- Page 1 2023 ROG Flow X13 (GV302X) Series Service Guide...
- Page 2 LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
- Page 3 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Keep liquids or moisture away from your Notebook PC before installing or removing any components. • Ensure to place your Notebook PC on a stable surface before installing or removing any components.
-
Page 4: Table Of Contents
Table of Contents ⚫ Service Overview ⚫ ASUS ROG Flow X13 (GV302X) Series Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Repair Overview ⚫ Appropriate Tools ⚫ Keyparts and Related Parts ⚫ Disassembly Steps : • BOTTOM CASE •... -
Page 5: Service Overview
Service Overview • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs. • To provide the best service, we have provided the below information for technicians from distributors and resellers to perform the complete device disassembly and assembly. -
Page 6: Asus Rog Flow X13 (Gv302X) Series Overview
ASUS ROG Flow X13 (GV302X) Series Overview Top View Bottom View Cover ❶ Array microphones ❷ Camera or IR Camera ❸ Camera indicator ❹ 360 ͦ - adjustable touch screen panel ❺ Capital lock indicator ❻ Keyboard ❼ Touchpad ❶ Microphone ❶... -
Page 7: Components Top View
Components Top View MAIN BOARD TOUCH PAD EDP CABLE WIFI ANTENNA LCD COVER ASSY CAM FPC CAMERA LCD Panel WIFI CARD SPEAKER POWER KEY FPC TOUCH CABLE (MIC RUBBER) CAMERA LED SPONGE POWER KEY BKT TP FFC BOTTOM CASE ASSY THERMAL ASSY MB MYLAR R THERMAL SSD PAD 2... - Page 8 Components Top View BATTERY TP BD AL FOIL TOP BATTERY GASKET BATTERY CONDUCTIVE CLOTH CPU PHOENIX KAPTON CAMERA AL FOIL TOP SPONGE ST TP BD SPONGE SPK ACETATE CLOTH SCREW ACETATE CLOTH Back...
-
Page 9: Components Bottom View
Components Bottom View LCD Panel KEYBOARD MODULE GV302NF TP GLASS UP ADHESIVE 2 GV302NF TP GLASS UP ADHESIVE 1 LCD ADHESIVE LCD COVER ASSY BOTTOM CASE ASSY TP GLASS DOWN ADHESIVE 1 TP GLASS DOWN ADHESIVE 2 THERMAL MODULE ASSY POWER KEY FPC MAIN BOARD TOUCHPAD... -
Page 10: Repair Overview
Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1. -
Page 11: Appropriate Tools
Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ROG Flow X13 (GV302X) Series notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Pad PTM7958 PLASTIC CARD T=0.35mm... - Page 12 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ROG Flow X13 (GV302X) Series notebook. ❺ ❼ ❶ ❸ ❻ ❷ ❹ Item Part Name Memo ❶ Silicone scraping pen Please store it in the environment of 10 ~ 40 ℃.
-
Page 13: Bottom Case
BOTTOM CASE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove screws *10pcs. Screws Spec Torque (kgf-cm) Step 2 : Use plastic blade to pry the bottom case. M2*8.5L (3.7,0.55) (K) #1 2.0±0.2 M2*7.5L(3.6,0.55) (K) #1 2.0±0.2... -
Page 14: Disconnect Battery Connector
DISCONNECT BATTERY CONNECTOR The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet. -
Page 15: Ssd
The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove the screw *1pc. Screws Spec Torque (kgf-cm) Step 2 : Remove SSD with PAD*2pcs. M2*2L (4.5,0.5) (K) #1| 1.8±0.2 Step 3 : Remove THERMAL SSD PAD 2. Step 4 : Remove THERMA SSD PAD1. - Page 16 The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When installing SSD, please follow the steps below. 1. Align and paste THERMAL SSD PAD 2 on SSD Card at front side. 2. Align and paste THERMAL SSD PAD 1 on SSD Card at rear side, and then install SSD Card into the module slot. 3.
-
Page 17: Battery
BATTERY The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Release SCREW ACETATE CLOTH *3pcs. Screws Spec Torque (kgf-cm) -
Page 18: Wifi Card
WIFI CARD The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Disconnect Antenna cables, and then remove the screw *1pc. Screws Spec Torque (kgf-cm) Step 2 : Remove the WIFI CARD. M2*2L(4.5,0.5) (K) #1 1.8±0.2 Assembly Notice Unscrew(Green circle) &... -
Page 19: Speaker
SPEAKER The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Disconnect the connector *2pcs. Step 2 : Release Mylar and SPK ACETATE CLOTH. Step 3 : Disconnect the connector *1pc. Step 4 : Remove SPEAKER. Disconnect (Yellow mark) Remove * Please refer to above image for the cable connection standard. - Page 20 SPEAKER The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When SPEAKER assembly, please follow the mark below to tidy up SPK cable and ACETATE Cloth SPK ACETATE Cloth Back...
-
Page 21: Power Key(With Main Board、Thermal Module & Fan)
POWER KEY(with Main Board、Thermal Module & Fan) The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Assembly Notice Screws Spec Torque (kgf-cm) Step 1 : Release Acetate Cloth. Step 2 : Remove screws *6pcs. M2*3.5L(4.5,0.5)(K) B-ZN 2.0±0.2 If FFC is damage during disassembly, please replace Step 3 : Disconnect the connector *3pcs. - Page 22 POWER KEY(with Main Board、Thermal Module & Fan) The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When assembly MAIN BOARD, please follow the image below to tidy up cables and paste SPK ACETATE Cloth. ACETATE Cloth SPK ACETATE Cloth *For the Green mark, please keep the white line (On Cable) at the same location.
-
Page 23: Thermal Module & Fan
THERMAL MODULE & FAN The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Release Mylar *3pcs behind Main-board. Screws Spec Torque (kgf-cm) Step 2 : Please follow the reverse screw numbers to remove screws *8pcs, then remove M2*3.5L(4.5,0.5)(K) B-ZN 1.8±0.2 Thermal Module from Main-board. - Page 24 THERMAL MODULE & FAN The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice For CPU FAN assembly, please follow the Before Thermal module assembly, please follow the steps below to rework thermal material and paste ‘WARRANTY VOID’ label. location below to paste MB Mylar R.
-
Page 25: Main Board
MAIN BOARD Mainboard connector placement * Please refer to below image for the cable connection standard. EDP CABLE TOUCH CABLE CPU FAN POWER KEY SPEAKER Supports using JIG BOARD to refresh F1 BIOS. BATTERY KB BL FPC TP FFC VGA FAN K/B FPC Back... - Page 26 MAIN BOARD Materials on mainboard GV302NF X6 GPU DIE ABSORBER (For GV302XI) GV302NF MB MYLAR R 2 GV302NF MB MYLAR UP GV302NF X4 GPU DIE ABSORBER (For GV302XU/XV) GV301RE MB GPU RUBBER (This is for No GPU SKU only) GV302NF MB MYLAR L GV302NF MB MYLAR L 2 GA402XY MB ALS SPONGE GV302NF MB EC MYLAR...
- Page 27 MAIN BOARD Materials on mainboard GV301QE MB BOSS MYLAR GV302NF MB TOP FOAM Back...
-
Page 28: Keyboard Module
KEYBOARD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove screws *2pcs, and then remove TOUCHPAD. Screws Spec Torque (kgf-cm) Step 2 : Disconnect TP FFC. Step 3 : Remove WIFI ANTENNA and Top Battery Gasket. M2*2L (5,0.5) (K) #1 1.8±0.2 Step 4 : Remove screws *4pcs, and release ACETATE Cloth... - Page 29 KEYBOARD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When assembly the KEYBOARD Module, please follow the image When assembly the WIFI ANTENNA, please follow the location below to tidy up cables. below to tidy up cables and paste SPK ACETATE Cloth. ACETATE Cloth When assembly the HINGE on Keyboard Module, please follow the order to tighten screws.
-
Page 30: Lcd Bezel
LCD BEZEL The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Use plastic blade to pry the LCD BEZEL, and then remove it. Move the plastic blade to separate the bezel away Pry the bezel (BEZEL) Start... -
Page 31: Lcd Panel
LCD PANEL The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Pull out LCD adhesive *2pcs. Due to some adhesive (Yellow mark) behind the panel, please separate panel by using plastic Step 2 : Using plastic blade to separate and teardown the panel. blade start from the bottom left and right side. - Page 32 LCD PANEL The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Disconnect TOUCH CABLE and Panel FPC, then separate TOUCHPANEL CONTROL BD and PANEL. Release TP BD AL FOIL Disconnect Release * Please refer to above image for the cable connection standard. (TOUCH CABLE) Remove (TOUCHPANEL CONTROL BD)
- Page 33 LCD PANEL The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When reuse the LCD PANEL or LCD Cover: When assembly the BEZEL: Please use the fingertip to clean the residual adhesive on back side of PANEL Please follow the order below to install and press BEZEL.
- Page 34 LCD PANEL The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When assembly the LCD PANEL: When reuse the LCD COVER: Step 1 : Remove Release paper of LCD Adhesive *9pcs. Please paste below new ADHESIVE *9pcs on LCD COVER. Step 2 : Assembly and align the LCD to the upper side of the LCD Cover.
-
Page 35: Lcd Cover
LCD COVER The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Release the tape, then disconnect the connector to remove EDP Cable. Step 2 : Remove CAM FPC. Step 3 : Remove CAMERA ARRAYMIC CR, MIC RUBBER *2pcs, CAMERA LED SPONGE and CAMERA LED SPONGE R from LCD COVER. Remove Remove (Green mark) (CAMERA LED SPONGE) - Page 36 LCD COVER The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When CAM FPC assembly, please follow the location below to fix FPC. When assembly the HINGE Rubber, please follow the location below to fix Rubber. *Do not cross the upper Frame.
