Liebert® CRV300CW
50 Hz/60Hz, 32-50 kW
User Manual
English, Cod. 265381, rev. 12.01.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liebert CRV300CW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vertiv Liebert CRV300CW

Summary of Contents for Vertiv Liebert CRV300CW

  • Page 1 Liebert® CRV300CW 50 Hz/60Hz, 32-50 kW User Manual English, Cod. 265381, rev. 12.01.2018...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS CAUTION • The manual is retained for the entire service life of the machine; • The user reads the manually carefully before carrying out any operations on the machine; • The control is used exclusively for the purpose for which it is intended; incorrect use of the control shall release the manufacturer any liability.
  • Page 4 Attention: data relevant to the unit supplied is indicat- ed on the inboard label (see the blank facsimile below). Data in the manual is referred to standard conditions and can be modified without any advance notice. Data plate fac-simile for 50 Hz units, CE marked POS.
  • Page 5 Family CR Unit size Digit 6 - Air Discharge Digit 16 - Enclosure options Air Discharge Horizontal airflow - In the Row Black Vertiv RAL 7021 colour Digit 7 - Cooling System Type Digit 17 -High Voltage Options Chilled Water None...

  • Page 6: Table Of Contents

    Contents 1 - PRELIMINARY OPERATIONS ..........................1 1.1 Inspection .......................................1 1.2 Handling .........................................1 1.3 Operating limits.......................................1 1.4 Product Description ....................................1 PLACEMENT ................................3 2.1 Single Row Placement ...................................3 2.2 Two Rows Placement .....................................3 2.3 Liebert CRV Applied in SmartAisle™ Cold Aisle Containment ......................4 ®...

  • Page 7: Preliminary Operations

    1 - PRELIMINARY CENTER OF GRAVITY DISTANCES FROM OPERATIONS CORNER ± 50 mm ± 50 mm ± 100 mm 140.5 586.8 889.7 WARNING! 140.5 586.8 889.7 Risk of top-heavy unit falling over. Can cause death, injury and equipment damage. Read all of the following 140.5 586.8 889.7...
  • Page 8 It is targeted for small and medium data centers and it is optimized Pos. Description to ensure maximum cooling capacity in a minimal footprint. The Top supply and return connections components of the system are managed by the Liebert iCOM ®...

  • Page 9: Placement

    Use walls or opposing racks to minimize the width of the hot and cold aisles; target 26ft (0.6 to 1.8m). For site specific recommendations on how to optimize your space for row based cooling, contact your local Vertiv representative. 2.1 Single Row Placement The Liebert CRV can be placed either at the end of a row or in ®...

  • Page 10: Liebert ® Crv Applied In Smartaisle™ Cold Aisle Containment

    2.3 Liebert CRV Applied in SmartAisle™ Cold Aisle Fig. e - Liebert CRV – Two Rows Placement ® ® Hot Return Air – Hot Aisle Containment Using the Liebert CRV with the SmartAisle is always recom- ® mended to ensure top efficiency, but not required. It is an excellent Rack Rack Rack Rack Rack Rack solution when attempting to cool widely varying heat loads, (ie.

  • Page 11: Recommended Unit Handling Equipment

    NOTICE Wooden crate RISK OF OVERHEAD INTERFERENCE! CAN CAUSE UNIT AND/ Open all the latches on the shipping crate. OR STRUCTURE DAMAGE! THE UNIT MAY BE TOO TALL TO Remove top and lateral wooden panels of shipping crate. FIT THROUGH A DOORWAY WHILE ON THE PALLET. MEASURE THE UNIT AND DOORWAY HEIGHTS AND REFER TO THE INSTALLATION PLANS PRIOR TO MOVING THE UNIT TO VERIFY CLEARANCES.

  • Page 12: Installation

    At least two properly trained and qualified personnel may roll the Liebert CVR down the ramp and off the pallet onto a flat ® surface. 3.5 Installation Opening the front panel, there are: serial number of the unit for service (a) To prepare installation open the electrical panel: Remove back panel Remove EP safety panels...

  • Page 13: Water Connections

    4 - WATER CONNECTIONS Open the door Remove screws Rotate baffles to desire direction Reinstall all screws 4.1 - Water connections - supply humidifier and drain water DOWN OPTION connections connections Condensate pump + Available choice Available choice humidifier Condensate pump Available choice Available choice Humidifier...
  • Page 14 • Condensate pump: • For the bottom connections use the flexible pipe inside the unit. Open 48 mm knockout located in the bottom of the unit. The head losses defined Vertical Total tubing length in this table are calcu- discharge 10 m 20 m 30 m...
  • Page 15 Quality Requirements Anti-corrosion wather properties for Copper 7.5 ÷ 9 <100 >10 Total hardness 4.5 ÷ 8.5 <50 <2.0 <0.5 Free Chlorine <0.5 <0.5 <0.05 <50 <50 Temperature ºC <65 Oxygen content <0.1 Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...

  • Page 16: Electrical Connections

    5 - ELECTRICAL Before proceeding with the electrical connections, ensure that: • All electrical components are undamaged; CONNECTIONS • All terminal screws are tight; • The supply voltage and frequency are as indicated on the unit. Power supply cable connections: High voltage •...
  • Page 17 Remove filters and shut-off main switch DETAIL DETAIL Remove electrical panel brackets Remove electrical panel grille Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...

  • Page 18: Protective Features Of Electrical Heaters

    Pull out electrical panel sensor monitors the temperature of the air entering the rack equip- ment. The reading is used to control the operation of the unit, so the sensor must be placed as directed below or the equipment will not operate properly.
  • Page 19 • Place the Liebert 2T sensors on the highest density racks. to be set to 2-3. If a CAN device is in the middle between other CAN ® Place the Liebert 2T sensors on racks far away from the Li- •...

  • Page 20: Start-Up

    6 - START-UP 6.1 - First start-up (or after long standstill) Start the air conditioner as follows: Open all valves in the water circuit according to the instruction label attached to the valve. In the “iCOM” control system factory setting the stand alone mode is standard.

  • Page 21: Environment Protection

    9.2 Spare parts 1 - REMOVE N°2 SCREWS Only original spare parts made by Vertiv may be used. Using third-party material can invalidate the warranty. When making inquiries always refer to the “Component List” supplied with the equipment and specify the model number, serial number and, if available, the part number as well.

  • Page 22: Inspection - Replacement Of The Electrical Heaters

    2 - REMOVE THE COVER OF THE PUMP Open the front door. 3 - REMOVE THE PUMP Pump maintenance: • Disconnect power to unit using disconnect switch. • Open the rear door • Check and clear obstructions in gravity lines leading to con- densate pump Remove the fan’s grilles •...

  • Page 23: Dismantling The Unit

    Disconnect the fan’s power connections. Remove the eight bolts attaching the fan to be replaced to the Remove the fan frame assembly by removing the bolts in the fan frame assembly. DETAIL corner; there are four bolts at each corner. Reverse the steps to install the replacement fan.

  • Page 24: Unit Diagnostic

    9.9 Unit diagnostic PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Dirty filters Replace filters False filter clogs Call Vertiv Service Incorrect positioning of remote temperature Verify remote temperature sensors correct positioning sensor/s Remote temperature sensor/s issue Call Vertiv Services Racks temperature is too...
  • Page 25 App. A HUMIDAIR HUMIDIFIER App. A.1 Electrode humidifier The operation of immersed electrode humidifiers is based on a very simple physical principle. As common drinking water contains a certain quantity of dissolved mineral salts, and is consequently slightly conductive, applying a volt- age to metal electrodes immersed in the water creates an electric current that heats the water until producing steam (Joule effect).
  • Page 26 The steam production rate can be controlled by varying the water level in the cylinder; the higher the water level, the deeper the electrodes are immersed into it and the greater the steam production. Note 1 In case of low water conductivity consult Vertiv Service. Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...
  • Page 27 Note 2 When starting with an empty cylinder, the water conductivity is normally insufficient for the HUMIDIFIER STEAM OUTPUT to be reached immediately. Therefore the humidifier produces as much steam as possible to fill the cylinder completely. Any evaporation water is immediately refilled. The drain valve is kept shut and therefore, as the steam does not contain any salts, the conductivity of the water within the cylinder slowly increases until the HUMIDIFIER STEAM OUTPUT is obtained.

  • Page 28: App. A Technical Data Table

    App. B TECHNICAL DATA TABLE Tab. 1 - Electrical data RESIDUAL-CURRENT CIRCUIT Configuration Model Unit Power supply FLA [A] LRA [A] BREAKERS IΔn = 0.3A (400V) (*) CR032RC Cooling CR038RC 230V/1ph/50Hz CR060RC 12.6 Cooling + Electrical heating CR032RC (post heating during CR038RC 10.7 400V/3ph+N/50Hz...
  • Page 29 Tab. 3 - Calibrations of electrical components Refrigeration Component Application Model Calibration Drawing Circuit Item no. Set point range 0.5- Clogged filter differential CR032- Johnson Control P2 4 mbar pressure switch 60RC 331-4 Filter G2 = 2 mbar (CF) Filter F5 = 3mbar Setting ring Servomotor for chilled CR032-...

  • Page 30: App. B Installation Drawing

    App. C INSTALLATION DRAWING Fig. 1. OVERALL DIMENSIONS / SERVICE AREA TOP PLENUM FRONT PLENUM Tab. 1 - Overall dimensions Weight Models CR032RC 2000 1100 / 1200 CR038RC 2000 1100 / 1200 CR060RC 2000 1100 / 1200 Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...
  • Page 31 Fig. 2. HOLE ON THE RAISED FLOOR FOR PIPING FRONT SIDE OF THE UNIT TOP VIEW FRONT SIDE OF THE UNIT Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...
  • Page 32 Fig. 3. ELECTRICAL CONNECTIONS - ENTRY TOP INLET Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...
  • Page 33 App. D REFRIGERANT, HYDRAULIC AND ELECTRICAL CONNECTIONS Fig. 1. CR032RC - CR060RC CONNECTIONS BOTTOM CONNECTIONS TOP CONNECTIONS TOP CHILLED WATER CONNECTIONS 58.2 2.29 1100.0 60.0 EC-LV2B 43.31 2.36 ICWT 40.0 1.57 EC-LV1B 83.0 60.0 3.27 2.36 OCWT 60.0 2.36 60.0 2.36 70.0 90.0...
  • Page 34 Fig. 2. Electrical board layout Wire bridge-Ponte a filo Kabelbrücke-Pont à fil Puente de hilo LEVEL 1 /BOTTTOM/ LEVEL 2 /TOP/ SPRING TERMINALS STTB2,5 Liebert CRV, Chilled Water - UM - 265381 -12.01.2018...
  • Page 35 ELECTRICAL FIELD CONNECTIONS DESCRIPTIONS 50 Hz STANDARD ELECTRICAL CONNECTIONS Primary high voltage entrance Quantity (2) 28 mm diameter concentric knockouts located in bottom of box Secondary high voltage entrance Quantity (2) 35 mm diameter concentric knockouts located in top of box Primary low voltage entrance Quantity (1) 18mm diameter knockouts located in bottom of unit Secondary low voltage entrance “...

  • Page 36: App. D Refrigeration & Hydraulic Circuits

    App. E REFRIGERATION & HYDRAULIC CIRCUITS Fig. 1.LIEBERT CRV: CR032RC - CR060RC (only with optional 2 ---way valve) CHILLED WATER OUTLET (top connections) CHILLED WATER OUTLET (bottom connections) CHILLED WATER INLET (top connections) CHILLED WATER INLET (bottom connections) POS. Components POS.
  • Page 37 Fabrikant - - Producent Κατασκεναστηζ Vertiv S.r.l. - Zona Industriale Tognana Via Leonardo da Vinci, 16/18 - 35028 Piove di Sacco - Padova (Italy) Il Fabbricante dichiara che questo prodotto è conforme alle direttive Europee: The Manufacturer hereby declares that this product conforms to the European Union directives: Der Hersteller erklärt hiermit, dass dieses Produkt den Anforderungen der Europäischen Richtlinien gerecht wird:...
  • Page 38 Leonardo Da Vinci 16/18, Zona Industriale Tognana, 35028 Piove di Sacco (PD) Italy, Tel: +39 049 9719 111, Fax: +39 049 5841 257 © 2016 Vertiv Co. All rights reserved. Vertiv, the Vertiv logo and Vertiv Liebert CRV300 are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners.
