SwingSesh SlimSesh SS2 Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Installation, Maintenance,

& User Manual

SlimSesh

Models SS2, SS2-SL, SS2-MB, SS2-SL-MB

WARNING

Read all precautions and instructions

in this manual before using this equip-

ment. Save this manual for future

reference and in the event that the

manufacturer has to be contacted.

13385 Joy Road

Lusby, MD 20657

Maximum fall height: 8'-2"

www.swingsesh.com

SUITABLE FOR USERS AGE 5+

Table of Contents

Need help?

Do you have a question about the SlimSesh SS2 and is the answer not in the manual?

Questions and answers

Summary of Contents for SwingSesh SlimSesh SS2

Page 1 Save this manual for future reference and in the event that the manufacturer has to be contacted. 13385 Joy Road Lusby, MD 20657 Maximum fall height: 8’-2” www.swingsesh.com SUITABLE FOR USERS AGE 5+...
Page 3: Table Of Contents
If any parts or components arrive damaged, we will do our best to provide replacement parts as soon as possible. Customer Care: 1-301-247-2881 Monday - Friday, 8am-5pm EST Please save this manual in the event that you need to contact SwingSesh. WARNING WARNING Read this manual prior to assembling and This product must be anchored.
Page 4: Before You Begin Installation
Your SwingSesh comes equipped with warnings and instructions for assembly, care, maintenance, and use. This information must be read by all SwingSesh supervisors and communicated to or read by all users before any person is allowed to use a SwingSesh.
Page 5: Playground Surfacing Materials
w w w . s w i n g s e s h . c o m Playground Surfacing Materials The following information is from Section 4 of the United States Consumer Product Safety Commission’s (USCPSC) Outdoor Home Playground Safety Handbook for playground surfacing material. This guide to home playground safety can be downloaded at https://www.cpsc.gov/s3fs-public/324.pdf.
Page 6: Safety Precautions
Installation, Maintenance, & User Manual Safety Precautions It is the responsibility of the owner and supervisors of this equipment to make sure all users obey the safety instructions printed in this manual. This product is intended for use by children and adults five years of age and over. Use this equipment only as described in this manual. Children should only use the equipment under adult supervision.
Page 7 w w w . s w i n g s e s h . c o m Maintenance Checklist At the beginning of play season: Date: _________ □ Tighten all hardware, including earth anchors. □ Lubricate swing pendulums. □ Check all moving parts including swing seats and chains for wear, rust, or other deterioration. Replace as needed. □...
Page 8: Assembly Instructions
Installation, Maintenance, & User Manual Assembly Instructions • Before you begin assembly, ensure your selected site has adequate clearance for the safety zone and prepare a level surface. Two adults needed to assemble. It will be very difficult to move your SwingSesh once assembled, so it is important to place the feet in their intended assembled location during installation. • Assemble all parts on a non-scratch surface to prevent damaging the finish.
Page 9 . s w i n g s e s h . c o m Determine Your Preferred Configuration • SwingSesh equipment is designed to be modular and can be configured in different ways. Before you begin installation, determine your preferred configuration. Slide between CONFIGURATION 1 Posts A7 & A8 Directions are written for this configuration, follow accordingly. Monkey Bars between Posts A9 &...
Page 10: Tools Required
Installation, Maintenance, & User Manual Tools Required 1 x 1/2” open end wrench & 1/2” open 1 x ratchet with end wrench 1/2” socket 1/2” drive ratchet 1 x 9/16” open end wrench & (for earth anchors) 1 x 3/4” open end wrench (for swing bolts & nuts) 1 1/2” open end wrench 24” level Tape measure Ladder or step ladder...
Page 11: Steel Parts Identification
w w w . s w i n g s e s h . c o m Steel Parts Identification A10L POSTS Post 2ft RAILING & BARS Post 2ft Post 8ft Dip Bar 1 Post 8ft Ladder MONKEY BARS DECKING Post 8ft Stair Railing Post 8ft...
Page 12: Hardware
Installation, Maintenance, & User Manual Hardware (Shown actual size) 5/16” washers 1” bolts 5/16” split lock washers 69 x 5/16” nuts 2 1/2” bolts 78 x 3/8” plugs 3 1/4” bolts 3 1/2” bolts 2 1/2” carriage bolts Monkey Bars Hardware 5/16” washers 3 1/4” bolt 5/16” split lock washers 3 1/2” bolt 34 x 5/16” nuts Slide Hardware 5/16” washers 1 3/4” bolts 5/16” split lock washers 5/16” nuts...
Page 13 w w w . s w i n g s e s h . c o m Upgraded Holed Posts Hardware 4 1/2” bolts washers split lock washers nuts...
Page 14 Installation, Maintenance, & User Manual STEP 1 Front Ladder Wall Sub-Assembly PARTS REQUIRED: HARDWARE REQUIRED: Post 31/4” bolt, 2 washers, lock washer, nut Post Ladder Split Railing • Lay Posts A5 and A8 on the ground with feet facing up. •...
Page 15 w w w . s w i n g s e s h . c o m STEP 2 Back Wall Sub-Assembly PARTS REQUIRED: HARDWARE REQUIRED: Post 31/4” bolt, 2 washers, lock washer, nut Post 31/2” bolt, 2 washers, lock washer, nut Configuration Half Railing (or C12 Monkey Bar Railing, if using Split Railing (or...
Page 16 Installation, Maintenance, & User Manual STEP 3 Play Deck Assembly PARTS REQUIRED: HARDWARE REQUIRED: Front Ladder Wall Assembly (Step 1) 31/4” bolt, 2 washers, lock washer, nut C6 A9 Back Wall Assembly (Step 2) 31/2” bolt, 2 washers, lock washer, nut Large Play Deck Configuration 2 Configuration...
Page 17 w w w . s w i n g s e s h . c o m STEP 3b • With a second adult holding the Front Ladder Wall Assembly (from Step 1) upright, stand up the Back Wall and Play Deck Assembly and use two (2) 31/4”...
Page 18 Installation, Maintenance, & User Manual STEP 4 Pull Up Bars Sub-Assembly PARTS REQUIRED: HARDWARE REQUIRED: Post 31/4” bolt, 2 washers, lock washer, nut Post Pull Up Bar Braced Bar • Lay Posts A4 and A7 on the ground with feet facing up. •...
Page 19 w w w . s w i n g s e s h . c o m STEP 5 Attachment of Pull-Up Bar Assembly PARTS REQUIRED: HARDWARE REQUIRED: Half Rail (3 brackets) 1” bolt, 2 washers, lock washer, nut A3 C8 Pull-Up Bar Assembly (Step 4) 31/4”...
Page 20 Installation, Maintenance, & User Manual STEP 6 Stair Climber Assembly PARTS REQUIRED: HARDWARE REQUIRED: WHEN INSTALLING MONKEY BARS USE: Post Monkey Bar Post 1” bolt, 2 washers, lock washer, nut Post A10L Monkey Bar Post 31/4” bolt, 2 washers, lock washer, nut Half Railing (4 brackets) Monkey Bar Railing 31/2”...
Page 21 w w w . s w i n g s e s h . c o m STEP 6c STEP 6d • Attach Stair Climber B3 to Small Deck B4 using two (2) 1” bolts. • Attach Stair Safety Triangle •...
Page 22 Installation, Maintenance, & User Manual STEP 7 Box Jump Assembly PARTS REQUIRED: HARDWARE REQUIRED: Post 31/4” bolt, 2 washers, lock washer, nut Post 21/2” bolt, 2 washers, lock washer, nut Small Box Jump Large Box Jump/Lower Deck STEP 7a • Place B2 on a non-scratch surface with the punched hole decking face down.
Page 23 w w w . s w i n g s e s h . c o m STEP 7c • Align Small Box Jump B1 to Posts A1 and A2 . • Attach Small Box Jump B1 to Post A1 using one (1) 31/4” bolt. •...
Page 24 Installation, Maintenance, & User Manual STEP 8 Dip Bar Assembly PARTS REQUIRED: HARDWARE REQUIRED: x2 Dip Bar 21/2” carriage bolt, washer, lock washer, nut • Align Dip Bar 1 C1 to Small Box Jump B1 and to Large Box Jump B2 . Bolt Dip Bar 1 C1 to Small Box Jump B1 using two (2) 21/2”...
Page 25 w w w . s w i n g s e s h . c o m STEP 9 Slide Assembly PARTS REQUIRED: HARDWARE REQUIRED: Slide 13/4” bolt, 2 washers, lock washer, nut • Bolt Slide D1 to Large Deck B5 using three (3) 13/4” bolts and tighten using wrenches. 13/4”...
Page 26 Installation, Maintenance, & User Manual STEP 10 Monkey Bars Assembly PARTS REQUIRED: HARDWARE REQUIRED: x2 Monkey Bar Post 31/4” bolt, 2 washers, lock washer, nut x2 Monkey Bar Horizontal Support 31/2” bolt, 2 washers, lock washer, nut x7 Monkey Bar Rungs STEP 11a STEP 11b •...
Page 27 w w w . s w i n g s e s h . c o m STEP 11c • Align the A14 and A15 Assemblies from the previous Step 11b perpendicular to one another as shown. • Bolt the two (2) Monkey Bar Posts A14 to both A15 using four (4) 31/4”...
Page 28 Installation, Maintenance, & User Manual STEP 11 Insert Earth Anchors PARTS REQUIRED: Earth Anchors (quantity varies depending on model features) NOTE: If installing other attachments, such as a Climbing Extension, please review those instructions at this point for installation. A4 A5 •...
Page 29 w w w . s w i n g s e s h . c o m...
Page 30 Please note that shipping charges are non-refundable. If products were shipped with free shipping the refund for the product will be less the actual shipping costs. SwingSesh reserves the right to reject any return that does not meet the return standards and may...
