2019/05/07 17:28:55 (GMT+09:00)
SERVICE MANUAL
Ver. 1.4 2016.01
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(US model only)
With 6 ohm loads, both channels driven, from 120 – 10,000
Hz; rated 75 watts per channel minimum RMS power, with
no more than 0.7% total harmonic distortion from 250
milliwatts to rated output.
Amplifi er section
The following are measured at
US model:
AC 120 V, 60 Hz
Mexican model:
AC 127 V, 60 Hz
AEP, UK and Russian models:
AC 220 V – 240 V, 50/60 Hz
E models:
AC 220 V – 240 V, 50 Hz
Other models:
AC 120 V – 240 V, 50/60 Hz
Power output (rated)
150 W + 150 W (at 6 ohms, 1 kHz, 1% THD)
RMS output power (reference)
250 W + 250 W (per channel at 6 ohms, 1 kHz)
Inputs
AUDIO IN/PARTY CHAIN IN L/R
Voltage 2 V, impedance 47 kilohms
Outputs
AUDIO OUT/PARTY CHAIN OUT L/R
Voltage 2 V, impedance 1 kilohm
USB section
Supported format
MP3 (MPEG 1 Audio Layer-3):
32 kbps – 320 kbps, VBR
WMA: 48 kbps – 192 kbps
AAC: 48 kbps – 320 kbps
WAV: 16 bit PCM
Sampling frequencies
MP3 (MPEG 1 Audio Layer-3):
32 kHz/44.1 kHz/48 kHz
WMA: 32 kHz/44.1 kHz/48 kHz
AAC: 32 kHz/44.1 kHz/48 kHz
WAV: 8 kHz – 48 kHz
Supported USB device
Mass Storage Class
Maximum current
1 A
(USB) port
Type A
9-890-644-05
2016A80-1
©
2016.01
Photo: GTK-X1BT
Bluetooth section
Communication system
Output
Maximum communication range
Frequency band
Modulation method
Compatible Bluetooth profiles
Supported codecs
1)
The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, reception sensitivity,
antenna's
application, etc.
2)
Bluetooth standard profiles indicate the purpose of
Bluetooth communication between devices.
FM tuner section
FM stereo, FM superheterodyne tuner
Antenna
Tuning range
Speaker section
Speaker system
Speaker unit
Rated impedance
Sony Corporation
Published by Sony EMCS (Malaysia) PG Tec
GTK-X1BT
SPECIFICATIONS
Bluetooth Standard version 3.0
Bluetooth Standard Power Class 2
Line of sight approx. 10 m
1)
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
FHSS (Freq Hopping Spread Spectrum)
2)
A2DP (Advanced Audio Distribution Profile)
AVRCP 1.3 (Audio Video Remote Control Profile)
SBC (Sub Band Codec)
AAC (Advanced Audio Coding)
aptX (aptX Codec)
performance,
operating
system,
FM wire antenna
US model:
87.5 MHz – 108.0 MHz (100 kHz step)
Other models:
87.5 MHz – 108.0 MHz (50 kHz step)
2-way, Bass refl ex
Woofer: 200 mm (7
in), cone type
7
8
Tweeter: 66 mm (2
5
in), cone type
8
6 ohms
PERSONAL AUDIO SYSTEM
US Model
AEP Model
UK Model
Russian Model
Argentina Model
Australian Model
Malaysia Model
Mexican Model
General
Power requirements
US model:
AC 120 V, 60 Hz
Mexican model:
AC 127 V, 60 Hz
AEP, UK and Russian models:
AC 220 V – 240 V, 50/60 Hz
E models:
AC 220 V – 240 V, 50 Hz
Other models:
AC 120 V – 240 V, 50/60 Hz
Power consumption
110 W
Power consumption (at the Power Saving mode)
AEP, UK and Russian models:
0.5 W (When "BT STBY" is set to "OFF")
6 W (When "BT STBY" is set to "ON")
Dimensions (w/h/d) (Approx.)
757 mm × 303 mm × 363 mm
(29
7
in × 12 in × 14
8
Mass (Approx.)
software
13.8 kg (30 lb 7 oz)
Supplied accessories
Remote control (1)
R6 (Size AA) batteries (2)
FM wire antenna (1)
Design and specifications are subject to change without
notice.
– Continued on next page –
E Model
3
in)
8
SYS SET
