LG MULTI AMNQ09GSJAA Engineering Product Data Book page 11

MULTI
Standard
2. Specifications
Model Name
Power Supply
Capacity Cooling
Power Input Min./Nom./Max.
Running Current Min./Nom./Max.
Casing Color
Body
Dimensions
Shipping
Body
Weight
Shipping
(Row x Column x Fins per inch)
x No.
Heat Exchanger
Face Area
Type
Fan
Air Flow Rate
Type
Fan Motor
Output
Sound Pressure Level
Liquid
Piping
Gas
Connections
Drain
Safety Devices
Connections Method
Power and Communication Cable (included Earth)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And "Electric characteristics" chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound Level Values are measured at Noise Measuring chamber accordance with standard. Therefore, these values depend on the ambient conditions
and values are normally higher in actual operation(Sound Pressure : LG Internal standard, Sound Power : EN 12102 (ISO 3741).
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
V, Ø, Hz
kW
W x No.
A
-
W x H x D mm
W x H x D inch
W x H x D mm
W x H x D inch
kg (lbs)
kg (lbs)
-
2 2
m (ft )
-
3
H / M / L
m /min
3
H / M / L
ft /min
-
W x No.
H / M / L dB(A)
mm(inch)
mm(inch)
O.D. / I.D. mm
-
- Thermal Protector for Fan Motor
-
2
No. x mm
(AWG)
AMNQ18GSKAA
220-240, 1, 50
220, 1, 60
5.0
15 / 21 / 40
0.14 / 0.20 / 0.25
Munsell 7.5BG 10/2 (RAL 9016)
998 x 345 x 210
39-9/32 x 13-19/32 x 8-9/32
1,080 x 422 x 281
42-17/32 x 16-5/8 x 11-1/16
11.2 (24.7)
13.0 (28.7)
(2 x 16 x 20) x 1
0.25 (2.69)
Cross Flow Fan
14.2 / 11.3 / 9.9
501 / 399 / 350
BLDC
30 x 1
44 / 38 / 35
Ø 6.35 (1/4)
Ø 12.7(1/2)
Ø 21.5 / 16.0
Fuse
Flared
4C x 0.75 (18)
Indoor Unit
AMNQ24GSKAA
220-240, 1, 50
220, 1, 60
7.1
26 / 39 / 60
0.22 / 0.28 / 0.40
998 x 345 x 210
39-9/32 x 13-19/32 x 8-9/32
1,080 x 422 x 281
42-17/32 x 16-5/8 x 11-1/16
11.8 (26.0)
13.6 (30.0)
(2 x 16 x 20) x 1
0.25 (2.69)
Cross Flow Fan
15.2 / 12.7 / 10.2
537 / 448 / 360
BLDC
60 x 1
46 / 41 / 36
Ø 6.35 (1/4)
Ø 12.7(1/2)
Ø 21.5 / 16.0
Fuse
Thermal Protector for Fan Motor
Flared
4C x 0.75 (18)
5
