- Page 1 User Manual 125kHz RFID Standalone Access Controller SecureEntry-AC900LF...
-
Page 2: Table Of Contents
Table of contents Specifications: ................................3 Set contents: ................................... 4 Features: .................................... 4 Defaults ....................................5 Light and sound signals ............................5 Connection Instructions ............................6 Detailed programming instructions ......................8 Reset the programming password ....................... 10 How to use the admin tab ............................ 11 What is a user ID number ............................ -
Page 3: Specifications
Specifications: • Warranty: 1 year • Device Type: Standalone Access Controller • Verification Type: RFID Card, Password • Operating frequency: 125 kHz • Max number of employees in the base: 1000 • Reading distance: 5 – 15 cm • Keyboard and keys: touch •... -
Page 4: Set Contents
Set contents: • Standalone Access Controller • Manual Features: • Can be connected directly to the electronic lock and doorbell • Verification via RFID card and password • 125 kHz operating frequency and DC12V operating voltage... -
Page 5: Defaults
Defaults Shared 123456 access lack Password password Relay Backlight Automatic Unlocking 5 seconds Output Wiegand 26 Input Safe Mode disabled Access card or password An access password includes a private Opening access password (PIN) and a shared access Mode password Light and sound signals Light Signal: Red and Green Description of the light signal... -
Page 6: Connection Instructions
Horn: buzzer Description Access Control Status 1 short beep Valid input 3 short beeps Invalid input 1 long beep Operation success A continuous, long beep Restoring Factory Programming Passwords Connection Instructions Lp. Designation Colour Function +12V Power + Black Power- PUSH Blue Low Output Signal... - Page 7 Connection diagram Remark: If the relay has an electrical interlock, the "+" and "-" poles of the interlock must be connected in reverse.
-
Page 8: Detailed Programming Instructions
Detailed programming instructions Basic functions Operation to be Purpose Comments performed Changing the # Programming If you lose the programming password # 0 new programming password programming password, use the password # default password (123456) Add a user card # Programming If you want to add password #1 card several cards, read... - Page 9 Add a private access # Programming There can be many PIN password (PIN) password # 22 PIN # codes Add a card by entering # Programming The card number is 10- the card number password #23 enter digit or 8-digit card number # Adding multiple cards # programming...
-
Page 10: Reset The Programming Password
Setting the safety # programming XX can be 01/02 (safety function password # 7 XX # function OFF/ON) and 03/04 (distance alarm Anti-disconnection OFF/ON). alarm setting Note: Enabled security feature means that the system will be locked for 5 minutes if it reads an unregistered card or the wrong access password is entered 10 times Backlight Setting... -
Page 11: How To Use The Admin Tab
• Turn off the power, unplug container 2 and 3, and connect container 1 and 2 RST. • Turn the power back on. How to use the admin tab To add a standby user card, follow these steps: Read admin card read new card reread admin card To remove a standby user card, follow these steps: Read admin card read registered card reread admin card To remove all standby users, follow these steps:...
