Daewoo SDA2698 User Manual

Espresso maker with milk frother
Hide thumbs

Advertisement

Table of Contents

Espresso Maker
Model No. SDA2698
User Manual
1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDA2698 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo SDA2698

Summary of Contents for Daewoo SDA2698

  • Page 1 Espresso Maker Model No. SDA2698 User Manual IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
  • Page 2 Espresso Maker Model No. SDA2698 User Manual Contents Page No. Contents Reading and Storing the User Manual Important Safety Instructions for Proper Use Additional Safety Information Explanation of Symbols Description of Parts Before First Use of Your Espresso Maker Instructions for Use - Pre-Heating Your Espresso Maker...
  • Page 3 Espresso Maker Model No. SDA2698 User Manual READING AND STORING THE USER MANUAL Before using this product, please read through this manual carefully paying particular attention to the safety instructions. Failure to do so may result in personal injury or damage to the product.
  • Page 4 Espresso Maker Model No. SDA2698 User Manual knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. • DO NOT leave the appliance unattended during use.

  • Page 5: This Appliance Must Be Earthed

    Espresso Maker Model No. SDA2698 User Manual • DO NOT use any accessories or attachments with this appliance other than those supplied or recommended by supplier. • DO NOT immerse the appliance, base or its cord in water or any other liquids.

  • Page 6: Additional Safety Information

    Espresso Maker Model No. SDA2698 User Manual ADDITIONAL SAFETY INFORMATION • This appliance is intended for use in domestic households only, it must not be used for commercial use. • Hot liquid or steam is emitted from the brewing head and steam nozzle during operation.
  • Page 7 Espresso Maker Model No. SDA2698 User Manual Explanation of Symbols The following warning symbols or words are used in this instruction manual: Products labelled with UK Conformity Assessment identifies products conforming to UK statutory requirements. Products labelled with this symbol conform to applicable provisions of the European Economic Area.
  • Page 8 Espresso Maker Model No. SDA2698 User Manual Description of Parts 1. Coffee Nozzles 2. Power Button 3. Control Panel 4. Brewing Button 5. Steam Button 6. Steam Control 7. Steam Nozzle 8. Water Tank Lid 9. Water Tank 10. Filter Holder Handle 11.
  • Page 9 Espresso Maker Model No. SDA2698 User Manual 13. Warming Plate 14. Coffee Filter holder 15. Coffee filter 16. Measuring Spoon/ Tamper IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
  • Page 10 Espresso Maker Model No. SDA2698 User Manual Before first Use of Your Espresso maker • Remove all packing materials and discard responsibly. • Ensure all parts are present - see Description of Parts above. • Check that there is no transit damage to the mains cable or product.
  • Page 11 Espresso Maker Model No. SDA2698 User Manual 3. Place one hand on the top of the espresso maker to support the unit and attach the Coffee Filter Holder (14) using the Filter Holder Handle (10) by holding the handle and placing it in the coffee maker as in fig.3 then rotate right to the locked position as shown below in fig.4:...
  • Page 12 Espresso Maker Model No. SDA2698 User Manual To make a good espresso coffee it is recommended to preheat the coffee maker before making the coffee. Pre-heating includes the coffee filter holder and the cup(s) so that the flavour of the coffee is not influenced by a cold machine.
  • Page 13 Espresso Maker Model No. SDA2698 User Manual 7. Pour out the hot water in the cup(s) from the pre-heating and place your warmed cups on the Drip Tray Plate (11). 8. Ensure that the Steam Control (6) is set to the ‘OFF’ position.
  • Page 14 Espresso Maker Model No. SDA2698 User Manual Instructions for Use – Making a Cappuccino Coffee 1. First, prepare an espresso coffee as the detailed above in ‘Making an Espresso Coffee’ above, making sure that the cup is big enough accommodate the coffee and the frothed milk.
  • Page 15 Espresso Maker Model No. SDA2698 User Manual Notes on Coffee This Espresso Maker uses ground powdered coffee which is available from most good supermarkets and coffee retailers. Do not use instant coffee or similar with this Espresso Maker. Distance to the surface of pressed coffee powder should be about 3mm away from the edge of the filter cup (important indicator).
  • Page 16 Espresso Maker Model No. SDA2698 User Manual Using the Warming Plate Place the coffee cup(s) onto the Warming Plate (13) on top of the machine to keep them warm prior to making coffee. Automatic power ‘off’ The coffee maker will turn itself off automatically 25 minutes after pressing the Power Button (2).
  • Page 17 Espresso Maker Model No. SDA2698 User Manual 3. Press the Steam Button (5), rotate the Steam Control (6) to the ‘ON’ position, the maximum level, and make steam for 2 minutes. 4. Rotate the Steam Control (6) to the ‘OFF’ position, then press the Steam Button (5) off to stop making steam.

  • Page 18: Troubleshooting Guide

    Espresso Maker Model No. SDA2698 User Manual Non-Rewireable Mains Plug If your appliance is supplied with a non-rewireable plug fitted to the mains lead and should the fuse need replacing, you must use an ASTA approved one (conforming to BS 1362 of the same rating). If in doubt, consult a qualified electrician.
  • Page 19 Espresso Maker Model No. SDA2698 User Manual Recycling Information Disposal of the Packaging Dispose of paper and cardboard in appropriate paper re-cycling facilities. Dispose of recyclable plastics in appropriate plastic re-cycling facilities. Dispose of non-recyclable plastics in the appropriate plastics collection service.

  • Page 20: Warranty

    As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year guarantee Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty product should be returned to the place of purchase, replacement or refund is at the discretion of the retailer.
