Warnings and Precautions TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. This symbol, located on back or bottom of the unit, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Important Safety Instructions 1. Read these instructions. All the safety and operating instruction should be read before the product is operated. 2. Keep these instructions. The safety and operating instruction should be retained for future reference. 3. Heed all warnings. All warning on the product and in the operating instructions should be adhered to.
Page 4
Video Out Connection Guide From Unit Connect to the video output connection. • Be sure to select the appropriate Video Input on the Television set. Viewing Video or Photos from your iPod on an External Device a. Using a video cable, connect an external device such as a TV to the Video Out port on the player. b.
Page 5
Audio In Connection Guide From Unit Connect to the Aux In or Line In jack. • The unit must be set to AUX in order for the external audio device to play through the unit’s speakers. Connecting Other Digital Audio Devices a.
Page 7
Features Defined DBBS Press the DBBS button to activate the Dynamic Bass Boost System. DBBS Indicator Indicates when the DBBS is activated. VOLUME Press the up arrow to increase the volume, and the down arrow to decrease volume. POWER Press the POWER button to turn the player on. LCD Display View the Time, AM Indicator, PM Indicator, iPod Indicator, Radio Frequency, and CD Indicator (“--”) through this Liquid Crystal Display.
Page 8
Peripherals iPod Inserts Bracket # iPod Model/Capacity iPod nano (first generation) iPod nano (second generation) iPod mini GB & GB iPod with video 30GB (fifth generation) iPod (fourth generation), iPod photo 0GB & 0GB, and iPod : U Special Edition 0GB iPod with video 60GB &...
Page 9
Peripherals Defined 24 MENU/PROG Press the MENU/PROG button to enter the menu on an iPod. 25 SHUFFLE Press the SHUFFLE button to randomly play songs on an iPod. 26 CHAPTER Press up on the CHAPTER button to increase the chapter number, or press down on the CHAPTER button to decrease the chapter number.
Operations Setting the Clock a. Press and hold the CLK SET button. b. While holding the CLK SET button, press the PREV/SEARCH/HR. button to cycle up through the hours. Press the NEXT/SEARCH/MIN. button to cycle up through the minutes c. Release the CLK SET button to set the specified time. Listening to the Radio a.
Operations Viewing Video or Photos from your iPod on an External Device a. Using a video cable, connect an external device such as a TV to the Video Out port on the player. b. Insert your iPod with video or photo capabilities into the iPod Docking Station with the appropriate insert.
