- Page 1 © Made in Ireland Congratulations! On the purchase of your Boru 400 Eco 5.0kW INSTALLATION & OPERATION INSTRUCTIONS TO AVAIL OF OUR EXTENDED WARRANTY COVER PLEASE FILL OUT WARRANTY SHEET IN FULL OR VISIT https://www.borustoves.com/warranty FOR DETAILS...
-
Page 2: Specification & Technical Details
SPECIFICATION & TECHNICAL DETAILS 400-E Stove Performance Results Output and Efficiency All efficiencies in table are Net values Wood Logs Results, 0.75 hour refuels Parameter A19/210-1 A19/210-2 A19/210-3 Mean 0.78 Test duration 0.75 0.78 0.80 Total efficiency 76.8 76.4 76.3 76.5 Nominal heat output 0.08... - Page 3 Heat Producing Appliances MUST BE ADHERED TO. Boru Stoves cannot accept responsibility for any fault arising through incorrect use or installation. It is the responsibility of the stove installer & owner to be aware of any amendments to the above document &...
-
Page 4: Important Warning
• Check the body of the stove for any damage or defect – Any damage or defect must be reported within 72 hours of delivery. • DO NOT INSTALL A DAMAGED OR DEFECTIVE STOVE. • It is required that the stove be installed by an experienced and accredited stove installer that is familiar with Boru Products, contact the local authorised dealer for advice. - Page 5 • If the stove is not properly installed, a house fire may result, to reduce the risk of fire, follow the installation instructions. Failure to follow instructions may result in property damage, bodily injury, or even death. • Use smoke detectors in the room where the stove is installed. Poor ventilation or excess time loading the unit may cause these detectors to activate.
-
Page 6: Stove Location
Metal Parts When installing or servicing this stove, care should be taken to avoid the possibility of personal injury. Flue Collar Place the flue collar on top exit/rear exit of the opening and secure with bolts provided. A cord is fitted on the blanking plate to ensure a good airtight seal. -
Page 7: Air Supply
Fibreglass cannot be used under any circumstances and could pose a serious health risk. CONNECTION TO THE CHIMNEY All Boru Stoves are certified with a chimney draught reading of 12-14 pascals – where the chimney draught exceeds this reading we recommend a draught stabiliser be installed – please contact an accredited chimney specialist for further details. - Page 8 installation. Flues should be: 1. Vertical wherever possible and where a bend is necessary, it should not make an angle of more than 45° with the vertical. 2. Horizontal flue runs should be avoided except in the case of a back outlet appliance, when the length of the horizontal section should not exceed 150 mm unless otherwise specified.
-
Page 9: Additional Information
draft is not lost. A blocked chimney flue could result in performance implications, cause serious injury or even death. • Failure to do this will affect the efficiency of the stove and may cause down draughts which will mean dangerous products of combustion are emitted into the room which may cause serious injury or even death. - Page 10 Burning petroleum based fuels will push your stove beyond it’s design capability. This will over fire your stove and void your extended warranty. Please do not hesitate to contact any member of our team at Boru Stoves if you have any further queries.
-
Page 11: Lighting The Stove For The First Time
Fuel should be stored in a dry place and fuel should be dried for at least 18-24 months in the correct conditions or have a moisture content of 20% or below to ensure you get the optimal efficiency from the stove. Wet wood/peat may cause serious creosote, which may damage the flue system and even the stove. -
Page 12: Warranty
• Burn only fuel recommended in this manual, failure to adhere to fuel guidelines will void the extended warranty. • After each fire leave the stove to cool down completely before lighting the next fire. • It is important to note that there may be an unpleasant odour for the first few fires, this is nothing to be alarmed about, it is just part of the curing process. -
Page 13: Do Not Overfire
REFUELING • Before refuelling open the primary & secondary levers to reduce the chance of fuel odour. • The handle & sliders get extremely hot – care must be taken when refuelling, use a protective glove or USE MULTI TOOL PROVIDED •... -
Page 14: Replacement Parts
STOVE MAINTENANCE Boru Stoves recommend your stove is checked and serviced by an accredited engineer at least once a year It is very important that your stove is checked regularly for the following: •... - Page 15 Do not open the door until the stove is completely cool. Glass for your Stove is 4mm Boru Stoves Heat Resistant Glass. Only use genuine Boru Glass. If handling glass whether broken or not – ALWAYS wear protective gloves.
-
Page 16: Ash Removal
Other precautions include: • Avoid burning damp or unseasoned fuel • Not overfilling the grate • Allowing the last refuelling of the day to burn on high for 20 to 30 minutes before closing the dampers • Glass is heat resistant but not force resistant •... -
Page 17: In The Event Of A Chimney Fire
What warranty do I have with my Boru Stove? • Boru Stoves offer a limited extended warranty cover of 5 years on the 400 Eco excluding wearable parts, from date of purchase, including your statutory rights. • Please be advised your extended warranty must be activated within three months of purchase. - Page 18 • To activate an extended warranty all Boru Stoves MUST be purchased from an authorised dealer. This extended warranty does not include your wearable parts. Why am I not getting heat from my stove •...
- Page 19 Why is the stove not heating my room • Check with an accredited heating specialist if the stove has been installed correctly and as per guidelines set out in this manual • Check that the certified output meets your requirements. Does my chimney need to be lined •...
-
Page 20: Service & Maintenance Record
SERVICE & MAINTENANCE RECORD Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service &... - Page 21 SERVICE & MAINTENANCE RECORD Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service & items replaced: Date: Serviced by: Signature: Contact number: Details of service &...
- Page 22 EXTENDED WARRANTY POLICY & PROCEDURES Boru Stoves offer a limited extended warranty cover of 5 years on the 400 Eco Stove, from the date of purchase, including your statutory rights. Please be advised your extended warranty must be activated within three months of purchase. After this Boru Stoves, will cancel their offer of an extended warranty. This offer can be availed either by registering online at http://borustoves.com/boru-stoves-warranty/...
-
Page 23: Troubleshooting
TROUBLESHOOTING The weather conditions outside the building could have an effect on the burning performance of the Boru Stove. These could include: • Windy days - smoking from the appliance. This could be caused by turbulent airflow around the chimney terminal, possibly caused by the position of other buildings or obstacles nearby. - Page 24 Please provide contact details of your stove installer: Name: Phone No: Address: E-Mail: Please tick to confirm you authorise Boru Stoves to contact your stove installer: Yes, I authorise _____ No, I do not authorise _____ If you answered no, please state the reason: ___________________________________________________________________________...
- Page 25 Phone: 0504-59033 Please be advised your extended warranty must be activated within three months from the day of purchase. After this Righpur Ltd t/a Boru Stoves will cancel their offer of extended warranty. If you require confirmation of an activated extended warranty please include a stamped addressed envelope or provide us with your email address.
- Page 26 • Stove serial number Boru Stoves offer a 5 year extended warranty be installed as Boru Stoves are not in any way • Copy of extended warranty on all Boru Dry Stoves including your 12...
