BOTTOM CASE
LCD COVER MODULE
LCD Panel MAIN BOARD
LCD BEZEL
SSD
KEYBOARD MODULE
TOUCH PAD

Components Top View

SPEAKER
BATTERY
THERMAL MODULE ASSY FP TOUCH MODULE
VGA FAN CPU FAN POWER KEY BKT
EDP CABLE
TOUCHPANEL CONTROLLER BD
CAMERA LED SPONGE (Blue mark)
POWER KEY RUBBER
CAMERA AL FOIL (Green mark)
WIFI ANTENNA
TOUCH CABLE
CAMERA ARRAYMIC CR CAM FPC
MIC RUBBER
TP FFC
HINGE L HINGE CAP L
HINGE R
BATTERY BOSS MYLAR
HINGE CAP R
MB FAN ACETATE CLOTH
