- Page 1 581-830F 10’MODERN TRIPOD SWING Installation Guide INSTALLATION INSTRUCTIONS 581-830F 10’ MODERN TRIPOD SWING Please read the entire manual before beginning installation. 2 CTN 16 PIPE 5 WF 23 TOTAL PCS 720# WEIGHT CLASS 70...
- Page 2 581-830F 10’MODERN TRIPOD SWING Installation Guide TAB SECTION INDEX 1. 3D AND 2D DRAWINGS 2. INSTALLATION GUIDE 3. INSTALLATION STEPS 4. COMPONENT INSTALLATION 5. APPENDIX 6. ORIGINAL COMPONENT MAINTENANCE FORMS 7. COMPLETED COMPONENT MAINTENANCE FORMS...
-
Page 3: Table Of Contents
581-830F 10’MODERN TRIPOD SWING Installation Guide Table of Contents 3D DRAWING ..................HARDWARE DRAWINGS TOP DOWN VIEW ................... COMPONENT INSTALLATION INSTRUCTION SETS FOOTING VIEW ..................APPENDIX Important ....................6 FINAL INSTALLATION STEPS When your receive your playground ..........6 MAINTENANCE AND INSPECTION Before you begin .................. - Page 4 581-830F 10’MODERN TRIPOD SWING Installation Guide...
- Page 5 581-830F 10’MODERN TRIPOD SWING Installation Guide...
-
Page 6: Important
SportsPlay recommends carefully unpacking the unit and taking an inventory before... - Page 7 581-830F 10’MODERN TRIPOD SWING Installation Guide SportsPlay Equipment inc. has provided two warning labels that state: “WARNING – Installation over a hard surface such as concrete, asphalt or packed earth may result in serious injury or death from falls.” These labels must be installed on vertical posts as per ASTM F1487.
-
Page 8: Safety Surfacing
SERIOUS INJURY OR DEATH FROM A FALL 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet Call – 618-832-9585 standard ASTM F1292 be placed under and around the structure and extend throughout the entire use zone. -
Page 9: Tools And Materials
581-830F 10’MODERN TRIPOD SWING Installation Guide Tools and Materials Files and sand paper List is for tools and materials needed that are not included with the Safety surfacing playground Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials. -
Page 10: Before Beginning
All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:... -
Page 11: Step 1: Layout
581-830F 10’MODERN TRIPOD SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing. -
Page 12: Step 3: Deck, Post & Component Installation
581-830F 10’MODERN TRIPOD SWING Installation Guide SportsPlay recommends having a CPSI (certified playground safety Step 3: Post & Component Installation inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by We recommend installing the posts once the post are square and level a CPSI. -
Page 13: Other Installation Tips
581-830F 10’MODERN TRIPOD SWING Installation Guide Other Installation Tips If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this. -
Page 14: Supervision Guide
581-830F 10’MODERN TRIPOD SWING Installation Guide Loose clothing, hoods, strings or jewelry shall be tight or not worn SUPERVISION GUIDE while playing to prevent strangulation. Although the equipment is designed, installed and maintained in accordance with Ensure the temperature of the equipment is not hazardous. Direct all safety guidelines adult supervision is required. - Page 15 581-830F 10’MODERN TRIPOD SWING Installation Guide 3/16 ALLEN ½ X ½ SET SCREW 2 3/8” SWING HANGER ¼ ALLEN 5/16 LOCK WASHER 5/16 X 1 BUTTON HEAD NUT 5/16 X 2 ½ BUTTON 5/16 ALLEN HEAD BOLT...
- Page 16 581-830F 10’MODERN TRIPOD SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...
- Page 17 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS Recommended crew (Adult): 2 Installation time: 4 hr User age: 5-12 Use zone: 40’ x 64’ Weight: 720 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
- Page 18 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 583-524 Swing End Fitting 583-523 Center Fitting 2 3/8” x 13’ Pipe 553-602 2 3/8” x 11’ Pipe 343-210A 2 3/8” Swing Hangers 585-520 ½” x ½” Socket Set Screw 196-802 5/16”...
- Page 19 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION FOOTING INFORMATION Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
- Page 20 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW March 2, 2016...
- Page 21 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING Apply locktite to all bolts during assembly prior to Tube – FloCoat® Galvanized 2 3/8” O.D. completely tightening them. Hardware – Stainless steel & tamper resistant ...
- Page 22 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:...
- Page 23 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Swing Hangers: You will need eight swing hangers (5), attach the swing hangers to the top rail following spacing on page 4. See (Detail C). __7) Dig footing holes: Footing holes may be marked out and dug from footing layout;...
- Page 24 581-830F 10’ MODERN TRIPOD SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __10) Once the concrete has set, back fill dirt over the footing holes; inspect the area and components for tools, hazardous debris and sharp edges. Verify all components are installed and all hardware is tight and then install the safety surfacing.
