INSTRUCTIONS AND ADVICE FOR THE USE,
INSTALLATION AND MAINTENANCE OF
Dear Customer,
Thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the
very highest quality materials, will meet your requirements in the best possible way. This
appliance is easy to use. it is, however, important to thoroughly read the instructions in
this handbook in order to obtain the best results.
These instructions are only valid for the countries of destination, the identification
symbols of which are indicated on the cover of the instruction manual and on the
appliance itself. The manufacturer shall not be held responsible for any damages to
persons or property caused by incorrect installation or use of the appliance.
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to
printing or transcription errors; the designs in the figures are purely indicative. The Manufacturer
alsa reserves the right to make any modifications to the products as may be considered necessary or
useful, also in the interests of the user, without jeopardizing the main functional and safety features
of the products themselves.
BUILT-iN
GLASS HOT PLATES
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Novy 1916
Summary of Contents for Novy 1916
- Page 1 INSTRUCTIONS AND ADVICE FOR THE USE, INSTALLATION AND MAINTENANCE OF BUILT-iN GLASS HOT PLATES Dear Customer, Thank you for having purchased one of our products. We are certain that this new, modern, functional and practical appliance, built with the very highest quality materials, will meet your requirements in the best possible way. This appliance is easy to use.
- Page 2 DESCRIPTION OF THE HOT PLATES Rapid Gas Burner of 3000W Semirapid Gas Burner of 1750W Auxiliary Gas Burner of 1000W Enamelled steel pan support for rapid burner Enamelled steel pan support for semirapid burner Enamelled steel pan support for auxiliary burner Burner no1 control knob Burner no2 control knob ( Left ) Burner no2 control knob ( Right )
- Page 3 1) BURNERS A diagram is screen-printed above each knob on the front panel. This diagram indicates to which burner the knob in question corresponds. After having opened the gas mains or gas bottle tap, light the burners as described below: -Automatic electrical ignition Push and turn the knob corresponding to the required burner in an anticlockwise direction until it reaches the full on position (large flame fig.
- Page 4 WARNING: Device and its accessible parts are hot during operation. Touching the heating elements should be avoided. Children under 8 years of age should be kept away, if they cannot be monitored continuously. This device can be used by children over 8 years of age, people with physical, hearing or mental challenges or people with lack of experience or knowledge;...
- Page 5 make sure that the pan handles are WARNINGS: correctly positioned and keep a check When the plate is switched on for the first foods requiring oil and grase to cook since time, or if has remained unused for a long these products can easily catch fire.
- Page 6 CLEANING IMPORTANT: Always disconnect the appliance from the gas and electricity mains before carrying out any cleaning operation. 2) HOT PLATE Periodically wash the hot plate, the enamelled stell pan support, the enamelled burner caps “C” and the burner heads “M” (see fig. 8) with lukewarm soapy water. Following this, all parts should be thoroughly rinsed and dried.
-
Page 7: Installation
INSTALLATION This information is intended for the installer or service engineer, as the person responsible for assembly, connection and service. If you install or attempt to repair/adjust the appliance yourself the manufacturer will not be held responsible for any possible damage. Installation must only be performed by a fully qualified electrician TECHNICAL INFORMATION FOR THE INSTALLER who must ensure regulations laid down for installation/service are observed. -
Page 8: Room Ventilation
INSTALLATION IMPORTANT INSTALLATION SPECIFICATIONS The installer should note that the appliance that side walls should be no higher than the hot plate itself. Furthermore, the rear wall, the surfaces surrounding and adjacent to the appliance must be able to withstand an overtemperature of 65 K. The adhesive used to stick the plastic laminate to the cabinet must be able to withstand a temperature of not less than 150°... -
Page 9: Gas Connection
INSTALLATION 7) GAS CONNECTION Before connecting appliance, check that the values on data label affixed to the underside of hot plate correspond to those gas and electricity mains in the home. A label on appliance indicates regulating conditions: type of gas and working pressure. -
Page 10: Electrical Connection
INSTALLATION 8) ELECTRICAL CONNECTION The electrical connections of the appliance must be carried out in compliance with the provisions and standards in force. Before connecting the appliance check that the socket or system an efficient earth connection in compliance with the provisions standards force. - Page 11 ADJUSTMENTS This information is intended for the installer or service engineer, as the person responsible for assembly, connection and service. If you install or attempt to repair/adjust the appliance yourself the manufacturer will not be held responsible for any possible damage. Installation must only be performed by a fully qualified electrician who must ensure regulations laid down for installation/service are observed.
-
Page 12: Replacing The Injectors
CONVERSIONS This information is intended for the installer or service engineer, as the person responsible for assembly, connection and service. If you install or attempt to repair/adjust the appliance yourself the manufacturer will not be held responsible for any possible damage. - Page 13 SERVICING This information is intended for the installer or service engineer, as the person responsible for assembly, connection and service. If you install or attempt to repair/adjust the appliance yourself the manufacturer will not be held responsible for any possible damage.
- Page 14 SERVICING CABLE TYPES AND SECTIONS SINGLE PHASE TYPE TYPE OF POWER SUPPLY PLATE CABLE H05 R R - F / VV-F Gas hot plate Section 3 X 0.75 mm ATTENTION!!! the power supply cable replaced, the installer should leave the ground wire longer than the phase conductors (fig.
-
Page 15: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS Before leaving the factory this appliance will have been tested and regulated by expert and specialized personnel in order to guarantee the best performance. Any repairs or adjustments that may be subsequently required may only be carried out by qualified personnel with the utmost care and attention. - Page 16 PRODUCT INFORMATION Model description (inci. version) 1916 Type of hob Gas Hob Number of cooking zones and/or areas Energy efficiency per gas burner (EE gas burner) Front left 58,7 Rear Left 56,8 Front Center Rear Center Front Right Rear Right...
- Page 17 The symbol on th e pro duct or on i ts packaging indi cates tha t th is pro duct may no t be trea ted as h ouseho ld waste. I nstead it sha ll be hande d o ver to the a ppli ca ble collect ion po int for the re cycling of electrica l and electronic equipment.
