluetooth/External Media mode, press to
switch between audio equalizer presets: Normal, Pop,
Rock, Jazz, Classical, Cut, Club.
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus from the
mains completely, the mains plug should be disconnected from the mains
socket outlet completely.
• WARNING: Shock hazard - Do Not Open.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specified may result in hazardous radiation exposure.
• WARNING: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces with
any type of soft, porous, or sensitive finish. As with any rubber compound
made with oils, the feet could cause marks or staining where the feet reside.
We recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.
• WARNING: Do not ingest battery, chemical burn hazard.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the
like.
• Lithium batteries, like all rechargeable batteries, are recyclable and should be
recycled or disposed of according to state and local guidelines. They should
never be disposed of in normal household waste, and they should never
be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.
Overview
1
9
10
11
12
9. DC Power Input: Plug in the Power Cord to charge the unit.
10. Indicator LED: When charging, the LED will display a RED light. When
finished charging, the LED will turn off.
11. MicroSD Slot: Supports MicroSD cards up to 32G (FAT32 format).
12. Echo +/-: Adjust microphone echo/reverberation.
13. Aux In (3.5mm Input): 3.5mm input jack.
14. USB Input: Supports USB Drives up to 32G (FAT32 format).
15. Power On/Off: Power speaker ON/OFF.
16. Volume +/-: Adjust playback volume.
17. Microphone Input 1: Microphone input jack.
18. Microphone Volume +/-: Adjust microphone volume.
19. Microphone Input 2: Microphone input jack
Note: Voice prompt volume is set to a default level. To avoid loud start up voice
prompts, turn down the volume before powering on the unit.
WARNING: To reduce the risk of electric
CAUTION
shock, do not remove cover (or back). No
RISK OF ELECTRIC SHOCK
DO NOT OPEN
user-serviceable parts inside. Refer servicing to
ATTENTION
qualified service personnel.
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
This symbol indicates that this product
incorporates double insulation between hazardous
mains voltage and user accessible parts.
WARNING: This product can expose you to
chemicals including lead, which is known to the
State of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
This product meets and complies with required
Federal product guidelines.
2 3 4 5 6 7
17 18 19
8
13
14
15
16
