Page 1
5. Please refer to the reference table to use this product 6. Do not immerse the plug into water or other liquids. 7. Do not allow children or the inexperienced to operate or use the product alone without safety guarantee. 8. Please refer to actual products and APP. ADP SERIES...
Smart DC Pump I. Introduction Jecod DC pump is inspected and tested to ensure the safety and operating performance product. Please read this manual carefully before operating correctly. In case of the improper usage, or maintenance to cause the pump damage.
Page 3
When using the pump, please pay attention to the position of the pump. Please connect the pump supply after finishing the installation. If the pump can’t pump the water out for the first time, it might be caused by the air in the pump body. Please ADP SERIES...
Page 4
7. The pump can’t be used in the swimming pool. 8. This product has a variety of protection functions. When it enters the protection state, after troubleshooting, please plug in and restore the normal operation of the pump. ADP SERIES...
1. Adjustable the flow rate and head max. 2. “Feed” mode, Pause, Timing, delay, Wi-Fi, Restart function. 3. Memory function, ensure that the pump rework while keeping the same parameters. Operation Function: Wi-Fi indicator light Power indication light Wi-Fi button Controller Panel ADP SERIES...
Page 6
A. Press Wi-Fi button for about 5 seconds, the Wi-Fi indication light flashing alternative in green and blue. The Pump is into smart configuration mode. B. Press Wi-Fi button for about 10 seconds, the Wi-Fi indication light flashing simultaneous in green and blue. ADP SERIES...
Page 7
Google Play to download the application. Alternative, the user may scan the QR code on the package or user manual to download the application. (Note: Scan function in certain countries or areas may be unavailable to read the QR code properly.) ADP SERIES...
B. Choose email way to register, fill the information as required and tap Create account; C. After registration, return back to the login page. enter the account and password to log in. Note: Phone number registration is valid for mainland China only. ADP SERIES...
Tap Forget Password on the log-in page. Enter your email address and tap Send link. Check your email and follow the instructions to reset your password. Then back to the log in page to input your account and new password to log in. ADP SERIES...
Page 10
1. Main page Add new devices Add new devices Go to My Group Go to Setting 2. Add new pump Tap My Devices. Tap “Add Now “ or tap the top right “ +” icon to add your ADP SERIES...
Smart configuration and AP configuration modes. Choose one mode to link your device. Smart Configuration mode: After the device is powered on, the Wi-Fi icon on the upper left of the controller screen flashes, and the device enters the intelligent distribution network mode. ADP SERIES...
Page 12
Smart DC Pump Choose the confirmation” Device is in smart configuration mode” then tap “Next”, start to smart configuration. Follow the instructions. Enter Wi-Fi password and tap Next. ADP SERIES...
Page 13
AP Configuration : Long press the Wi-Fi key of the device for about 5 seconds, and see that the Wi-Fi with AP icon flashes in the upper left of the screen, and the device enter into the AP network ADP SERIES...
Page 14
Smart DC Pump distribution mode. Tap “AP Network “ in the upper right corner on APP device page to enter into AP configuration. Check the confirmation “ Device is in AP configuration mode” and tap “Next”. ADP SERIES...
Page 15
PS: Due to different operating system, IOS and Android operate differently in the following details. A. IOS System: After entering the Wi-Fi password, you need to switch manually the Wi-Fi of the phone to "Jebao_WiFi-xxxx", the specific operation as below: ADP SERIES...
Page 16
Smart DC Pump Tap “Go to settings”. Tap “Settings” in the upper left corner to enter the mobile phone settings page, then enter the Wi-Fi setting page as below. ADP SERIES...
Page 17
Smart DC Pump Go to Settings > Wi-Fi and choose the Jebao_WiFi-xxxx” with password 123456789. 123456789 After connection successfully, tap “Jebao Aqua “return back to the APP. ADP SERIES...
Page 18
The configuration starts automatically. Tap “Start” to control the device after the device has been added successfully. B. Android: After input the Wi-Fi password, need to manually switch the Wi-Fi connection "Jebao_WiFi-xxxx". The specific operation is as follows. ADP SERIES...
Page 19
Wi-Fi Settings screen, Switch the Wi-Fi of the mobile phone to "Jebao_WiFi-xxxx" with the password 123456789. After successful connection, manually return to APP, APP prompts to connect router Wi-Fi, tap “Confirm”. Enter the mobile phone Wi-Fi setting page. ADP SERIES...
Page 20
1.In the APP login interface, tap the “Access Point (direct)” connection at the bottom right or tap the login to enter the main interface and select the “Access Point (direct)” connection in “Settings”. ADP SERIES...
Page 21
Smart DC Pump 2. Select the device type, check the confirmed device to enter AP Hotspot mode and tap “Next”. ADP SERIES...
Page 22
3. Select the Wi-Fi name of the device, tap Confirm. Jump to the phone Wi-Fi setting interface. Select the hotspot "Jebao_WiFi-xxxx" issued by the device (the name is the same as the device name), enter the password 123456789 and tap Connection. Manually return to APP after successful connection. ADP SERIES...
Page 23
3. AP direct connection is only suitable for control of the device in a non-Wi-Fi environment. (Manual calibration time is required when the equipment is directly connected to AP after delivery. See V.5 Pump Management for detail. ) ADP SERIES...
Drag the arc progress bar (drag to the end then effective), Change the gear value of the pump. The minimum gear is 30 and the maximum is 100. Manual control bar Current gear value Long press icon for 2 seconds ON/OFF button Feed icon Program icon ADP SERIES...
Page 25
The pump will stop running immediately according to the setting feeding time. Press the "Feed" icon 2 seconds to enter the feed settings. Set the feeding pause time, turn on the feeding switch, then tap save and return. ADP SERIES...
Tap the circle twice Choose the mode Tap the "Stop, Auto, Feed" icon or tap the circle twice to edit, each time period. ADP SERIES...
Page 27
Choose the work mode of the plan time period Drag the slider to adjust the start and end time or to modify start and end time directly. Tap “Done” to save the plan setting. If want to delete the current setting period, then tap delete. ADP SERIES...
Page 28
After the setup is completed, return back to the main page and tap the “plan” icon to run the plan mode. Note: The plan mode will be closed if you manual to set the flow stage (Plan mode effect after ending the manual mode). ADP SERIES...
Page 29
Tap My Groups Select “ADD NOW” or the “+” sign on the upper right-hand side to add a group. Tap “Aqua pump”, after enter the group name, select the pump that need to be grouped, and tap "Confirm". ADP SERIES...
Page 30
2)Manage groups Tap to go to the edit You may rename the group or re-select the pumps which you want to add or delete from the group. Tap to save Rename ADP SERIES...
Page 31
Smart DC Pump Save Delete pump Add pump Tap “-” on the individual pump you want to delete and tap Delete to delete the pump 3) Delete Groups ADP SERIES...
1. The factory time of the equipment may not be accurate, so the first time to use the AP direct connection mode of the mobile phone needs to set the calibration time (tap the set time). ADP SERIES...
Page 33
2. Users can also change the name of the pump to facilitate management. Rename 3.You can also delete the current pump, but when you want to add another pump, you should reconfigure the network to add the pump. Reset the Wi-Fi module if necessary. ADP SERIES...
APP prompt power description indicator Controller over blinks twice The working current is temperature quickly abnormal. Check whether the water pump cable is short-circuited or the controller is abnormal. Slow flashing The pump is in “feed” or “stop” mode. ADP SERIES...
Page 35
The pump must be filled with water before operation. The motherboard is in bad contact The Wi-Fi with the module and the module fails to communicate communication part is with the damaged. Contact suppliers or mainboard manufacturers. ADP SERIES...
●Monthly maintenance will prolong the pump life. Clean the rotor, remove the dirt etc. ●The power cord of the pump must be under the power socket to form a drip ring to prevent water into the power socket along the power cord ADP SERIES...
Page 37
Not put it together with the domestic waste which should be solved as an authorized place for recycling of electrical and electronic appliances for collecting and recycling waste. Please consult with your local seller, to make sure the product is disposed in an environmental and healthy way. ADP SERIES...
