Indoor Units; Outdoor Units - LG MULTI AMNQ09GSJAA Engineering Product Data Book

MULTI
Standard
2. Nomenclature

2.1 Indoor Units

Model Name
No.
No.
A*N : Indoor units using R410A
* Indicates Product type
1
M : Multi Room Air conditioner
Model type
2
Q : DC Inverter Cooling Only
Nominal Capacity
3
Ex) 9,000 Btu/h Class → '09', 18,000 Btu/h Class → '18'
Electrical rating
4
G: 1Ø, 220-240V, 50 Hz / 1Ø, 220V, 60 Hz
Indoor unit type
5,6
Chassis name
Functions
7
A : Basic (Standard)
8
Serial number

2.2 Outdoor Units

Model Name
No.
No.
Indicates that this is multi system outdoor unit using R410A
1
Ex) A2U : Connectable max. 2 indoor units
Model type
2
Q : DC inverter Cooling Only
Cooling/heating capacity
3
Ex) 18,000 Btu/h Class → '18', 24,000 Btu/h Class → '24'
Electrical rating
4
G : 220-240V, 1Ø, 50Hz / 220V, 1Ø, 60Hz
L : 380-415V, 3Ø, 50Hz / 380V, 3Ø, 60Hz
Outdoor unit type
5
F : Fixed multi type
Functions
6
A : Basic (Standard)
7
Serial number
AMN Q 12
1 2 3
A2U Q
1 2
A3U : Connectable max. 3 indoor units
G S
4 5
Signification
18 G
3 4
Signification
General information
J A
6 7
F A
5 6
A
8
B
7
3
