- Page 1 User Manual RFID Card Access Control System SecureEntry-AC100...
-
Page 2: Table Of Contents
Table of contents Specifications: ................................3 Set contents: ................................... 4 Features: .................................... 4 Device description ..............................5 Starting the device ..............................5 Entering Programming Mode ..........................6 Function settings ................................. 6 Wiring ....................................9... -
Page 3: Specifications
Specifications: • Warranty: 1 year • RFID Card Supported: 125 kHz • Type: Outdoor Access Control System • Interface: Wiegand 26/ Wiegand 34 • Additional Features: Wired Doorbell Control, Wiegand Output, Access Control, Switch Control • Verification Type: RFID Card, Password •... -
Page 4: Set Contents
Set contents: • Access control system • Screws and mounting plugs • Manual Features: • Ability to verify and control access with RFID card and password • Resistance to water ingress allows the device to be installed as an external access system to the building •... -
Page 5: Device Description
Device description Starting the device Method 1 When the power is off, press and hold the Reset button on the back of the unit, turn on the power for 3 seconds, the unit will beep 3 long and 3 short beeps to let you know that the boot is successful. -
Page 6: Entering Programming Mode
Entering Programming Mode • Press * • Enter the 6-digit programming password, default 123456 • When successfully entered, the LED will illuminate green and there will be two short beeps, and one long beep when unsuccessful. Press * to exit programming mode Function settings Changing the Programming Password •... - Page 7 • Press 3 and enter 0000 • Two short beeps mean successful setting, press * to exit Card Registration • Enter Programming Mode • Press 5 and enter a 3-digit number, then swipe the card • When you enter the 3-digit number, two short beeps will sound, then swipe the card.
- Page 8 Register a card with a master card • In standby mode, drag the main card 3 times within 3 seconds • Enter the 3-digit number, and then swipe the card you want to register. • Two short beeps mean successful setting, press * to exit Tamper alarm setting 1.
-
Page 9: Wiring
the value is set to 00, when you swipe the card or password to open the door, the door will be in the normally open state, and the LED will always be on. Permanent keyboard backlight To turn off the permanent backlight mode: •... - Page 10 2. If the doorbell is 4-record, it needs to be connected to 12V and GND power supply, and the connection method for different doorbells is different. 3. Connect the wires when the power is off, then turn on the power after checking clearly. 4.
