Installation, Maintenance,
& User Manual
SS6 SpartanSesh Cube
WARNING
!
Read all precautions and instructions in
this manual before using this equipment.
Save this manual for future reference
and in the event that the manufacturer
has to be contacted.
13385 Joy Road
Lusby, MD 20657
Designed for persons 12 years & older.
www.swingsesh.com
Maximum fall height: 10'-7"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SpartanSesh Cube SS6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SwingSesh SpartanSesh Cube SS6

  • Page 1 Save this manual for future reference and in the event that the manufacturer has to be contacted. 13385 Joy Road Lusby, MD 20657 Designed for persons 12 years & older. www.swingsesh.com Maximum fall height: 10’-7”...
  • Page 3: Table Of Contents

    If any parts or components arrive damaged, we will do our best to provide a repair kit or replace- ment parts as soon as possible. Customer Care: 1-301-247-2881 Please save this manual in the event that you need to contact SwingSesh. WARNING WARNING Read this manual prior to assembling and This product must be anchored.
  • Page 4: Before You Begin Installation

    Your SwingSesh comes equipped with warnings and instructions for assembly, care, maintenance, and use. This information must be read by all SwingSesh supervisors and communicated to or read by all users before any person is allowed to use a SwingSesh.
  • Page 5: Surfacing Materials

    w w w . s w i n g s e s h . c o m Surfacing Materials The following information is from Section 4 of the United States Consumer Product Safety Commission’s (USCPSC) Outdoor Home Playground Safety Handbook for playground surfacing material. This guide to home playground safety can be downloaded at https://www.cpsc.gov/s3fs-public/324.pdf.
  • Page 6: Safety Precautions

    Installation, Maintenance, & User Manual Safety Precautions It is the responsibility of the owner and supervisors of this equipment to make sure all users obey the safety instructions printed in this manual. This product is intended for use by children and adults twelve years of age and over. Use this equipment only as described in this manual.
  • Page 7: Maintenance Information

    w w w . s w i n g s e s h . c o m Maintenance Checklist Maintenance Checklist At the beginning of play season: Date: _________ □ Tighten all hardware, including earth anchors. □ Lubricate swing pendulums. □...
  • Page 8: Assembly Instructions

    Installation, Maintenance, & User Manual Assembly Instructions • Before you begin assembly, ensure your selected site has adequate clearance for the safety zone and prepare a level surface. Two adults needed to assemble. It will be very difficult to move your SwingSesh once assembled, so it is important to place the feet in their intended assembled location during installation. • Assemble all parts on a non-scratch surface to prevent damaging the finish.
  • Page 9: Parts Identification

    w w w . s w i n g s e s h . c o m Steel Parts Identification POSTS Holed Post 8ft Climbing Wall Post Spartan Beam Cantilever Tube Ring Bar Climbing Wall Bracket BARS Pull Up/Lache Bar Monkey Bar Rungs Braced Rungs Components 8’x8’...
  • Page 10: Hardware

    Installation, Maintenance, & User Manual Hardware (Shown actual size) 1”-8 HARDWARE 16 x 4 1/2” bolts 16 x nuts narrow washers 16 x split lock regular washers washer 5/16”-18 HARDWARE 28 x 3 1/4” bolt 5/16” washers 5/16” split lock washers 28 x 5/16” nuts...
  • Page 11 w w w . s w i n g s e s h . c o m Cantilever Hardware 3/8”-16 HARDWARE 1 Cantilever Lane (2 Cantilever Lanes) 4 (8) x 3 3/4” bolt 8 (16) 3/8” washers 4 (8) x 3/8” nuts 4 (8) 3/8” split lock washers 1”-8 HARDWARE...
  • Page 12 Installation, Maintenance, & User Manual Climbing Wall 5/16”-18 HARDWARE 4’x8’ Wall (8’x8’ Wall) 28 (56) 1 1/4” bolt 8 (11) 3 1/2” bolt 72 (134) 5/16” washers 8 (11) x 5/16” nuts 36 (67) 5/16” split lock 28 (56) x 5/16” cap nuts washers 1”-8 HARDWARE 4 (8) x 4 1/2” bolts 8 (16) x washers 4 (8) x...
  • Page 13 w w w . s w i n g s e s h . c o m Climbing Net 8x8’ Hardware stainless steel snap hooks stainless steel ring with cross bar...
  • Page 14 Installation, Maintenance, & User Manual STEP 1 Monkey Bars PARTS REQUIRED: HARDWARE REQUIRED: 31/4” bolts (5/16”-18), 2 washers, lock washer, nut x2 Spartan Beam 41/2” bolts (1”-8), 2 regular washers, lock washer, nut x4 Double Rungs 41/2” bolts (1”-8), 1 regular washer, 1 narrow washer, lock washer, nut x2 Posts with 1-in Holes x2 Braced Ladder STEP 1a...
  • Page 15 SP6 aligns with the fourth hole of the AH Post. Note the direction of the feet on the AH Posts; if attaching to another SwingSesh model, all feet must align in the same direction as the existing set.
  • Page 16 Installation, Maintenance, & User Manual STEP 2 (Continued) STEP 2b • Align the two assembled SP6-AH from Step 2a in their respective places adjacent to the previously assembled Monkey Bar assembly from Step 1. On each side, rotate the SP6-AH assembly ninety degrees into position and on top of the AH Post on the ground.
  • Page 17 w w w . s w i n g s e s h . c o m STEP 2c • Using two (2) 4 1/2 inch bolts on each side, bolt the SP6 Cantilever Beam to the bottom AH Post and hand tighten. •...
  • Page 18 Installation, Maintenance, & User Manual STEP 3 Assemble the Opposite Side PARTS REQUIRED: HARDWARE REQUIRED: 41/2” bolts (1”-8), 1 regular washer, 1 narrow washer, lock washer, nut x2 Cantilever Tube 31/2” bolts (3/8”-16), 2 washers, lock washer, nut x2 Posts with 1-in Holes x1 Spartan Beam x1 Ring Bar STEP 3a •...
  • Page 19 w w w . s w i n g s e s h . c o m STEP 4 Attach Lache Bars PARTS REQUIRED: HARDWARE REQUIRED: 31/4” bolts (5/16”-18), 2 washers, lock washer, nut x3 Lache Bars 31/2” bolts (5/16”-18), 2 washers, lock washer, nut x1 Climbing Wall Post • Insert the three C9 Lache Bars between the two SP3 Beams and bolt together using 3 1/4” long (5/16”-18) bolts.
  • Page 20 Installation, Maintenance, & User Manual STEP 5 Assemble Climbing Walls PARTS REQUIRED: HARDWARE REQUIRED: 31/2” bolts (5/16”-18), 2 washers, lock washer, nut x10 Climbing Wall Brackets 41/2” oversized bolt, 2 washers, lock washer, nut Climbing Wall Panels 11/4” bolts (5/16”-18), 2 washers, lock washer, nut Climbing Wall Holds STEP 5a • The climbing walls can be installed on either side of the SpartanSesh Cube or Adult Monkey Bars. If attaching to a larger system, the side the wall is placed on may be specified.
  • Page 21 w w w . s w i n g s e s h . c o m STEP 5b STEP 5c • Attach the Climbing Wall Panels to the SP8 • On the back side of the wall, align the remaining two SP8 Brackets using 1 1/4”...
  • Page 22 Installation, Maintenance, & User Manual STEP ? STEP 6 Assemble the Climbing Net PARTS REQUIRED: HARDWARE REQUIRED: Climbing Net 8’x8’ Snap Hooks 25’ section of 550 cord Rings with cross bar STEP 6a: Attach the Snap Hooks to the Net & Hang •...
  • Page 23 w w w . s w i n g s e s h . c o m STEP 6c: Attach the Net to the Post Using Cord Align the ring to first horizontal loop of the net, which is approximately the fourth hole from the top of the post on the outside of the AH post.
  • Page 24: Limited Warranty & Return Policy

    Please note that shipping charges are non-refundable. If products were shipped with free shipping the refund for the product will be less the actual shipping costs. SwingSesh reserves the right to reject any return that does not meet the return standards and may...
