KYOWA CAN-40A Instruction Manual

Can card for edx-2000a/edx-100a
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This product is a copyrighted work of KYOWA ELECTRONIC INSTRUMENTS Co., Ltd. All rights reserved.
Copying or reproduction of this product, whether in part or whole, is strictly prohibited without permission.
The contents of this Manual are subject to change without prior notice.
CAN CARD for EDX-2000A/EDX-100A
I
NSTRUCTION MANUAL
Thank you for purchasing KYOWA's product CAN-40A, CAN card for EDX-2000A
(Memory Recorder/Analyzer) or EDX-100A(Universal Recorder).
Read this manual carefully to ensure the long life and reliability of the product.
The product should not be used in any manners other than as described in this Instruction
Manual.
IM-A-583c May 2008
CAN-40A
